THOR EDGE Manuel utilisateur

EDGE

User Guide

Document reference: EDGE User Guide 22v8

Distribution date: August 15, 2022

No part of this publication may be reproduced or

transmitted in any form or by any means without the

express written consent of the publisher.

www.THORav.us | sales@thorav.us | (763) 999-4253

EDGE LED PANEL INSTRUCTIONS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS

INSIDE.

The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of un-insulated and/or potentially dangerous voltage within the

products enclosure that may be of sufcient magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature

accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1. Intended use for the EDGE series is for indoor applications.

2. Inspect all products and perform safety related checks before deployment.

3. Read and understand this entire manual.

4. Keep this manual available for reference.

5. Heed all warnings and precautions in this manual and notices marked on the product.

6. Do not use this product near water or damp environments.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Provide for proper airow around product. Do not install near products that produce high levels

of heat. Do not expose the unit to direct sun light or heating units as the internal components’

temperature may rise and shorten the life of the components.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two

blades with one wider than the other. A grounding type plug has two blades and a third grounding

prong.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they connect to the product. Do not use the unit if the electrical

power cord is frayed or broken.

11. THOR AV products must be used in accordance with local, state, federal and industry regulations.

The responsibility to evaluate the reliability of any rigging or mounting method for their application

is solely the user’s responsibility. Rigging is to be carried out by experienced professionals.

12. Abide by the Working Load Limit (WLL) of third party equipment for suspension points, chain hoists

and additional rigging hardware.

13. Verify structural integrity meets engineering requirements for ying, ground stacking and wall

mounting applications.

14. THOR AV is not responsible for any rigging, attachments and accessories provided by third party

manufacturers.

15. Utilize safety measures at all times, including safety slings and cables.

16. Unplug this product during lightning storms or when unused for long periods of time.

17. Refer all servicing to qualied service personnel. There are no user serviceable components inside

the product.

18. The product shall not be exposed to moisture. Do not touch the unit with wet hands. Do not handle

the unit or power cord when your hands are wet or damp.

19. The product should be connected to a power supply only of the type described in the operating

instructions or as marked on the product.

CARE

• From time to time you should wipe off the front and side panels and the cabinet with a dry soft

cloth. Do not use rough material, thinners, alcohol or other chemical solvents or cloths since this may

damage the nish or remove the panel lettering.

• The manufacturer cannot be held responsible for damages caused to persons, personal possessions,

or data due to an improper or missing ground connection.

www.THORav.us | sales@thorav.us | (763) 999-4253

THOR LIMITED WARRANTY

All THOR AV LED products are warranted to the original purchaser to be free of defects in materials and

workmanship for a period of two years from date of purchase. During this period, THOR AV will, at its

discretion, repair the defective unit or replace it with a new or rebuilt one.

The warranty does NOT cover:

• Damages caused by abuse, accident, improper use, improper handling, improper operation,

improper installation/disassembly of the display or any other customer misconduct.

• Damages due to installation of any unauthorized hardware, accessories, consumable parts or

components.

• Defects, malfunctions or damages caused during transportation.

• Units on which the product serial number has been removed or altered.

• Units that have been serviced by unauthorized personnel.

All implied warranties, including warranties on merchantability and tness, are limited in time to the length

of this warranty. Some states do not allow time limitations on implied warranties, so this limitation may not

apply to you. THOR AV’s liability is limited to the repair or replacement of its product. THOR AV shall in no

way be held liable for incidental or consequential damages resulting from the use of their product or its

software, including, without limitation, damages from loss of business prots, business interruption, loss

of business information or other pecuniary loss. Some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation or exclusion may not apply to you.

REPAIR POLICY

Please contact support@thorav.us to obtain an RMA number prior to returning your product to THOR AV.

Do not return the product to the place of purchase. Write the RMA number on the outside of the shipping

carton. Any product sent to us without a valid RMA number will be refused.

Shipping Address:

THOR AV

Attn: RMA Number

8821 Zealand Ave. N, Ste. B

Brooklyn Park, MN 55445 USA

Include the following with the product: a brief description of the problem, your name, return shipping

address, phone number and the RMA number. Do not include any accessories. THOR AV is not

responsible for any damage to or loss of the product during transit. We recommend that customers obtain

a receipt and tracking number for all packages shipped to us. Turnaround time on repairs is generally ten

business days. If you live outside of the United States, please contact your local distributor for warranty

service.

WARRANTY SERVICE

You will be responsible for shipping charges to THOR AV and the product will be returned by THOR AV.

We reserve the right to inspect any product that may be the subject of any warranty claim before repair is

carried out. To qualify for warranty service, documentation showing the date of purchase may be required.

Final determination of warranty coverage lies solely with THOR AV.

NON-WARRANTY SERVICE

If it is determined that the product does not meet the terms of our warranty, you will be billed for labor,

materials, return shipping and insurance. There is a $100 USD minimum charge for materials and labor.

Appropriate shipping charges will be applied. We require payment in advance of repair by credit card;

we accept Visa and Master Card. In the event the charges are over the minimum charge, THOR AV will

contact you and inform you of the cost of the repair before any work is completed.

www.THORav.us | sales@thorav.us | (763) 999-4253

TABLE OF CONTENTS

SAFETY INSTRUCTIONS

EDGE LED PANEL INSTRUCTIONS II

WARRANTY

THOR LIMITED WARRANTY III

OVERVIEW

EDGE LED PANEL 5

SPECIFICATIONS 6

ANATOMY 7

Front View 7

Rear View 500mm x 1000mm 8

Rear View 500mm x 500mm 9

Parts 10

Dimensions 12

INSTALLATION REQUIREMENTS

MECHANICAL 13

ELECTRICAL 13

VIDEO SYSTEM 14

INSTALL APPLICATION

IMPORTANT SAFETY CONSIDERATIONS 15

FLOWN LED WALL 16

GROUND STACKED LED WALL 18

CONNECTION GUIDE

POWER CONNECTION 23

DATA CONNECTION 24

PROCESSORS

PROCESSORS 25

Brompton Technology 25

Novastar 25

www.THORav.us | sales@thorav.us | (763) 999-4253

TABLE OF CONTENTS

SERVICE & MAINTENANCE

Replacing Power Data Box 26

Cleaning Modules 26

Removing Modules 26

Replacing Modules 27

APPENDIX

TROUBLESHOOTING 28

CONTACT 30

GLOSSARY 31

For ground stacked or own LED walls, the EDGE series

of LED video walls are quick to set up and offer incredible

high performance with options that will t your budget and

creativity. With unparalleled on-camera performance, EDGE

LED video walls are distraction-free and excel in live and

broadcast scenarios.

• 2.9mm, 3.4mm, and 3.9mm pixel pitches

• Brompton or NovaStar processor options

• 500mm x 500mm or 500mm x 1000mm cabinet options

• Superior on-camera performance

• Front and rear maintenance access

• Up to 1250 nit calibrated brightness

• Straight or curved option

INDOOR LED WALL PANEL

EDGE LED PANEL

www.THORav.us | sales@thorav.us | (763) 999-4253

2.9 Brompton

2.9i NovaStar

3.4 Brompton

3.4i NovaStar 3.9i NovaStar

Pixel Pitch 2.97mm 3.47mm 3.9mm

Calibrated Brightness 1,250 nits 1,250 nits 1,250 nits

Viewing Angle 140° x 140° 140° x 140° 140° x 140°

Closest Viewer 12.5 FT / 3.5M 15 FT / 4M 18FT / 5M

LED Module SMD 2020 gold wire SMD 2020 gold wire SMD 2020 gold wire

Driving IC Module MBI IC Drivers with S-PWM MBI IC Drivers with S-PWM MBI IC Drivers with S-PWM

Serviceability Front / Rear Front / Rear Front / Rear

Panel Dimensions

500mm x1000mm 500 x 1000 x 88mm

(19.7” x 39.37” x 3.5")

500 x 1000 x 88mm

(19.7” x 39.37” x 3.5")

500 x 1000 x 88mm

(19.7” x 39.37” x 3.5")

500mm x 500mm 500 x 500 x 88mm

(19.7” x 19.7” x 3.5")

500 x 500 x 88mm

(19.7” x 19.7” x 3.5")

500 x 500 x 88mm

(19.7” x 19.7” x 3.5")

Hardware Options Fly & Ground Stack Fly & Ground Stack Fly & Ground Stack

Processor Platform/Receiving Card Brompton Brompton R2 Brompton R2 N/A

NovaStar NovaStar A8s NovaStar A8s NovaStar A5s Plus

Driving Method 1/14 scan 1/12 scan 1/16 scan

Gray Scale 16 bit 14 bit 14 bit

Refresh Rate 3,840+ Hz 3,840+ Hz 3,840+ Hz

Brightness Control Brompton 1250 steps 1250 steps N/A

NovaStar 256 steps 256 steps 256 steps

Pixel Conguration 500mm x1000mm 168 x 336 (w x h) 56,448 144 x 288 (w x h) 41,472 128 x 256 (w x h) 32,768

500mm x 500mm 168 x 168 (w x h) 28,224 144 x 144 (w x h) 20,736 128 x 128 (w x h) 16,384

Module Conguration 500mm x1000mm 2 x 2 2 x 2 2 x 2

500mm x 500mm 1 x 2 1 x 2 1 x 2

Chassis - Straight Standard Standard Standard

Chassis - Curving Option* +/- 0°, 2.5°, 5°, 7.5°, 10° +/- 0°, 2.5°, 5°, 7.5°, 10° +/- 0°, 2.5°, 5°, 7.5°, 10°

Operating Temperature -30° to 50° C -30° to 50° C -30° to 50° C

Operating Humidity 10% to 90% 10% to 90% 10% to 90%

Power Input 120/240 Volt at 50/60 Hz 120/240 Volt at 50/60 Hz 120/240 Volt at 50/60 Hz

Power Consumption 500mm x1000mm 300W max. 150W avg. 300W max. 100W avg. 300W max. 100W avg.

500mm x 500mm 200W max. 100W avg. 200W max. 75W avg. 200W max. 75W avg.

BTU/hr 500mm x1000mm 1024 max. 500 avg. 1024 max. 342 avg. 1024 max. 342 avg.

500mm x 500mm 683 max. 300 avg. 683 max. 256 avg. 683 max. 256 avg.

Electrical Circuits 120V/20A

(Recommended)

500mm x1000mm 10 panels 10 panels 10 panels

500mm x 500mm 18 panels 18 panels 18 panels

Flown Maximum Rigging Height 14M (46’) 14M (46’) 14M (46’)

Ground Stacked Maximum Height 6M (20’) 6M (20’) 6M (20’)

Chassis Material Die Cast Aluminum Die Cast Aluminum Die Cast Aluminum

Weight 500mm x1000mm 14.5 kg (32 lbs) 14.5 kg (32 lbs) 14.5 kg (32 lbs)

500mm x 500mm 10.5 kg (24 lbs) 10.5 kg (24 lbs) 10.5 kg (24 lbs)

IP Rating IP31 IP31 IP31

Certications FCC, ETL, EMC FCC, ETL, EMC FCC, ETL, EMC

Life Span 100,000+ Hours 100,000+ Hours 100,000+ Hours

Limited Warranty 2 years 2 years 2 years

SPECIFICATIONS

*Special Order Only

www.THORav.us | sales@thorav.us | (763) 999-4253

LED MODULES

500mm X 500mm500mm X 1000mm

FRONT VIEW

www.THORav.us | sales@thorav.us | (763) 999-4253

RATCHETING LOCKS

DATA IN DATA OUT

POWERCON IN POWERCON OUT

POWER & TEST

PATTERN BUTTON

POWER SUPPLY

THUMB SCREWS

GUIDE PINS

GUIDE PIN

LOCK RECEIVERS

STRAIGHT LOCK

RECEIVERS

LED MODULE SAFETY

CARABINER & CABLE

CHASSIS HANDLE/STEP

REMOVABLE

PDB

LATCH LOCKS

REAR VIEW 500mm X 1000mm

www.THORav.us | sales@thorav.us | (763) 999-4253

RATCHETING LOCKS

LATCH LOCKS

DATA IN DATA OUT

POWERCON IN

POWERCON OUT

POWER & TEST

PATTERN BUTTON

POWER SUPPLY

THUMB SCREWS

GUIDE PINS

GUIDE PIN

LOCK RECEIVERS

STRAIGHT LOCK

RECEIVERS

LED MODULE SAFETY

CARABINER & CABLE

CHASSIS HANDLE/STEP

REMOVABLE

PDB

REAR VIEW 500mm X 500mm

Table des matières

Autres manuels THOR Équipement d'éclairage

THOR

THOR RIDGE Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
