TOPIC-LIGHT TPL123 Manuel utilisateur
MINI STUDIO PAR 12 x3W RGBW
1
User Manual
MINI STUDIO PAR 12x3W RGBW
TPL123
MINI STUDIO PAR 12x 3
2
Table of contents
1. Safety
instructions
............................................................................................................................... 3
1.1. FOR SAFE AND EFFICIENT
OPERATION
............................................................................3
2. Technical
Information
...........................................................................................................................4
3. Menu structure
.................................................................................................................................... 4
4. DMX Table
............................................................................................................................................9
4.1. DMX Mode 1 (1
Channel)
.............................................................................................................9
4.2. DMX Mode 2 (2
Channel)
.............................................................................................................10
4.3. DMX Mode 3 (3
Channel)
............................................................................................................. 10
4.4. DMX Mode 4 (4
Channel)
.............................................................................................................. 10
4.5. DMX Mode 5 (4A
Channel)
.............................................................................................................11
4.6. DMX Mode 6 (5 Channel) ...........................................................................................................
..
11
4.7. DMX Mode 7 (5A Channel) .........................................................................................................
..
11
4.8. DMX Mode 8 (6 Channel) ..........................................................................................
...
................
12
4.9. DMX Mode 9 (6A Channel) ........................................................................................................
...
12
4.10. DMX Mode 10 (7 Channel) ........................................................................................................
..
13
4.11. DMX Mode 11 (7A Channel) ......................................................................................................
..
14
4.12. DMX Mode 12 (8 Channel) ......................................................................................................
...
.
.
15
4.13. DMX Mode 13 (16 Channel) ......................................................................................................
...
16
4.14. DMX Mode 14 (16A Channel) ...................................................................................................
...
17
W RGBW
MINI STUDIO PAR
3
1. Safety instructions
This device is suitable for indoor use only.
All modifications to the device will void the warranty.
Repairs are to carry out by skilled personnel only.
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
Make sure to unplug the power supply before opening the housing.
1.1.
FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle.
12x3
W RGBW
MINI STUDIO PAR
4
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Information
- Full DMX 512 control
- DMX Modes with 1, 2, 3, 4, 4A, 5, 5A, 6, 6A, 7, 7A, 8, 16, 16A Channels
- Sound controlled via built-in microphone
- Adjustable sound sensitivity; Linear and curve lighting option
- Function: Color mix
Automatic color change
Built-in programs
Strobe effect with adjustable speed
Dimmer
Master/slave
- LED-display
- 3 Pin XLR Input & Output
- 12 x 3W LEDs R3,G=3,B=3,W=3
- Beam Angle: 45 degree
- Power Max. 60W
- Power input AC 100-240V, 50/60Hz
- Weight: 2.1kgs (L*W*H = 198 x 138 x 253mm)
3. Menu structure
Master-Slave mode as “A SL” or “A HO”, all of the settings are controlled by four buttons: “MODE,
Up, Down and Enter”.
Press “MODE” to switch functions (10 functions can be selected):
R E S T
A D
——>RESET ALL SETTING
“REST”: Function Code
——>MASTER-SLAVE MODE SETTING
“A”: Function Code
“D”: Set the machine as a master
12x3
W RGBW
MINI STUDIO PAR
5
——>SINGLE COLOR SETTING
“U255”: 0-255 setting for white color
——>SINGLE COLOR SETTING
“B255”: 0-255 setting for blue color
Press the “MODE” then press the “ENTER” to begin your setting. Press “UP” and “DOWN” to switch the
modes with the shining Function Code. Be sure to press the “ENTER” button to save your changing, it
won’t be saved if the button has not been pressed. Moreover, the saving data still exists even after power
off and then on.
MASTER SLAVE MODE SETTING
C 1
D 0 0 1
F 0 0 0
A H O
2 8 _ C
R 2 5 5
G 2 5 5
B 2 5 5
U 2 5 5
A D ——>Press “MODE” -> “Enter” and Press UP/Down button to setting.
Press “Enter” to confirm the DMX condition and forbid the Master Slave
Mode.
——>DMX ADDRESS SETTING
“D”: Function Code
“001”: DMX Address
——>SINGLE MODE SETTING, work only on the situation of
“F”: Function Code
“000”: Function number
——>DMX AMOUNT SETTING
“C”: Function Code
“1”: Channel amounts
——>Temperature setting
“C”: Function Code
“28”: Show temperature of LED PCB
——>SINGLE COLOR SETTING
“R255”: 0-255 setting for red color
——>SINGLE COLOR SETTING
“G255”: 0-255 setting for green color
12x3
W RGBW
MINI STUDIO PAR
6
WHILE IN MASTER-SLAVE MODE, ONLY ONE HOST MACHINE CAN BE EXISTED, IF NOT, IT
MAY CAUSE SIGNAL CONFLECTS.
DMX CHANNEL SETTING
A H O
A S L
C 1
C 2
C 3
C 4
C 4 A
C 5
C 5 A
C 6
C 6 A
C 7
——>SLAVE MODE
The machine only accept the signal that send from host-machine, it won’t accept
the signal from the console.
——>Default in C1, DMX Channel: CH. 1
——>DMX Channel: CH. 3
——>DMX Channel: CH. 4A
——>The machine will send signal to all connected slave-machines.
——>DMX Channel: CH. 6
——>DMX Channel: CH. 2
——>DMX Channel: CH. 4
——>DMX Channel: CH. 5A
——>DMX Channel: CH. 5
——>DMX Channel: CH. 7
——>DMX Channel: CH. 6A
12x3
W RGBW
MINI STUDIO PAR
7
DMX ADDRESS SETTING
SINGLE MODE SETTING:
C 7 A
C 8
C 1 6
C 1 6 A
D 0 0 1
F 0 1 0
F 0 1 0
F 0 2 0
F 0 3 0
F 0 4 0
——>Press “MODE” to begin your setting, and press “ENTER” to select the mode.
Select the UP/DOWN from F010～F121, press “ENTER” to save your setting.
——>FADE IN/OUT: 8 colors changing, Adjust the speed from
F020(slow)～F029(fast). (8 colors are from F011 to F018)
——>FADE IN/OUT: 9 colors + dark changing, the color from brightness to
dark, Adjust the speed from F030(slow)～F039(fast). (9 colors are from
F011 to F019)
——>SINGLE COLOR WITH STROBE for many times: Adjust the
changing color speed from F040(slow)～F049(fast). (8 colors are
from F011 to F018)
——>Default in D001, DMX Address from “D001-D512”, Press “ENTER” to
save the setting
——>SINGLE COLOR MODE, F010~F019, 10 colors, F010: full darkness, F011: Red,
F012: Orange, F013: Yellow, F014: Green, F015: Blue, F016: Indigo, F017:
Purple, F018: Pink, F019: full brightness
——>DMX Channel: CH. 8
——>DMX Channel: CH. 16A for 3in1 RGB
——>DMX Channel: CH. 16 for 4in1 RGBW
——>DMX Channel: CH. 7A
12x3
W RGBW
MINI STUDIO PAR
8
TEMPERATURE CONTROL
F 0 5 0
F 0 6 0
F 0 7 0
F 0 8 0
F 0 9 0
F 1 0 0
F 1 1 0
F 1 2 0
F 1 2 1
2 8 _ C
——>COLOR AUTOMATIC CHANGE: 9 colors changing, Adjust the
changing color speed from F050(slow)～F059(fast). (9 colors are
from F011 to F019)
——>Mixed WHITE STROBE: Adjust the speed from F070(slow)～
F079(fast)
——>SOUND ACTIVE MODE: Color jump, keep last color with mute.(9
colors are from F011 to F019)
——>SOUND ACTIVE MODE: Color jump, change to F020 in 10 seconds
mute, adjust the speed from F090(slow)～F099(fast). (9 colors are
from F011 to F019)
——>COLOR JUMP WITH STROBE: when jumping, change to another
color. Adjust the color changing speed from F060(slow)～
F069(fast). (9 colors are from F011 to F019)
——>SOUND ACTIVE MODE: Color jump and Strobe. Adjust the strobe
speed from F100(slow)～F109(fast). Shut down the light in 5 seconds
mute. (9 colors are from F011 to F019)
——>FADE IN/OUT and STROBE: Adjust the speed of fade in/out by F020
and the strobe speed from F110(slow)～F119(fast). (8 colors are
from F011 to F018)
——>RGBW mixed white color
——>Show the temperature of LED PCB.
——>WHITE color
12x3
W RGBW
MINI STUDIO PAR
9
SINGLE COLOR SETTING
RESET TO DEFAULT
Default as following:
MASTER-SLAVE MODE:
Controlled by DMX512 console. The machine accepts DMX512 signals and DMX dimming signals.
4. DMX Table
4.1.
DMX Mode 1 (1 Channel)
DMX Channel DMX Value Function
R 2 5 5
G 2 5 5
B 2 5 5
U 2 5 5
R E S T
——>SINGLE RED SETTING
“R255”: 0-255 setting for red color
——>SINGLE GREEN SETTING
“G255”: 0-255 setting for green color
——>SINGLE BLUE SETTING
“
B255
”
: 0
-
255 setting for blue color
——>SINGLE WHITE SETTING
“U255”: 0-255 setting for white color
——> RESET TO DEFAULT: Press “ENTER” to reset all setting.
12x3
W RGBW
MINI STUDIO PAR
10
1. R, G, B, W Dimming 1~255 Adjust LEDs dimmer low to high
4.2.
DMX Mode 2 (2 Channel)
4.3.
DMX Mode 3 (3 Channel)
DMX Channel DMX Value Function
1. R, G, B, W Dimming 1~255 Adjust LEDs dimmer low to high
2. STROBE 1~255 STROBE speed low to high
3. Linear and curve lighting
option
0~70 Linear
71~255 Curve
4.4.
DMX Mode 4 (4 Channel)
DMX Channel DMX Value Function
1. R, G, B, W Dimming 1~255 Turn on the light and R, G, B Dimming
and color is controlled by CH2, 3, 4
2. Red Dimming 1~255 Adjust red LEDs dimmer low to high
3. Green Dimming 1~255 Adjust green LEDs dimmer low to high
4. Blue Dimming 1~255 Adjust blue LEDs dimmer low to high
DMX Channel DMX Value Function
1. R, G, B, W Dimming 1~255 Adjust LEDs dimmer low to high
2. STROBE 1~255 STROBE speed low to high
12x3
W RGBW
