Top View A100WIRF Series Manuel utilisateur
3MP Ultra Discreet In-Ceiling Industrial
Indoor Network Dome Camera
User Manual
V. 02.11
Mini Dome Series | User Manual
1
Table of Content
1Product Overview 4
1.1 Physical Characteristics 4
2Installation and Connection 6
2.1 Package Content 6
2.2 Installation 6
2.2.1 Checking Appearance 6
2.2.2 Connecting the power wire 6
2.2.3 Disassembling the Camera 7
2.2.4 Installing the Camera 9
2.2.5 Network Topology 11
2.2.6 System Requirements 11
2.3 Connection 12
2.3.1 Default IP address 12
2.3.2 Connecting from a computer & Viewing Preparation 12
2.4 IP Finder 16
3Administration and Configuration 17
3.1 Live View 17
3.2 Configuration 19
3.2.1 Information 19
3.2.2 Image Parameter 19
3.2.3 Network Settings 28
3.2.4 Account Management 32
3.2.5 Event Settings 33
3.2.6Record Settings 36
3.2.7 System Settings 37
3.2.8 Event Log 40
Appendix A: Specification of A301MIF Series 41
Mini Dome Series | User Manual
2
WARNING
This unit operates with PoE (IEEE 802.3af Class 0) as power supply only.
Installation and service should be performed only by qualified and experienced technicians and comply
with all local codes and rules to maintain your warranty.
To reduce the risk of fire or electric shock, do not expose the product to rain or moisture.
Wipe the camera with a dry soft cloth. For tough stains, slightly apply with diluted neutral detergent and
wipe with a dry soft cloth.
Donotapplybenzene orthinnertothecamera,whichmaycausethesurfaceof unitto bemeltedorlensfogged.
Avoid aligning the lens to very bright objects (example, light fixtures) for long periods of time.
Avoid operating or storing the unit in the following locations:
Extremely humid, dusty, or hot/cold environments (recommended operating temperature: -10°C to +50°C)
Close to sources of powerful radio or TV transmitters
Close to fluorescent lamps or objects with reflections
Under unstable or flickering light sources
Get Started
This user manual is designed as a reference for the installation and manipulations of the unit including the
camera’s features, functions, and detailed explanation of the menu tree. Please read this manual thoroughly
and save it for future use before attempting to connect or operate the unit. The reader is supposed to be able
to get the following information in this manual.
Product Overview: the main functions and system requirements of the unit.
Installation and Connection: instructions on unit installation and wire connections.
Administration and Configuration: the main menu navigation and controls explanations.
WEEE (Waste Electrical and Electronic Equipment). Correct disposal of this product
(applicable in the European Union and other European countries with separate collection
systems). This product should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
Mini Dome Series | User Manual
3
FCC Compliance Statement
Information to the user: This unit has been tested and found to comply with the limits for a Class
B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation. These
limits are designed to provide reasonable protection against harmful interference in a residential installation.
This unit generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the manual, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this unit does cause harmful interference to radio or television reception, which can be determined by
turning the unit off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the unit and receiver.
Connect the unit to an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the unit.
CE Statement
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation. The manufacturer declares that the unit supplied with this
guide is compliant with the essential protection requirements of EMC directive and General Product Safety
Directive GPSD conforming to requirements of standards EN55022 for emission, EN 55024 for immunity, EN
300 and EN 328 for WIFI.
Mini Dome Series | User Manual
4
1Product Overview
1.1 Physical Characteristics
Figure 1 - 1: Dimension & Pictorial Index
Unit: ㎜
Mini Dome Series | User Manual
5
Table 1 - 1: Pictorial Index Definition
Index #
Name
1
Bracket
2
Unit Body
3
Dome Case
Figure 1 - 2: Rear Panel
Table 1 - 2: Network LED and Button Definition
RJ-45 Ethernet
Connector/PoE
To insert the RJ-45 cable for network
connection along with PoE (Power over
Ethernet) capability
Ethernet
Link LED
Solid green light stands
for a live connection is
established
Ethernet
Activity
LED
Amber flashing indicates
data is being transmitted
/ received by the unit
DEFAULT
Using a paperclip or thin object to reset
all settings of unit to the factory default
by pressing for 5 seconds.
RESET
Using a paperclip or thin object to
reboot the unit.
Mini Dome Series | User Manual
6
2Installation and Connection
2.1 Package Content
Check everything in the packing box matches to the order form and the packing slip. In addition to this manual,
items below are included in the packing box.
One set of mini indoor dome camera
One CD containing the IP Finder, user manual, and quick installation guide
One printed quick installation guide
One mounting template
Please contact your dealer if any item missing.
2.2 Installation
Following tools might help you complete the installation:
a drill
screwdrivers
wire cutters
2.2.1 Checking Appearance
When first unboxing, please check whether if there is any visible damage to appearance of the unit and its
accessories. The protective materials used for the packaging should be able to protect the unit from most of
accidents during transportation. Please remove the protective materials of the unit when every item is
checked in accordance with the list in “2.1 Package Content”
2.2.2 Connecting the power wire
PoE (IEEE 802.3af Class 0): Connect the RJ-45 jack to a PoE compatible network device that supplied
power through the Ethernet cable.
Mini Dome Series | User Manual
7
2.2.3 Disassembling the Camera
Step 1: Loosen the screws on the dome case
1. Use a screwdriver to counterclockwise loosen the screw on the dome case.
Figure 2 - 1: Disassembling the Camera 1/4
Step 2: Remove the dome case
1. After the screw was loosened, gently remove the dome case from the unit.
Figure 2 - 2: Disassembling the Camera 2/4
Mini Dome Series | User Manual
8
Step 3: Remove the unit body while retaining bracket on ceiling
1. Pull the 3 fasteners on the bracket apart to take out the unit body. (Two of three fasteners are thinner,
which are the 1st priority to pulling apart before the rest thicker one.)
2. Take off the unit body while the bracket is still attached to the ceiling.
Figure 2 - 3: Disassembling the Camera 3/4
Step 4：Detach network cable and finish disassembling.
1. Simply take the network cable out from the unit body to complete the disassembling process.
Figure 2 - 4: Disassembling the Camera 4/4
Mini Dome Series | User Manual
9
2.2.4 Installing the Camera
Step 1:
1. Use the mounting template to mark out and prepare a mounting area on ceiling.
2. Drill a round hole with Ø 84mm in diameter based on the mounting template on ceiling.
3. Put network cable through the drilled hole on ceiling, and attach the cable to the unit body with bracket.
4. Put unit body with bracket into the round hole on ceiling. (Please hold it securely since it’s not fixed yet.)
Figure 2 - 5: Installing the Camera 1/5
Step 2:
1. Use a screwdriver to turn the three screws of the bracket clockwise so that you can expand locking arms.
2. Tighten the screws sufficiently to compress the locking arms and thus stably fix the unit to the mounting
surface.
Figure 2 - 6: Installing the Camera 2/5
