Thomann JunoScan MK-II Manuel utilisateur

JunoScan MK-II

LED scanner

user manual

Musikhaus Thomann e.K.

Treppendorf 30

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: [email protected]

Internet: www.thomann.de

26.10.2012

Table of contents

1 General notes............................................................................................................................................... 5

2 Safety notes.................................................................................................................................................. 8

3 Features....................................................................................................................................................... 14

4 Installation.................................................................................................................................................. 15

5 Setup.............................................................................................................................................................. 18

6 Connections and controls................................................................................................................... 21

7 Operation.................................................................................................................................................... 26

7.1 Starting up the device.................................................................................................................... 26

7.2 Main menu.......................................................................................................................................... 27

7.3 Settings menu................................................................................................................................... 33

7.4 Gobos................................................................................................................................................... 36

7.5 Functions in 5-channel DMX mode........................................................................................... 38

7.6 Functions in 8-channel DMX mode........................................................................................... 42

8 Troubleshooting...................................................................................................................................... 50

Table of contents

JunoScan MK-II

9 Cleaning....................................................................................................................................................... 52

10 Technical data........................................................................................................................................... 53

11 Protecting the environment.............................................................................................................. 54

Table of contents

LED scanner

1 General notes

This user manual contains important information on safe operation of the device. Read and

follow all safety notes and all instructions. Save this manual for future reference. Make sure

that it is available to all persons using this device. If you sell the device, include the manual for

the next owner.

Our products are subject to a process of continuous development. We therefore reserve the

right to make changes without notice.

This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words

General notes

JunoScan MK-II

Signal word Meaning

DANGER! This combination of symbol and signal word

indicates an immediate dangerous situation

that will result in death or serious injury if it is

not avoided.

WARNING! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in death or serious injury if it is not

avoided.

CAUTION! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in minor injury if it is not avoided.

NOTICE! This combination of symbol and signal word

indicates a possible dangerous situation that

can result in material and environmental

damage if it is not avoided.

General notes

LED scanner

Warning signs Type of danger

Warning – high-voltage.

Warning – hot surface.

Warning – dangerous optical radiation.

Warning – suspended load.

Warning – danger zone.

General notes

JunoScan MK-II

2 Safety notes

This device is intended for use as a multifunctional lighting instrument with movable mirror.

Use the device only as described in this user manual. Any other use or use under other oper‐

ating conditions is considered to be improper and may result in personal injury or property

damage. No liability will be assumed for damages resulting from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual

abilities and having corresponding knowledge and experience. Other persons may use this

device only if they are supervised or instructed by a person who is responsible for their safety.

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not

within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Intended use

Safety

Safety notes

LED scanner

DANGER!

Electric shock caused by high voltages inside

Within the device there are areas where high voltages may be present. Never

remove any covers.

There are no user-serviceable parts inside.

DANGER!

Electric shock caused by short-circuit

Always use proper ready-made insulated mains cabling (power cord) with a pro‐

tective contact plug. Do not modify the mains cable or the plug. Failure to do so

could result in electric shock/death or fire. If in doubt, seek advice from a regis‐

tered electrician.

Safety notes

JunoScan MK-II

WARNING!

Eye damage caused by high light intensity

The lamp used in this device produces an intense beam of visible and invisible

light radiation.

Do not start the operation of the device without completely fixed covers. Never

look directly into the light source.

WARNING!

Risk of epileptic shock

Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons

should avoid looking at strobe lights.

Safety notes

LED scanner
