TOP VEHICLE TECH GRKFD04 Manuel utilisateur

www.topvehicletech.com

The informaon provided in this document is subject to change without noce due to changes and/or

improvements to the product/s.

V2.0522

GRKFD04

FORD TRANSIT



2015-2021

INSTALLATION MANUAL

This dash image is a visual representaon for display purposes only.

www.topvehicletech.com

ABOUT THIS PRODUCT

The GRKFD04 installaon kit allows for the retenon of the vehicle’s steering wheel controls and helps maintain

the original aesthec of the interior when installing a new car stereo. The GRKFD04 gives you everything you

need for a complete install in one box. The components of this kit are compable for the Ford Transit (V363,

2015-2021) with factory stereos. The wiring harness and interface will retain the steering wheel controls, factory

phone buons and parking sensor audio (if vehicle is equipped). The interface supplied features a Ford OEM

specic connector.









Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any

problems during the installaon of this product, then please contact our dedicated customer service team at:

Phone:  E-Mail: 



• 1x Fascia plate (with accessories)

• 1x Instrucon manual

• 1x Steering wheel control harness and interface

• 1x Antenna adapter

• 1x Stereo patch lead

www.topvehicletech.com



1. Use a panel removal tool to lever o the top dash cover which is held in place by x12 locator clips.





1. Once the main fascia panel is o, remove both torx screws that hold the air vents in place. These will

then need to be relocated onto the new fascia. Use 2x of the screws within the kit to aach the fans to the

new fascia.

2. Take either the newly ordered or pre-exisng hazard & airbag light and insert them into the fascia in the

applicable port. If the vehicle does not have a airbag light, we have included a blanking plate in the kit.

2. Remove the 2x torx screws found at the top of the main fascia, and using a panel removal tool, pry away

the enre panel, disconnecng the hazard switch connector in the process.

3. Remove the 2x screws that hold the main radio in place and remove it from the dashboard, again,

disconnecng all the wiring in the process.



Some plascs will need to be cut and removed from the dashboard to make space for the new car stereo.

Measure where the stereo will sit and take due care when modifying the vehicle. TopVehicleTech always promote the

help of professional installers. TopVehicleTech will not be held responsible for any damage to the vehicle.

3. Aach the 12x metal clips within the kit onto the new dash panel. These clips have a specic locaon as

shown below:

www.topvehicletech.com



4. When all the above wires (and any addional accessories) have been connected, nally make the power

connecons between the stereo and the vehicles pre-exisng connector.

1. Take the steering wheel control interface and aach the 14-way steering wheel harness connector to

the relevant side.



3. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.

5. Aach the brackets to either side of the radio using the 4x screws within the kit. Once aached, roughly

test t the radio and bracket combinaon in relaon to the new fascia, doing this, you can best measure

whether the brackets need moving forwards/backwards.

6. Aer the “Stereo Installaon” process is complete and you are re-assembling the vehicle, simply place

the new fascia over top the radio and ulising the plasc clips, secure it rmly to the dashboard.

4. Once all of the metal clips have been seen to, proceed to aach the remaining 4x plasc clips to long

locator posts on the back of the new fascia.

 CONT’D

2. Make a cut within the orange and purple loops on the back of the patch lead connector. Then proceed

to aach ‘Key 1’ to the light blue ‘SWC Remote’ wire on the stereo. When done, connect the 12-way

connector to the steering wheel control interface.

www.topvehicletech.com

Please note: conguraon layout may dier dependent on vehicle model.



1. Volume +

2. Volume -

3. Track -

4. Track +

1. Volume +

2. Volume -

3. Track -

4. Track +

 

www.topvehicletech.com



ISO Connector

Connect to new stereo

Vehicle Speciﬁc Connector [OEM Speciﬁc]

Connect to OEM connector from vehicle

Main Wiring Loom Connector [14 Pin]

Connect to Interface Box

Interface Box

Stereo Connection (Patch)

Lead Connector [12 Pin]

Connect to Interface Box

Note: Must be connected

ﬁrst, before power

connection is made to the

interface

www.topvehicletech.com



www.topvehicletech.com

If at any point you experience any problems and need any assistance before, during or aer the

installaon process, please contact us via :

Phone: 

E-Mail: 

Mon - Fri 9am - 5.30pm GMT



If you would like to download a digital copy of this manual, or any other product, then please

visit the www.topvehicletech.com website.

This manual is considered correct at the me of prinng but is subject to change. For the latest

manuals & updates, refer to our website.

in any form or by any means, including photocopying, recording, copying or other electronic or

mechanical methods, without the prior wrien permission of the author.
