Topfloor TF91-TRS Manuel utilisateur

operator manual

TF91-TRS vacuum sweeper

Table of Contents

TF100-TRS I

Table of Contents

1.1 Usage conformant with intended purpose ..........................................................................2

2.1 Safety device ......................................................................................................................4

3.1 Sweeper description ...........................................................................................................5

3.2 Initial start-up ......................................................................................................................6

4.1 Movement operation ...........................................................................................................7

4.2 Sweeping operation ............................................................................................................7

4.3 Sweeping wet refuse...........................................................................................................7

4.4 After sweeping ....................................................................................................................7

4.5 Setting the traversing mechanism ......................................................................................8

4.6 Parking the sweeper...........................................................................................................8

4.7 Emptying the dustbin ..........................................................................................................9

5.1 Safety Information.............................................................................................................10

5.2 Cleaning............................................................................................................................10

5.3 Filter cleaning....................................................................................................................10

5.4 Changing the filter.............................................................................................................11

5.4.1 Dismantling the filter..........................................................................................11

5.4.2 Filter mounting...................................................................................................11

5.5 Battery charging................................................................................................................11

5.6 Side brushes.....................................................................................................................12

5.6.1 Mounting the side brushes ................................................................................12

5.6.2 Removing the Sidebrushes ...............................................................................12

5.7 Changing the main brooms...............................................................................................12

5.7.1 Dismantling the main brooms............................................................................12

5.7.2 Assembling the main brooms............................................................................13

5.8 Maintenance chart ............................................................................................................14

5.8.1 Maintenance daily..............................................................................................14

5.8.2 In addition, after every 50 running hours...........................................................14

5.8.3 In addition, after every 100 running hours.........................................................14

5.9 Malfunctions / error messages and troubleshooting.........................................................15

5.10 Technical Data..................................................................................................................16

5.11 Product marking................................................................................................................16

5.12 Disposal ............................................................................................................................16

5.13 Accessories and spare parts ............................................................................................16

Table of Contents

II TF100-TRS

5.14 Service..............................................................................................................................17

5.15 Transport...........................................................................................................................17

6EC Declaration of conformity........................................................................................................18

Table of Contents

TF91-TRS I

2 TF91-TRS

1 Introduction

This operating manual contains instructions for using the hand-operated

sweeper.

Our products are subject to continuous improvement. Therefore, design

changes that were made after this manual went to print could not be

incorporated. If you have any questions, please contact our Service

department.

The operating manual must be read and applied by all persons who

operate the sweeper.

Apart from the operating manual and the regulations for accident pre-

vention applicable in the country of use and the location of use, the

common, recognised rules for safe and technically correct working must

also be followed.

1.1 Usage conformant with intended purpose

The appliance is intended exclusively for sweeping on solid surfaces (for

example. parking areas, walkways, and shop floors). The area to be

swept should not be wet.

The sweeper may only be used by reliable and instructed personnel.

prevent children, juveniles and other unauthorised persons from using

the machine (e.g. by pulling out the key after use).

Any other use, or any use over and above that, will be considered to be

non-conformant with intended purpose. The manufacturer rejects any

and all liability for damage resulting from such use. The risk is that of the

user alone.

Usage conformant with intended purpose also includes compliance with

the operating manual and the inspection and maintenance specifica-

tions. Drive the sweeper only along expressly marked routes and spac-

es.

TF91-TRS 3

2 Safety information

1. The machine should only be used in a flawless state, as

well as in keeping with its intended purpose, in a safety-

conscious and risk-conscious manner and in compliance

with these operating instructions.

2. In addition to the operating manual, please heed general le-

gal and other binding regulations for accident prevention

and environmental protection.

3. Sweeping and picking up of flammable, toxic or explosive

substances, along with flammable gases or diluted acids

and solvents, burning or smouldering objects is prohibited!

4. The appliance is not suitable for picking up fluids, cables,

cords, wires or the like.

5. The machine should only be used with the dust box fitted to

prevent injuries caused by parts being slung out.

6. Transporting loads with the sweeper is not allowed.

7. Faults should be eliminated immediately, particularly those

that could impair safety.

8. Do not make any changes, modifications or additions to the

sweeper without the approval of the manufacturer.

9. Replacement parts must meet manufacturer specifications.

This is always ensured by using original replacement parts.

10. Ensure that operating media, auxiliary media and replace-

ment parts are disposed of in a safe and environmentally-

friendly manner, particularly batteries!

11. Suitable non-slip footwear should be worn to avoid acci-

dents.

12. If you have any questions, please contact our Service de-

partment.

13. Persons (including children) who are not able to use this

machine safely due to their physical, sensory or mental ca-

pabilities or their inexperience or lack of knowledge may not

use this machine without the supervision or instruction by a

responsible person! Children should be supervised to en-

sure that they do not play with the appliance.

14. Caution: loose clothing can be caught and drawn in on rotat-

ing parts.

15. The operating instructions provided by the battery manufac-

turer relating to his product and legal specifications for the

handling of accumulator batteries should be heeded!

4 TF91-TRS

16. Charge flat batteries directly after use and only in well-

ventilated rooms.

17. Keep naked flames and electrical sparks away from the

charging area, since a highly-explosive electrolytic gas mix-

ture is generated when batteries are being charged.

18. Note that the accumulator batteries are filled with battery ac-

id.

19. Batteries should always be kept clean and dry to avoid

leakage currents! Never short-circuit battery poles!

20. Smoking, eating and drinking should be avoided in the vicin-

ity of the battery charging station to avoid risks to health.

21. Batteries should only be charged with the hood opened and

secured with the holder.

2.1 Safety device

The hood switch prevents the machine from getting switched on when

the hood is open and switches off the machine if it is opened during

operation

TF91-TRS 5

3 Sweeper description

3.1 Sweeper description

The suction sweeper is driven by an electric motor.

Sweeping is done with two side brushes which convey the refuse to the

two main brooms that are mounted at 90 degrees to the direction of

motion. The rollers throw the refuse overhead in the rear dirt collector.

The dust that is collected by the main brooms is kept in a lamellar filter

in the machine by the dust extraction.

The lamellar filter can be cleaned by a manually actuated filter vibrator.

handle bar

dustbin

driving lever

hood

operating console

side brushes

filter cleaning lever

dustbin holder

operating lever, left side brush / operating lever, right side

brush

key switches

batter meter

operating lever, main brooms

6 TF91-TRS

3.2 Initial start-up

Ensure that the machine was supplied complete and undamaged.

In case of any objections, contact your specialist dealer or our Service

department.

Open the packaging and carefully lift the machine off the pallet.

Reach under the frame of the machinery to lift it. There is a risk of

injury if you attempt to lift the machinery by the hood, the side

brush retainer, or the dustbin!

Open the hood and fasten it.

Push the handle bar -1- into the receptacles till the cross hoop is at

hip height (ergonomically correct height).

Tighten the handle bar screws -2-.

Set the side brush arms to the top position and mount the side

brushes.

Connect the battery.

Close the hood again.

The sweeper is ready for operation.

CAUTION!
