TLS Electronics 875750 Manuel utilisateur

875750 HDMI 4K Matrix 6x6
User Manual

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 2
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
Use of surge protection systems is highly recommended in order to
protect and extend the life of your equipment.

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 3
Table of Contents
1. Introduction.......................................................................................4
2. Features.............................................................................................4
3. Panel Descriptions.............................................................................5
4. Remote Control Descriptions.............................................................6
5. Application Diagram..........................................................................7
6. Specifications.....................................................................................8
7. Package Contents.................................................................8
8. RS-232 Pin Assignment and Commands.........................................9
9. GUI Control.....................................................................................11
10. Maintenance....................................................................................22
11. Warranty Policy................................................................................22
12. Limitations of Warranty....................................................................22
13. Exclusive Remedies........................................................................23
14. RMA Policy...................................................................................23

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 4
Introduction:
The 875750 HDMI 4K Matrix 6x6 routes six Hi-Def sources to any six
HDTV displays, supporting 1080p Full HD up to 4K plus all 3D formats,
along with multichannel digital audio formats such as Dolby® True HD
and DTS-HD® Master Audio™. Each source can be routed to any display
using the front-panel push buttons, IR remote control, RS-232 interface,
or via TCP/IP.
Features:
•Supports resolutions up to 1080p@60HZ,48-bit deep color, 4k@30HZ
•Allows any source to be displayed on multiple displays at the same
time
•Allows any HDMI display to view any HDMI source at any time
•Dolby TrueHD and DTS-HD master audio pass through HDMI output
•Advanced EDID management for rapid integration of sources and
displays
•Multiple switching mode, push-in button, IR remote control, RS-232
control, and TCP/IP control
•Easy installation with rack-mounting ears
•Full 3D pass through.
•HDCP compliant

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 5
Panel Descriptions
Front Panel
1. HDMI output selection button 1 to 6---Press to select the output from 1
to 6.
2. Source LED indicator---lit when selected by the output
3. IR receiver window----Receive the IR from the remote control of the
Matrix.
Back Panel
1. RJ45 ----TCP/IP control
2. RS232 port----Connect to this port for control from a computer
3. HDMI inputs 1 to 6----Connect HDMI sources
4. HDMI outputs 1 to 6----Output for displays, AVR etc.
5. IR extension receiver input ---- 3.5mm stereo phone-jack
6. Power port---Use included DC adaptor to power the matrix switcher.

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 6
Remote control descriptions
Output and Input select
A. OUTPUT-X select INPUT-Y:
1. Press OUTPUT-X (X means 1 to 8 of outputs)Press INPUT-Y ( Y
means 1 to 8 of inputs )
2. Press OUTPUT-X (X means 1 to 8 of outputs)press the left and
right arrow buttons to select the input.
B. All outputs select INPUT-Y: Press ALL button in zone
OUTPUTPress INPUT-Y button ( Y means 1 to 8 of inputs ), then
INPUT-Y switched to ALL OUTPUTS
C. Mirror all inputs and outputs (Ex. Input 1 to output 1, input 2 to output 2,
etc): Press PTP button in Zone OUTPUT
EDID Set Up

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 7
A. Fixed EDID to INPUT-Y/ALL
Press 1080I/1080P/3D/4KPress 2.0CH/5.1CH/7.1CH
INPUT-Y/ALL button in Zone INPUT
B. Copy EDID of OUTPUT-X to INPUT-Y/ALL
Press COPY buttonPress OUTPUT-X buttonPress INPUT-Y/ALL
button
C. User defined EDID to INPUT-Y/ALL
Press USER1/USER2 buttonPress INPUT-Y/ALL
NOTE: Pressing button sequence should be finished in 5 seconds,
otherwise, operation discarded.
Manual Output and Input select
First Press: OUTPUT select, output button 1 to 6
Second Press: INPUT select, output button 1 to 6
Application Diagram

875750 HDMI 4K Matrix 6x6 User manual
Specifications:
Package Contents:
1. 1x 875750
2. 1x 12V DC power supply
3. 1x Remote control
4. 1x IR Receiver.
5. 1x mounting kit.

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 9
RS-232 Pin Assignment
MT0606-140 Remote Control
Console
PIN Assignment
PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud rate 57600,8,n,1
RS232 and Telnet Commands
No. Command Action
0 ? Print Help Information
1 HELP Print Help Information
2 STATUS Print System Status And Port Status
3 PON Power On, System Run On Normal State
4 POFF Power Off, System Run On Power Save State
5 IR ON/OFF Set System IR Control On Or Off (Only for IR Extension)
6 KEY ON/OFF Set System KEY Control On Or Off
7 DBG ON/OFF Set Debug Mode On Or Off
8 BEEP ON/OFF Set Onboard Beep On Or Off
9 LCD ON/OFF Set LCD Always On Or Auto Turn Off When Power On
10 RESET Reset System To Default Setting,
Should Type ‘Yes’ To Confirm, ‘No’ To Discard
11 OUT xx ON/OFF Set OUTPUT:xx On Or Off

875750 HDMI 4K Matrix 6x6 User manual
TLS electronics GmbH Contact: in[email protected] 10
12 OUT xx FR yy Set OUTPUT:xx From INPUT:yy
14 EDID xx CPyy Set Input:xx EDID Copy From Output:yy
15 EDID xx DF zz
Set Input:xx EDID To Default EDID:zz
xx=00: Select All INPUT Port
xx=[01...04]: Select One INPUT Port
yy=[01...04]: Select One OUTPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH PCM/DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=09: HDMI 4K2K, Audio 2CH PCM
zz=10: HDMI 4K2K, Audio 5.1CH PCM/DTS/DOLBY
zz=11: HDMI 4K2K, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: User EDID 1
zz=16: User EDID 2
zz=17: GUI Download EDID
18 NET DHCP ON/OFF Set Auto IP(DHCP) ON Or OFF
19 NET IP xxx.xxx.xxx.xxx Set IP Address
20 NET GW xxx.xxx.xxx.xxx Set Gateway Address
21 NET SM xxx.xxx.xxx.xxx Set Subnet Mask Address
22 NET RB Set Network Reboot and Apply New Config!!!
