TM Electron TMHC121 Manuel utilisateur
INSTRUCCION MANUAL
Thanks for choosing to buy our Hair Clipper.
Read all instructions of the manual thoroughly before use, even if you are familiar with
this type of product. The safety precautions enclosed herein reduce the risk of re, electric
shock and injury when correctly adhered to. Keep the manual in a safe place for future
reference. If applicable, pass the instructions on to the next owner of the appliance.
7 EN 1 GROOMING KIT
TMHC121
5
INDEX
Features........................................................................................................6
Important safety instructions.....................................................................7
Usage Instructions ......................................................................................8
7 EN 1 GROOMING KIT
TMHC121
ENGLISH
6
CARACTERÍSTICAS
1. On/off switch
2. Power Indicator light
3. Precision trimmer attachment
4. Full size trimmer attachment
5. Nose trimmer attachment
6. USB charging cable
7. Micro shaver attachment
8. Eyebrow trimmer attachment
9. Cleaning brush
10. Lubricating Oil
11. Long comb
12. Cutting guide comb (3-15mm)
13. Cutting guide comb (0.5-10mm)
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
When using an electric product, basic precautions should always be followed, including
the following:
Read all instructions before using this product.
DANGER
To reduce the risk of electric shock:
· Do not reach for a corded product that has allen into water. Unplug immediately.
· The power cord and the accessories connected to it are not for immersion or for use in shower.
· Do not use an extension cord with this product.
· Do not place or store the product while plugged in where it can fall or be pulled into a tub or
sink. Do not place or drop the product water or other liquid while plugged in.
· Always unplug this product from the electrical outlet immediately after (re)charging.
· Unplug and remove power supply cord from this product before cleaning.
· The batteries used in this product may present a re or chemical burn hazard if mistreated. Do
not disassemble,heat above 100°C (212°F) or incinerate.
WARNING
• To reduce the risk of burns, re, electric shock or injury to persons:
• This appliance is for household use only.
• An appliance should never be left unattended when it’s plugged in, except when charging a
rechargeable appliance.
• Close supervision is necessary when this appliance is used by, on, or near children or persons
with special needs or certain disabilities.
• Use this appliance only for its intended use as described in this manual.
• Keep the cord away from heated surfaces.
• Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or if it has been dropped into water.
• Never drop or insert any object into any of the appliance’s openings.
• Do not use outdoors or operate where aerosol (spray) products are being used,or where oxygen
is being administered.
• Always store this appliance and cord in a moisture-free area. Do not store it in temperatures
exceeding 60°C(140°F)
• Make sure the cord is disconnected from the groomer stand when storing.
• Do not use this appliance with a damaged or broken cutter unit, as injury may occur. Always
make sure blades are aligned properly.
• Do not use an extension cord or a voltage converter with this appliance.
• Do not wrap the cold around the appliance.
• The power unit is intended to be correctly oriented in a vertical or oor mount position.
7
8ENGLISH
• WARNING: For the purposes of recharging the battery, only use the detachable supply unit
provided with this appliance.
• The appliance is only to be used with the power supply unit provided with the appliance.
• This appliance contains batteries that are non-replaceable.
• The battery must be removed from the appliance before it is scrapped
• The appliance must be disconnected from the supply mains when removing the battery
• The battery is to be disposed of safely.
• Only remove the rechargeable battery when you are intending to discard the appliance and you
have the rechargeable battery removed by a professional.
USAGE INSTRUCTIONS
CHARGING YOUR PERSONAL GROOMER
Before using your personal groomer for the rst time, charge for 14-16 hours.
• Make sure the product is switched off.
• Insert the small plug into the product charge connector and put the USB cable to an adaptor
5V 1A in any 100-240V AC outlet.
• During charging, the indicator will be red color ,once full charged around 2 hours, then the
indicator light will be off from red color.
• After charging, remove the adaptor from the wall outlet and pull the small plug out of the
product.
Your appliance cannot be overcharged. However if the product is not going to be used for an
extended period of time (2-3 months), unplug it from the mains and store. Fully recharge your
appliance when you would like to use it again. To preserve battery life, let them run out every 6
months then recharge for 14-16 hours.
BEFORE YOU BEGIN
Always comb your beard or moustache with a ne comb before you start trimming.
ATTACHING AND REMOVING THE GUIDE COMBS
• With the trimmer blade facing away from you. Slide the guide comb on top of the full size trim-
mer attachment and click into position.
• With the trimmer blade facing away from you , carefully push the guide comb away from the
trimmer blade.
NOTICE: Always make sure that the arrow should be alignment before attaching the guide combs
to trimmer attachments . (Fig.1)
9
ENGLISH
(Fig.1)
Table1. Precision Trimmer
Setting Remaining hair lenght (mm)
10,5
21,0
31,5
42,0
52,5
63,0
73,5
84,0
94,5
10 5,0
11 5,5
12 6,0
13 6,5
14 7,0
15 7,5
16 8,0
17 8,5
18 9,0
19 9,5
20 10,0
10 ENGLISH
Table2. Full size trimmer
Setting Remaining hair lenght (mm)
13,0
25,0
37,0
49,0
511,0
613,0
715,0
11
ENGLISH
TRIMMING EDGE OF SIDEBRUNS (Diagram 1. Attachement 4)
• Hold the personal groomer with full size trimmer attachment facing you.
• Start with edge of sideburn, and with the trimmer blades resting lightly against your skin. Use
motions towards edge of sideburn line to trim to desired locations in facial area.
TRIMMING THE NAPE OF YOUR NECK (Diagram 2 - Diagram 3. Attachement 3/4)
Note: You will need a hand mirror for this operation if performing it alone .
• Before you begin, attach the precision trimmer attachment.
• Use your ngers to lift the hair at the base of your head up off the neck. Your index nger should
be covering the roots of the hairs you are lifting to prevent accidental removal by the personal
groomer.
• Using your other hand, hold the personal groomer to the base of your neck with the cutting unit
facing up, and move the personal groomer up the length of the neck until it touches your nger
covering the hair roots at the base of your head.
• Be sure to move the unit slowly when performing this operation and to keep the hair roots at the
base of your head out of the way of the trimmer.
USING THE MINISCREEN SHAVER (Diagram 4. Attachement 7)
• Attach the mini Screen shaver.
• Hold the groomer so the Mini Screen gently touches your face in a 45 degree angle.
• Use short,well-controlled movements to shaver around your beard or moustache.Use your free
hand to scratch your skin. This encourages the hair to stand upright, making it easier to shave.
NOTE: The Mini Screen shaver was designed to shave the detail areas around your beard/mous-
tache/sideburns. It was not designed to shave your entire face. For a close comfortable shave,
guaranteed, use one of electric shavers.
TO REMOVE HAIR FROM NOSE AND EAR (Diagram 5 & 6. Attachement 5 )
• Attach the nose trimmer attachment.
• Insert the personal groomer gently into nostril or ear.
• Gently move the groomer in and out of the nostril or ear and at the same time rotate.
• Avoid inserting the cutting unit more than 6mm into your nostril or ear .
USING THE DETAIL TRIMMER (Diagram 7. Attachement 14)
• Attach the detail trimmer.
• Gently move the groomer to create a variety of shapes you need.
• It also can trim nose and ear trimmer but avoid inserting the cutting unit more than 6mm into
your nostril or ear.
