Tornado SFS1-500B3IW Manuel utilisateur

ITEM NO.: HI-FAN-20POF-5BA-1P

MODEL NO.: SFS1-500B3IW

20 IN. PEDESTAL OSCILLATING FAN

PACKAGE CONTENTS

A

B

C

Part Description Quantity

A Fan head 1

B Standing pole 1

C Base 1

3

1 Extending the standing pole

□Loosen the height adapter (1) on the standing pole (B).

Then pull the upper portion of the standing pole (B) to the

desired height and re-tighten the height adapter (1).

2 Removing hardware from the standing

pole

□Remove the triangular knob (BB) and washer (AA) from the

standing pole (B). Retain the triangular knob (BB) and

washer (AA) for future use.

3 Attaching the standing pole to the

base

□Attach the standing pole (B) to the base (C) using the

triangular knob (BB) and washer (AA).

4 Attaching the fan head

□Place the fan head (A) on top of the standing pole (B) and

secure in place using the plum knob (CC).

B

B

1

1

AA

AA

BB

BB

B

C

B

A

CC

4

1 Adjusting the fan tilt angle

□Ensure the fan is unplugged from the power source before

adjusting the height or angle.

□

be pulled by the cord.

□To adjust the angle of the fan head (A), loosen the fan head

knob (2), tilt the fan head (A) to the desired angle, and

re-tighten the fan head knob (2).

2 Turning the fan On/Off and adjusting

□Plug the power cord into an outlet.

□

□

T

Turn the oscillation function on by pressing the oscillation

button down. Turn the oscillation function off by pulling the

oscillation button up.

Always turn off and unplug the fan after using.

urn the switch to the desired speed. The settings are

0 = off, 1 = Low, 2 = Medium, 3 = High.

SWITCH

POWER CORD

A

2

Tornado Fans warrants this product to be free of defects in material and

workmanship for the applications specified in the Owner's Manual for a period of

12 months for the whole fan from the date of purchase. This warranty only applies

to the original purchaser of this product.

This warranty excludes damage, accidental or otherwise, to the unit not caused by

a defect in material or workmanship.

The warranty also exlcudes damage caused by misuse, tampering, modification,

missassembly, repairs or alternations, or failure to adequately maintain and care

for the unit. Operating this product under any conditions others than those

recommended or at voltages other than indicated will also void this warranty. For

warranty issues, contact the place of purchase for repair/ replacement opportunities.

The originaldated receipt or proof of purchase must accompany all returns.

All warranties, expressed or implied, are limited for 12 months for the whole fan

from the date of purchase. Please register at www.tornado-fans.com/registration

once you received the products to get the extended warranty if there is any.

Tornado is a registered trademark.

Some states do not allow for the limitation or exclusion of incidental or

consequential damages, or do not allow limitation on implied warranties. The

above limitations and exclusions may not apply to you. This warranty gives you

specific legal rights, and may also include other rights that vary state by state.

5
