Toa 9000M2 Series Manuel utilisateur
9000M2 Series
Quick Start Guide
- Multi Zone Paging-
Office / School Using Scene Changes
1/30
System Overview
9000M2 Series Mixer Amplifier and audio devices are installed in a Security office. There are
eight speaker zones (Hall, Cafeteria, Conference room, Security office, Parking, Yard).
When the emergency situation happens, evacuation announcements are generated by using a
microphone. Remote controllers on the wall can select which areas receive the page. Paging
through telephone PBX to selected areas is also available. When the emergency
announcement inputs to the 9000M2, a contact can be triggered from the 9000M2 to activate
Emergency Lights.
System Components
1．A-9120DHM2 x 1
2．ZM-9013 x 1
3．ZM-9014 x 1
4．D-001T x 1
5．T-001T x 3
6．ZP-001 x 1
7．S-20S x 1
8．T-001T x 3
9．RC-001T x 1（with AD-246）
10．PM-660U x 1
11．Phone
12．P-9120DH
13．DA-500F-HL
14．DA-250DH
15．PC-671R
16．PE-304
17．HX-5B
18．F-1000BT
19．SC-615T
Setting
Input 1 (D-001T): PM-660U
2/30
Input 2 (ZP-001T): PBX
Input 3 (S-20S): Emergency Announcements
Output 1 (A-9120DHM2): Hall A
Output 2 (A-9120DHM2): Hall B
Output 3 (P-9120DH): Hall C
Output 4 (P-9120DH): Hall D
Output 5 (DA-500F-HL): Cafeteria
Output 6 (DA-500F-HL): Auditorium/Conference Room
Output 7 (DA-250DH): Security Office
Output 8 (DA-250DH): Parking Lot/ School Yard
Remote out (RC-001T): ZM-9013 [0] >> ZM-9014 [1]
Button Configuration
ZM-9013
Button 1: Paging 1 route to speaker output 1.
Button 2: Paging 1 route to speaker output 2.
Button 3: Paging 1 route to speaker output 3.
Button 4: Paging 1 route to speaker output 4.
Button 5: Paging 1 route to speaker output 5.
Button 6: Paging 1 route to speaker output 6.
Button 7: Paging 1 route to speaker output 7.
Button 8: Paging 1 route to speaker output 8.
ZM-9014
Button 1: Paging 1 route to speaker output 1-8.
Button 2: Contact output 1 (Alarm Activate)
Button 3: Contact output 2 (Message Activate)
Button 4: Contact output 3 (Emergency Lights)
Volume: Paging Master Volume
3/30
Configuration
4/30
1. The following is the initial setting wizard screen.
2. Click “ New File” on the Start Menu window.
5/30
3. Set module configurations.
4. Select the modules to be inserted into the amplifier’s slots from the pull-down menu in the
Module field.
6/30
5. Select a module for each slot. At the same time, name each channel (ex. “MIC1”).
Main Frame Name 1 >> “HALL-A” Name 2 >> “HALL-B”
Slot #1 >> D-001 Name 1 >> ”PAGING1” Name 2 >> ”-”
Slot #2 >> ZP-001 Name 1 >> ”PBX”
Slot #3 >> 900 Module Name 1 >> ”S-20S”
Slot#4>>NONE
Slot #5 >> T-001 Name 1 >> ”HALL-C” Name 2 >> ”Hall-D”
Slot #6 >> T-001 Name 1 >> ”CAFE” Name 2 >>”ROOM”
Slot #7 >> T-001 Name 1 >> ”OFFICE” Name 2 >> ”SCHOOL”
Slot#8>>RC-001
6. Click the “NEXT” button when finished.
7/30
7. The following window is for setting devices connected to REMOTE VOLUME terminal on
9000M2 rear panel. If you do not use ZM-9001, ZM-9002 or ZM-9003, select “NONE” from the
combo box “TYPE”.
8. In this “Multi-zone Paging“ application, select NONE both REMOTE VOL1 and REMOTE
VOL 2
8/30
9. Click “Next” button.
0. Setting for Remote Controller: ZM-9011/9012/9013/9014.
1
9/30
10/30
1. Select how many Remote Controller you use.
In this application, select “2”.
1
12. Select “ZM-9013” from the combo box “MODEL” for 01.
And select “ZM-9014” from the combo box “MODEL” for 02.
If “CROSS POINT CHANGE” function will be assigned to a button of Remote Controller, select
either type of “SOURCE SELECTION MODE”.
EXCLUSIVE MODE: A single cross point can be turned ON for each output channel.
SIMULTANEOUS MODE: Multiple cross points can be arbitrarily turned ON.
Here, check “SIMULTANEOUS MODE”.
10/30
