Toa 30-SDM Manuel utilisateur

PROFESSIONAL SOUND SYSTEM

Speaker System

Model 38-SDM, 30-SDM

General Description

The 38-SDM and 30-SDM are compact, roadworthy 3-way

stage monitor speaker systems with Thiele-Small aligned bass

reflex enclosures which house one 15" (38-SDM) loudspeaker

one 12" (30-SDM) loudspeaker and a small-sized radial horn

coupled with high efficient compression driver and two

(38-SDM) or one (30-SDM) high performance tweeter They

are designed to be used as full range systems or with the use

of the additional in/out 1/4" phone jacks can be bi-amplified.

They offer extended frequency response, exceptionally high

power capacity (120W continuous pink noise) and high effi-

ciency TOA's unique front-slotted design functions as an

acoustic low pass filter obtaining a smooth crossover be-

tween low and high frequencies and ensuring flat response.

The enclosure's have side-mounted handles for ease in carry-

ing and set up, and metal grills to protect loudspeakers.

Features

1. Extended frequency response

2. High power capacity of 120 watts continuous pink noise

(Test duration: 24 hours)

3. Slotted design that functions as an acoustic low pass filter

4. Side-mounted handles for ease in carrying

5. Input jacks for bi-amplification

38-SDM 30-SDM

Specifications

MODEL NUMBER

Enclosure

Speaker

Handling Power Capacity

Continuous Pink Noise

Continuous Program

Impedance

Sensitivity

Frequency Response

Crossover Frequencies

Middle Frequency

Level Control

Finish (Enclosure)

Dimensions

Weight

38-SDM 30-SDM

Vented (bass reflex) type

15" (38cm) woofer Radial horn and

compression driver Two 3" tweeters 12" (30cm) woofer Radial horn and

compression driver 3" tweeter

120 watts of band-limited pink noise [50Hz~20kHz]

360 watts 8 ohms

102dB (1W/1m)

50Hz~20kHz

100dB (1W/1m)

60Hz~20kHz

1kHz, 10kHz

0- -10dB (with an "OFF" position)

Polyester pa

520(H)x500(W)x660(D) mm

20.5(H)x19.7(W)x26.0(D) inches

24kg (52.9 Ibs)

int, Color: Gray

475(H)x430(W)x600(D)mm

18,7(H)x16.9(W)x23.6(D) inches

20kg (44.1 Ibs)

* Specifications are subject to change without notice.

Input Panel

FULL RANGE INPUT

Connects to the output of power amplifier. This is

the input jack when used as a full range speaker.

BI-AMP INPUT (HIGH)

Connects to the amplifier for high frequency when

driving the speaker system with bi-amplification.

BI-AMP INPUT (LOW)

Connects to the amplifier for low frequency when

driving the speaker system with bi-amplification.

MID-FREQUENCY ATTENUATOR

Adjusts the sound level of the mid-frequency when

driving the speaker system as a full range speaker

system. Make the level setting according to the

environmental conditions, although almost flat

frequency response is obtainable so far as the

attenuator remains within the "NORMAL" range.

FULL RANGE OUTPUT

Make bridge connection of this output to the full

range input of another speaker system when driving

two speaker systems with one power amplifier.

BI-AMP OUTPUT (HIGH)

For bridge connection in high frequency to another

speaker.

BI-AMP OUTPUT (LOW)

For bridge connection in low frequency to another

speaker.

CAUTION:

DO NOT USE THE BI-AMP JACKS UNLESS THE

SPEAKER SYSTEM IS DRIVEN UNDER

MULTI-AMPLIFIERED SYSTEM. CONNECTING

THE FULL RANGE OUTPUT TO THE BI-AMP

INPUT JACK MAY DAMAGE THE SPEAKER.

Frequency Response (1W/1m: Pink Noise)

38-SDM 30-SDM

— : Attenuator at NORMAL position.

---

: Attenuator at MAX. position.

133-01-173-30
