THORLABS EXULUS-HD2 Manuel utilisateur

EXULUS-HD2,

EXULUS-HD2HP,

EXULUS-HD3,

EXULUS-HD3HP, &

EXULUS-HD4

Spatial Light Modulators

User Guide

EXULUS®Spatial Light Modulators

Table of Contents
Chapter 1 Warning Symbol Definitions ...........................................1
Chapter 2 Safety.................................................................................2
1. Precautions...................................................................2
2. Product Care.................................................................3
3. Service..........................................................................3
4. Accessories and Customization ......................................4
Chapter 3 Introduction.......................................................................5
1. Overview ......................................................................5
2. Principle –Liquid Crystal on Silicon (LCoS)......................5
3. Parts List –Accessories..................................................5
4. Operating Elements ......................................................9
4.1. Overview................................................................................... 9
4.2. Horizontal and Vertical Fine Adjusters (Standard SLMs)..........11
4.3. SLM Head (High-Power SLMs)................................................11
4.4. Trigger Output Connector (SMA)..............................................11
4.5. Holes for 30 mm Cage System (Standard SLMs).....................12
4.6. Post Mounting Holes................................................................12
4.7. Removable Dust Cover (Standard SLMs) ................................13
Chapter 4 Setup and Software Operation......................................14
1. Installing the SLM .......................................................14
1.1. Mounting Method Conversion of High-Power SLMs.................17
2. Hardware Requirements .............................................22
3. Installing the Software................................................22
4. Connect the SLM to the PC...........................................26

EXULUS®Spatial Light Modulators

4.5. Software GUI ..............................................................28
4.5.1. Main Menu...............................................................................29
4.5.2. Preview Window ......................................................................33
4.5.3. Operation Mode.......................................................................33
4.5.4. Display Mode...........................................................................34
4.5.5. Sequence Setting.....................................................................39
4.5.6. Status Bar................................................................................40
Chapter 5 Troubleshooting.............................................................41
Chapter 6 Specifications.................................................................42
Chapter 7 Mechanical Drawings.....................................................44
Chapter 8 CE/FCC Certification......................................................47
Chapter 9 Warranty..........................................................................51
Chapter 10 Regulatory.......................................................................52
Chapter 11 Thorlabs Worldwide Contacts.......................................53

EXULUS®Spatial Light Modulators Chapter 1: Warning Symbol Definitions

Rev F, December 7, 2020 Page 1

Chapter 1 Warning Symbol Definitions

Below is a list of warning symbols you may encounter in this manual or on your

device.

Symbol

Description

Direct Current

Alternating Current

Both Direct and Alternating Current

Earth Ground Terminal

Protective Conductor Terminal

Frame or Chassis Terminal

Equipotentiality

On (Supply)

Off (Supply)

In Position of a Bi-Stable Push Control

Out Position of a Bi-Stable Push Control

Caution: Risk of Electric Shock

Caution: Hot Surface

Caution: Risk of Danger

Warning: Laser Radiation

Caution: ESD Sensitive Components

EXULUS®Spatial Light Modulators Chapter 2: Safety

Page 2 CTN013676-D02

Chapter 2 Safety

2.1. Precautions

Please read the instruction manual carefully before operating your Spatial Light

Modulators. All statements regarding safety and technical specifications will only

apply when the unit is operated correctly.

Refer to this User’s Guide whenever the following symbols are encountered on the

Spatial Light Modulators.

DO NOT OPEN HOUSING

Thorlabs’ SLM has no user-serviceable parts. Service should only be performed

by trained service personnel.

SHOCK WARNING

High voltage inside. To avoid electrical shock, before powering up, make sure that

the ground pin of the power cord is correctly connected to the ground connector

in the power socket. Improper grounding can cause electric shock resulting in

severe injury or even death. Do not operate without the cover installed.

WARNING

This unit must not be operated in explosive environments. Do not operate in

wet/damp conditions. Do not obstruct the air ventilation slots in the housing.

WARNING

Transportation and delivery may cause the SLM to be warm or cool upon receipt.

Please wait for the whole device to reach room temperature before attempting to

operate.

EXULUS®Spatial Light Modulators Chapter 2: Safety

Rev F, December 7, 2020 Page 3

2.2. Product Care

Handle the complete system with care during transportation and unpacking.

Banging or dropping the system can damage the unit or lower the system

performance. If this occurs, the complete system will need to be sent back for

recalibration. Please contact Thorlabs Technical Support for more information.

•Do not store or operate in a damp, closed environment.

•Do not store or operate on surfaces that are susceptible to vibrations.

•Do not expose to direct sunlight.

•Do not use the solvents on or near the equipment.

•Mobile telephones, cellular phones, or other radio transmitters should not

be used with a range of 3 m of this unit since the electromagnetic field

intensity may exceed the maximum allowable disturbance values,

according to EN50082-1.

•Keep away from dust, dirt, and air-borne pollutants (including cigarette

smoke). The system is not designed for outdoor use. Protect the

equipment from rain, snow, and humidity.

•Do not expose to mechanical and thermal extremes. Protect the

equipment from rapid variations in temperature.

•Handle all connectors with care. Do not use unnecessary force, as this

may damage the connectors.

•Handle the mainframe with care. Mishandling may cause the body injury.

•Clean the protective window by using a soft, lint free cloth. Use of

isopropyl alcohol is permitted; however, do not immerse in any liquid or

solvent.

•Clean any accessible optical surfaces with an appropriate optics grade

tissue or cloth.

2.3. Service

CAUTION

Except for the main fuse, which is accessible from the outside of the housing, the

EXULUS®SLM has no user-serviceable parts. Service should only be performed

by trained service personnel.

Only trained and approved Thorlabs’ personnel should service the system. Please

contact Thorlabs Technical Support at techsupport@thorlabs.com and a member

of our team will be happy to assist you.

EXULUS®Spatial Light Modulators Chapter 2: Safety

Page 4 CTN013676-D02

2.4. Accessories and Customization

Although the system is easily adapted for custom interfaces, to achieve the listed

specifications, this system should only be used with accessories provided by

Thorlabs. Any modification or servicing by unqualified personnel renders the

warranty null and void, leaving Thorlabs free of liability.

Custom version with panel and controller in separate units available, please

contact Tech Support for questions on customization.

EXULUS®Spatial Light Modulators Chapter 3: Introduction

Rev F, December 7, 2020 Page 5

Chapter 3 Introduction

This manual provides instruction on how to install and operate a Thorlabs

EXULUS-HD2, EXULUS-HD2HP, EXULUS-HD3, EXULUS-HD3HP, or EXULUS-

HD4 2D Spatial Light Modulator (SLM). To ensure correct usage, read this manual

carefully before operating your EXULUS®.

3.1. Overview

Thorlabs’ EXULUS®SLM is a reflective SLM based on Liquid Crystal on Silicon

(LCoS) technology. It offers individually addressable pixels of phase shift or

retardance and provides large phase stroke and excellent phase stability.

Therefore, the EXULUS®SLM is ideal for many beam manipulation applications

including optical trapping, beam steering and shaping, femtosecond pulse

shaping, adaptive optics, imaging applications, holography, interferometry, laser

processing, lithography, and others.

3.2. Principle –Liquid Crystal on Silicon (LCoS)

The Liquid Crystal on Silicon (LCoS) technology is a reflective retarder panel

utilizing a liquid crystal layer sandwiched between a top transparent and

conductive ITO layer, and the reflective electrode layer on the bottom. On the

bottom layer, pixels are arranged as individual addressable aluminum electrodes.

Together with the ITO layer on top, an electric field is built by applying a voltage

between the two layers. The liquid crystal modules align according to the direction

and strength of the electric field. Since liquid crystal is a birefringent material, the

alignment of the liquid crystal modules in turn determines the retardance or phase

shift of each pixel.

Figure 1 Schematic of Liquid Crystal on Silicon

3.3. Parts List –Accessories

The EXULUS®SLM is thoroughly tested and carefully packed at the factory. The

complete package varies according to the EXULUS model. Standard SLMs

(EXULUS-HD2, HD3, and HD4) consist of a main unit with a built-in SLM panel

and relevant accessories. The High-Power SLMs (EXULUS-HD2HP and HD3HP)

contains a main unit, an adapter board, an SLM head, and additional accessories.

The adapter board and SLM head are pre-installed on the main unit.

EXULUS®Spatial Light Modulators Chapter 3: Introduction

Page 6 CTN013676-D02

Accessories of standard SLM:

•Power Supply (Item # DS12)

•USB Cable

•HDMI Cable

•DP-to-HDMI Cable

•USB Drive with Software and Manual

•Hex Key Thumbscrew (Item # HKTS-5/64)

Accessories of High-Power SLMs:

•Power Supply (Item # DS12)

•USB Cable

•HDMI Cable

•DP-to-HDMI Cable

•USB Drive with Software and Manual

•2 mm Balldriver

•Ø2” Dust-Proof Tape

•Tubing Clip

•2.5 mm Stereo Cable for Thermistor Connection to Liquid Cooling System

(Item # LK220)

•CPC®Valved Quick-Connection Fittings for 4.3 mm (0.17”) Inner

Diameter Hose

•CPC®Valved Quick-Connection Fittings for 6.0 mm (0.24”) Inner

Diameter Hose

Figure 2 Standard SLM, with Main Unit and Removable Dust Cover Installed

EXULUS®Spatial Light Modulators Chapter 3: Introduction

Rev F, December 7, 2020 Page 7

Figure 3 High-Power SLM, Main Unit with Adapter Board and SLM Head Pre-

mounted

Figure 4 Power Supply

(Item # DS12)

Figure 5 USB Cable

Figure 6 HDMI Cable

Figure 7 DP-HDMI Cable

Figure 8 USB Drive with Software

and Manual

Figure 9 Hex Key Thumbscrew

(Item # HKTS-5/64)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels THORLABS Équipement industriel

THORLABS

THORLABS Vytran LFS4100 Manuel utilisateur

THORLABS

THORLABS IO-K-1050 Manuel utilisateur

THORLABS

THORLABS ULTRAsplice Manuel d'utilisation et d'entretien

THORLABS

THORLABS DTS25 Manuel utilisateur

THORLABS

THORLABS LCC1620A Manuel utilisateur

THORLABS

THORLABS vytran LDC450B Manuel utilisateur

THORLABS

THORLABS IO-K-1064 Manuel utilisateur

THORLABS

THORLABS MAX300 Series Manuel utilisateur

THORLABS

THORLABS DDS300 Manuel utilisateur

THORLABS

THORLABS PICO D Manuel utilisateur

THORLABS

THORLABS MicroBlock MBT Series Manuel utilisateur

THORLABS

THORLABS KT120 Manuel utilisateur

THORLABS

THORLABS IO-L-1030 Manuel utilisateur

THORLABS

THORLABS IO-F-780APC Manuel utilisateur

THORLABS

THORLABS LNR50 Series Manuel utilisateur

THORLABS

THORLABS PRM1-Z7 Series Manuel utilisateur

THORLABS

THORLABS PDA400 Manuel utilisateur

THORLABS

THORLABS IO-F-940 Manuel utilisateur

THORLABS

THORLABS IO-J-1050APC Manuel utilisateur

THORLABS

THORLABS M F1 Series Manuel utilisateur

THORLABS

THORLABS LNR502 Manuel utilisateur

THORLABS

THORLABS PDF10C2 Manuel utilisateur

THORLABS

THORLABS IO-K-1030 Manuel utilisateur

THORLABS

THORLABS IO-L-2000 Manuel utilisateur

Manuels Équipement industriel populaires d'autres marques

ABB

ABB Unifix AD Manuel

Mark 7

Mark 7 Evolution Manuel utilisateur

Husky

Husky HyPET Manuel utilisateur

bora

bora PM-1800 Manuel utilisateur

Grizzly

Grizzly T32428 Manuel utilisateur

Siemens

Siemens 8MF1 Series Manuel utilisateur

ABB

ABB HT610965 Manuel utilisateur

ABB

ABB SafeLink Manuel utilisateur

Phoenix

Phoenix PHX-150 Manuel utilisateur

ABB

ABB A165-L32 Manuel utilisateur

ABB

ABB HT842936 Manuel utilisateur

Rioned

Rioned UrbanJet Manuel utilisateur

Hermetica

Hermetica 10 Series Manuel utilisateur

HORNER

HORNER OEE Solution Manuel utilisateur

Hammerhead

Hammerhead HG375 Manuel utilisateur

SCHUNK

SCHUNK VERO-S NSE-A3 138 Instructions d'utilisation

ABB

ABB HT566657 Manuel utilisateur

Webasto

Webasto GSE CAN Manuel utilisateur
