AC/DC Power Supply
INSTALLATION MANUAL
Thrane & Thrane A/S
AC/DC Power Supply
Installation Manual
Document number: 98-129099-C
Release date: February 26, 2010
Disclaimer
Any responsibility or liability for loss or damage in connection with the use of this
product and the accompanying documentation is disclaimed by Thrane & Thrane. The
information in this manual is provided for information purposes only, is subject to
change without notice and may contain errors or inaccuracies. Manuals issued by
Thrane & Thrane are periodically revised and updated. Anyone relying on this
information should acquire the most current version e.g. from http://www.thrane.com or
from the distributor.Thrane & Thrane is not responsible for the content or accuracy of
any translations or reproductions, in whole or in part, of this manual from any other
source.
Copyright
© 2010 Thrane & Thrane A/S. All rights reserved.
DISPOSAL
Old electrical and electronic equipment marked with this symbol can
contain substances hazardous to human beings and the environment.
Never dispose these items together with unsorted municipal waste
(household waste). In order to protect the environment and ensure the
correct recycling of old equipment as well as the re-utilization of individual components,
use either public collection or private collection by the local distributor of old electrical
and electronic equipment marked with this symbol.
Contact the local distributor for information about what type of return system to use.
iii
Safety summary 1
The following general safety precautions must be observed during all
phases of operation, service and repair of this equipment. Failure to comply
with these precautions or with specific warnings elsewhere in this manual
violates safety standards of design, manufacture and intended use of the
equipment. Thrane & Thrane assumes no liability for the customer's failure
to comply with these requirements.
Observe marked areas
Under extreme heat conditions do not touch
areas of the unit that are marked with this
symbol, as it may result in injury.
KEEP AWAY FROM LIVE CIRCUITS
Operating personnel must not remove equipment covers. All repair and
servicing tasks must be made by qualified maintenance personnel. Do not
service the unit with the power cable connected. Always disconnect and
discharge circuits before touching them.
MAKE SURE THE UNIT IS GROUNDED DURING OPERATION.
Warning! Never insert or remove a power supply while its power
switch is in the On (|) position. Make sure the power
switch is Off (O) first.
iv
About the manual 2
Intended readers
This manual is an installation and user manual for the AC/DC
Power Supply system. It is important that you observe all safety
requirements listed in the beginning of this manual, and operate
the AC/DC Power Supply according to the instructions and
guidelines in this manual. All installation must be done by
qualified service personnel.
Manual overview
This manual has the following chapters:
•Introduction contains a description of the principle of operation
and uses and features of the power supply.
•Installation contains step-by-step guidelines how to install the
power supply as a stand-alone unit or in a combined setup and
describes the connectors.
•Service and repair contains information on support, how to
return units for repair and instructions how to exchange the
fuses.
Typography
In this manual, typography is used as indicated below:
Bold is used to emphasize words and to indicate connector names
of the unit.
Italic is used to emphasize the paragraph title in cross-references.
Example: “For further information, see Connecting Cables on
page...”.
v
Table of Contents
Chapter 1 Introduction
General description ............................................................ 1
Features .............................................................................2
Block diagram ....................................................................3
Applications .......................................................................4
Chapter 2 Installation
Unpacking ..........................................................................5
Installing the AC/DC Power Supply .....................................6
Installing 2 or 3 AC/DC Power Supply units .......................15
Chapter 3 Service and repair
Contact for support ............................................................17
Repair and servicing .........................................................17
Exchanging the fuses ....................................................... 18
Returning units for repair ..................................................19
Table of Contents
vi
App. A Technical specifications
App. B Wall-mount tray (option)
App. C Special installation
App. D Declaration of conformity
Glossary ......................................................................................... 31
Index .........................................................................................33
1
Chapter 1
1111
Introduction
Introduction 1
General description
The TT-6080A AC/DC Power
Supply can deliver 300 W
output power on average
with a peak of 370 W for a
minimum of 2 minutes.This
is useful for MF/HF
applications and DSC
transmissions of 2 minutes
duration. It is AC powered
with a battery switch-over function. The AC/DC Power Supply has an on/off
switch. It is lit when the power is turned on.
All connectors are placed at the same end of the power supply to simplify
mounting and installation. The connector panel is protected by a transparent
lid. To secure an installation with heavy cables a cable-relief bracket can be
installed.
When mounted vertically the AC/DC Power Supply fulfills IP32 in areas with
more than 42 V and IP22 in other areas. This means that the unit is protected
against the intrusion of solid objects (including body parts like fingers), dust,
water etc.
Chapter 1: Introduction
2Features
Features
The AC/DC Power Supply has the following features:
IEC 60945 Maritime approval
Two DC connectors, output, range: 28.7 V - 31.2 V
Output power 300 W continuous, 370 W peak (2 min., 100-240 VAC) or
270 W continuous, 333 W peak (2 min., 90-100 VAC)
AC input (100-240 VAC operating) with fuse (6.3 A)
Automatic selection of input voltage range
AC alarm and On/off switch
Daisy-chaining of up to three units to give up to 900 W.1
Short circuit protection
Over-temperature protection (shutdown with automatic restart)
Battery switch-over in case of AC supply failure, secured by 2 fuses (30 A)
No forced cooling required
IP 3X for internal high voltage areas (>42 V), IP 2X in other areas
IP X2 when vertically mounted (wall) and connector panel is facing down
1. Output power capability depend on the mounting position (horizontal or
vertical), input voltage, ambient temperature and ventilation at the place of
installation.
