USE AND CARE GUIDE

MODELS TMFS1W/TMFS2B

TMFS1W/TMFS2B

Food Slicer

Questions

Call toll free 1-800-947-3744

Monday–Friday, 8:00 a.m.-5:30 p.m. CST

www.toastmaster.com

•Foldable Plastic Housing For Easy Storage

•Removable 6 1/2 inch Stainless Steel Blade

•Thick-to-Thin Adjustable Slicing

•Food Collection Tray

•Interlock Safety Switch

•Feeder and Food Press

TMFS1W&TMFS2B_IB__Cover_26-8-03 26/8/03 2:58 PM Page 1

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed including the following:

◆Read all instructions.

◆To protect against electrical shock do not put cord, plugs, or

appliance in water or other liquid.

◆Close supervision is necessary when any appliance is used by or

near children.

◆Unplug from outlet when not in use, before putting on or taking

off parts, and before cleaning.

◆Avoid contacting moving parts. Never feed food by hand. Always

use completely assembled slicer with Food Press and Feeder.

◆Blade is sharp. Handle carefully when cleaning.

◆Do not operate any appliance with a damaged cord or plug or

after the appliance malfunctions or is dropped or damaged in any

manner. Contact Consumer Service for examination, repair or

electrical or mechanical adjustment.

◆The use of attachments not recommended or sold by the

manufacturer may cause fire, electric shock or injury.

◆Do not use outdoors.

◆Do not let cord hang over edge of table or counter.

◆Do not let cord contact hot surface, including the stove.

SAVE THESE INSTRUCTIONS

For Household Use Only

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 1

ADDITIONAL IMPORTANT

SAFEGUARDS

◆All users of this appliance must read and understand this Use and

Care Guide before operating or cleaning this appliance.

◆The cord to this appliance should be plugged into a 120V AC

electrical outlet only.

◆Do not leave this appliance unattended during use.

◆If this appliance begins to malfunction during use, immediately

release the "Pulse" Button and Safety Lock and unplug the cord. Do

not use or attempt to repair the malfunctioning appliance.

◆If this appliance falls or accidentally becomes immersed in water,

unplug it immediately. Do not reach into the water! Do not use this

appliance after it has fallen into or becomes immersed in water.

◆To reduce the risk of injury to persons or property, never use this

appliance in an unstable position.

◆Do not use this appliance for other than its intended use.

◆The Safety Lock Button prevents accidental operation of the Food

Slicer by pressing the Pulse Button. Do not attempt to defeat this

safety feature.

◆Unplug the appliance from the wall outlet when not in use, before

putting on or taking off parts and before cleaning. Be careful, the

blade continues to turn for a while even after the Safety Lock and

Pulse buttons are released.

◆Do not operate the appliance continuously for more than

10 minutes. Allow the appliance to cool down for one hour before

second operation.

◆Do not use appliance to cut deep frozen food, bones or jellylike or

wet food.

◆Operate the appliance only when the Blade-Locking Knob is

properly engaged and tightened.

◆Handle the Blade carefully when cleaning, removing and inserting,

as the Blade is extremely sharp. Do not touch the sharp edge of

the Blade. Do not use or install the Blade in anyway other than

recommended in this manual.

2. Food Slicer Use and Care Guide

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 2

ADDITIONAL IMPORTANT

SAFEGUARDS (cont.)

◆Do not touch sharp surfaces. To avoid danger of injury, always cut

food with Feeder and Food Press in place. The Food Press should

always be used, unless the size and shape of the food prohibits its

use. The Protective Rail requires the Feeder to be used in all

slicing situations. Do not attempt to defeat this safety feature.

◆Always set the Thickness Adjustment Knob to minimum thickness

position and lock the Slicer after each use, before and after cleaning.

◆Operate this appliance on a flat, level surface only.

Plug

This appliance has a polarized plug (one blade is wider than the

other). To reduce the risk of electrical shock, this plug is intended to

fit into a polarized outlet only one way. If the plug does not fit fully in

the outlet, reverse the plug. If it still does not fit, contact a qualified

electrician. Do not attempt to modify the plug in any way.

Short Cord Instructions

A short power-supply cord is provided to reduce the risk resulting

from becoming entangled in or tripping over a longer cord.

Do not use an extension cord with this product.

Electric Power

If the electrical circuit is overloaded with other appliances, your

appliance may not operate properly. It should be operated on a

separate electrical circuit from other appliances.

Plasticizer Warning

CAUTION: To prevent Plasticizers from migrating from the finish of

the countertop or tabletop or other furniture, place NON-PLASTIC

coasters or placemats between the appliance and the finish of the

countertop or tabletop.

Failure to do so may cause the finish to darken, permanent blemishes

may occur or stains can appear.

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 3

Food Slicer Use and Care Guide

Getting To Know Your Toastmaster

Food Slicer

Your product may vary slightly from illustration.

10.

11.

13.

12.

7. 6.

1. Adjustment Plate

(P/N 71052W), (P/N 71052B)

2. Pulse Switch (I=On, O=Off)

3. Safety Lock

4. Blade-Locking Knob

(P/N 71053)

5. Blade - Stainless Steel

(P/N 71054)

6. Feeder

(P/N 71055W), (P/N 71055B)

7. Food Press

(P/N 71056W), (P/N 71056B)

8. Thickness Adjustment Knob

9. Food Tray

(P/N 71057W), (P/N 71057B)

10. Power Cord

11. Base

12. Base Platform Locks

13. Foldable Base Platform

FIGURE 1

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 4

Before Using Your Food Slicer

CAUTION: Blade is sharp. Handle carefully. Do not wash in dish-

washer. Do not immerse cord, plug or appliance in water or any other

liquid. Do not remove the lubricant on the gears.

1. Remove any packaging

materials.

2. Adjust the Thickness

Adjustment Knob to

minimum thickness

setting “O”.

3. Always make sure the unit

is unplugged and the Blade

has come to a complete

stop before cleaning or

removings parts.

4. Remove the Food Press, Feeder,

(see Figure 2 for disassembly and

assembly) and Food Tray and wash in

warm, soapy water. Rinse and dry

thoroughly.

5. Remove the Blade by inserting a coin in

the slot of the Blade-Locking Knob and

turning clockwise. Remove the Blade-

Locking Knob. See Figure 3. With one

hand on the back side of the Blade,

gently push the Blade forward and at

the same time, grip the hole in the

center of the Blade from the front and

lift off. The Blade is very sharp, use

extreme care when handling. DO NOT

touch sharp edge of Blade.

6. Wipe all surfaces with a damp cloth. Dry thoroughly. Keep the Pulse

Switch and Safety Lock dry.

7. Wash the Blade, in warm, soapy water. Rinse and dry thoroughly. Do

not allow the Blade to soak in water. Trying to locate the Blade under

water is potentially dangerous.

FIGURE 2

FIGURE 3

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 5

6. Food Slicer Use and Care Guide

Before Using your Food Slicer (cont.)

8. We suggest that you wash, rinse, dry and reinstall the Blade

immediately. Re-assemble the Blade in reverse order of Step 5.

NOTE: Turn Blade-Locking Knob counter clockwise.

Make sure the Blade-Locking Knob is properly engaged and

tightened.

9. Do not remove the White lubricant on the gears. The lubricant is

used to reduce the friction and noise of the gears.

CAUTION: BLADE IS SHARP.

UNPLUG UNIT BEFORE CLEANING.

NEVER USE SLICER UNLESS

COMPLETELY ASSEMBLED.

Operating The Food Slicer

CAUTION: Blade is sharp. Handle carefully.

1. Place the Food Slicer on a hard, flat and level work surface. Slide

the Base Platform Locks (on both sides of base) to unlock

positions and lower the Foldable Base Platform.

2. Slide the Base Platform Locks to the locked position to ensure

Foldable Base Platform is locked into place.

3. Plug the Food Slicer into a 120V AC, 60Hz, outlet.

4. Position the Food Tray on the countertop, under the Blade, to the

left of the Slicer.

5. Set the desired cutting thickness by

turning the Thickness Adjustment Knob.

Turning the Knob clockwise will increase

the thickness of the slice.

6. Before you begin slicing, ensure that the

Blade is installed correctly and not

touching anything.

7. Put the Food and the Food Press on the

Feeder and place them on the Base

Platform. Make sure the guide, located on

the bottom of the Feeder, fits into the groove on the

Base Platform (See Figure 4). The Feeder should slide smoothly on

the Base Platform. See Figure 5.

FIGURE 4

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 6

Operating The Food Slicer (cont.)

8. To start operating the appliance,

first push the Safety Lock Button

then without releasing the Safety

Lock Button, press down on the

Pulse Button from position “O” to

“I”. KEEP HANDS AWAY FROM

BLADE! See Figure 6.

9. To stop the appliance, release the

Pulse Button. The Pulse Switch

Button will spring up to the "O"

position automatically. Then release the Safety

Lock Button, the Blade will stop in seconds.

10. Push the food with the Food Press. Move the Feeder steadily back

and forth, pressing food gently with the Food Press against the

Adjustment Plate for even slices. See Figure 4. To avoid injury,

always cut the food with Feeder and

Food Press. In case the food shape

or size does not allow for the use of

the Food Press, it can be removed.

However, extra care should be taken

during cutting. Once the food is

reduced in size, use the Food Press

to continue slicing the remainder of

the food.

11. Do not use the slicer to cut deep

frozen food or bones. The slicer may

become overloaded and damage the Blade.

12. Do not use the slicer to cut jellylike or wet food. The jelly or the

excessive juice may spread into the electrical components of the

motor assembly. It may lead to fire and electric shock, personal

injury or death.

FIGURE 6

FIGURE 5

Pulse

Switch

Safety

Switch

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 7

8. Food Slicer Use and Care Guide

User Maintenance Instructions

This Toastmaster®Food Slicer requires little maintenance. It contains

no user-serviceable parts. Contact qualified appliance repair

technician if the product requires servicing.

CAUTION: Blade is sharp. Handle carefully. Do not wash in dish-

washer. Do not immerse cord, plug or appliance in water or any other

liquid. Do not remove the lubricant on the gears.

CLEANING

To keep your Food Slicer operating properly, clean after each use.

1. Always unplug the appliance and let the Blade come to a

complete stop before cleaning.

2. Adjust the Thickness Adjustment Knob to the minimum thickness

setting “O” before cleaning.

3. Remove the Food Press, Feeder, and Food Tray and wash in

warm, soapy water. Rinse and dry thoroughly.

4. Remove the Blade by inserting a coin in the slot of the Blade-Locking

Knob and turning clockwise. Remove the Blade-Locking Knob. With

one hand on the back side of the Blade, gently push the Blade

forward and at the same time, grip the hole in the center of the

Blade from the front and lift off. The Blade is very sharp, use extreme

care when handling. DO NOT touch sharp edges.

5. Remove the Adjustable Plate by turning the Thickness Adjustment

Knob counter clockwise until it is released.

6. Wipe all surfaces with a damp cloth making sure to thoroughly

clean between the Base and Foldable Base Platform. Dry

completely with a soft cloth. DO NOT use harsh or abrasive

cleansers or sharp metal objects to remove food as these could

damage the coating on the exterior surface.

7. Wash the Blade and Adjustable Plate in warm, soapy water. Rinse

and dry thoroughly. Do not allow the Blade to soak in water.

Trying to locate the Blade under water is potentially dangerous.

8. Reattach the Adjustment Plate in reverse order of step 5.

9. We suggest that you wash, rinse, dry and reinstall the Blade

immediately. Reinstall the Blade in reverse order of Step 4 (See

figure 7). Make sure the Blade-Locking Knob is properly engaged

and tightened. Fold the Base Platform up and slide the Base

Platform Locks to the lock positions.

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 8

User Maintenance Instructions (cont.)

10. Do not remove the White lubricant on

the gears and Motor Assembly. The

lubricant is used to reduce the friction

and noise of the gears. Removal of the

lubricant will reduce the cutting

performance and increase the operating

noise. If the lubricant has been removed,

a thin film of margarine or food-grade

lubricant may be applied. Never apply

industrial-use or automotive-use

lubricants as they may not be safe for

consumption and may damage the gears.

11. Any servicing requiring disassembly other than the above cleaning

must be performed by a qualified appliance repair technician.

Helpful Hints

The Food Slicer can be used to cut meat, cheese, vegetables or bread.

1. Roasts: Beef, pork, poultry and lamb -- Allow roasts to stand for

20 minutes after removing from the oven before slicing.

2. Bulk Bacon: With a sharp knife, remove the rind from

"thoroughly chilled" bacon. Trim bacon to fit securely on Feeder,

fat side down.

3. Cheese and cold cuts: Slice as needed to retain flavor. Remove

the plastic or hard casing from "well chilled" food before slicing.

Use gentle pressure for uniform slices.

4. When you are going to slice very thin food, unplug the unit and

moisten the Blade with a damp cloth; this helps to prevent

sticking. If cheese builds up on the Blade or under the Blade

Cover, unplug the slicer and wipe the Blade clean with a damp

cloth.

5. When slicing food that is not uniform in size, always slice with the

largest side first.

6. Vegetables and fruits: Slice potatoes, tomatoes, carrots,

cucumbers, cabbage, lettuce, eggplant, squash and zucchini in a

matter of minutes.

7. Breads: Do not use excessive pressure or squeeze the loaf. Trim

or cut bread to fit comfortably on the Feeder. Move the loaf of

bread smoothly through the blade with continuous "gentle"

pressure on the loaf.

FIGURE 7

TMFS1W&TMFS2B_IB_26-8-03 26/8/03 2:56 PM Page 9

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Toastmaster Appareils de cuisine

Toastmaster

Toastmaster PMA-18 Manuel utilisateur

Toastmaster

Toastmaster TPC2 Manuel utilisateur

Toastmaster

Toastmaster TMFS2B Manuel utilisateur

Toastmaster

Toastmaster TSG-1 Manuel utilisateur

Toastmaster

Toastmaster 1740 Manuel utilisateur

Toastmaster

Toastmaster Snackster TSM2032T Guide rapide

Toastmaster

Toastmaster Snackster TSM2SAN Guide rapide

Toastmaster

Toastmaster TSM2SANCAN Guide rapide

Toastmaster

Toastmaster Snackster 288 Guide rapide

Toastmaster

Toastmaster 6122S Manuel utilisateur

Toastmaster

Toastmaster TPC3 Manuel utilisateur

Toastmaster

Toastmaster 6202 Manuel utilisateur

Toastmaster

Toastmaster TMPC4 Manuel utilisateur

Toastmaster

Toastmaster tm-11sk Manuel utilisateur

Toastmaster

Toastmaster TMCKM2SIM Manuel utilisateur

Toastmaster

Toastmaster TMDC24 Manuel du propriétaire

Toastmaster

Toastmaster 6128 Manuel utilisateur

Toastmaster

Toastmaster TSG-2 Manuel utilisateur

Toastmaster

Toastmaster TMCKM2S Manuel utilisateur

Toastmaster

Toastmaster TES1 Manuel utilisateur

Toastmaster

Toastmaster TWB2PIZ Manuel utilisateur

Toastmaster

Toastmaster TES1CAN Manuel utilisateur

Toastmaster

Toastmaster 1739 Manuel utilisateur

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
