Toa SM-75 Manuel utilisateur

TOA SPEAKER SYSTEM

2-WAY SPEAKER SYSTEM

SM-75

GENERAL DESCRIPTION

The TOA SM-75 is a compact, two-way speaker system two full-range, cone-type speakers (5"/12cm) and a horn

designed for professional applications requiring

tweeter (1.85"/4.7cm) for clarity and efficiency, while

personal, on-stage monitoring. The SM-75 easily the enclosure itself is cast aluminum for durability. An

handles 200 watts of continuous program material at an

adjustable bracket is included for mounting the SM-75

impedance of 8 ohms, and features a variable attenuator

on mic stands up to 1.10" in diameter, or on walls in

to adjust volume. The infinite baffle design incorporates permanent installations.

SPECIFICATIONS

Enclosure:

Speakers:

Sealed type

Two 5-inch (12cm) full-range

cone speakers

One 1.85-inch (4.7cm) horn

tweeter

Frequency

Response

Attenuation

Material

(Finish):

110 Hz~20 kHz

0 dB to 40 dB or more

Front GriII...Perforated metal

(Black)

Body. . . . . . .

Cast aluminum

(Black)

Two locking 1/4" phone jacks

12.8(W)X6.7(H)X5.5(D) inches

325(W)X170(H)X140(D)mm

Approx. 10.6 pounds (4.8 kg)

Power Handling

Continuous

pink noise:

70 watts of band limited pink

noise (50 Hz to 20 kHz)

Connectors:

Dimensions:

Continuous

program:

Impedance:

Sensitivity:

200 watts

8 ohms

90 dB (1W/1m)

Weight:

included for mounting the speaker on mic

stands up to 1.10" in diameter, or on walls in

permanent installations. The speaker system

shall meet the following criteria: Sensitivity:

90dB at 1 meter with 1 watt. Frequency

response: 110Hz~20kHz. Attenuation: 0dB to

40dB or more. Front grill: Perforated metal.

Body: Cast aluminum. Connectors: Two locking

type 1/4" phone jacks. Dimensions: 12.8"(W)X

6.7"(H)X5.5"(D). Weight: approx. 10.6 pounds

The speaker system shall be designated the

TOA Model SM-75.

ARCHITECT’S AND

ENGINEER’S

SPECIFICATIONS

The speaker system shall be a compact, two-

way speaker system designed for professional

applications requiring personal, on-stage

monitoring. It shall easily handle 200 watts of

continuous program material at an impedance

of 8 ohms, and shall feature a variable

attenuator to adjust volume. The infinite baffle

design shall incorporate two full-range, cone-

type speakers (5"/12cm) and a horn tweeter

(1.85"/4.7cm) for clarity and efficiency, while

the enclosure itself shall be cast aluminum for

durability. An adjustable bracket shall be

CHARACTERISTIC DIAGRAMS

(PINK NOISE)

Polar Response

(1m)

Vertical

Horizontal

Dispersion

500Hz

1kHz

2k Hz

4k Hz

Scale is 10dB per division 4k Hz Scale is 10dB per division

Frequency Response (1W/1m)

Directional Frequency Response

(1W/1m)

---- 45”

I

90

70

100

90

70

a

60

20 50

100

200 500

1000

2000 5000 10000 20000

Frequency (Hz) Frequency (Hz)

TOA Corporation

Printed in Japan (306)833-64-509-0B
