Thomann Proline 3000 Manuel utilisateur

Proline 3000

power amplifier

user manual

Musikhaus Thomann e.K.

Treppendorf 30

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: [email protected]

Internet: www.thomann.de

04.07.2014, ID: 168990

Table of contents

1 General notes............................................................................................................................................... 4

2 Safety instructions..................................................................................................................................... 6

3 Installation and starting up................................................................................................................ 11

4 Connections and operating elements........................................................................................... 17

5 Technical specifications....................................................................................................................... 22

6 Cleaning....................................................................................................................................................... 24

7 Protecting the environment.............................................................................................................. 25

Table of contents

Proline 3000

1 General notes

This user manual contains important information on safe operation of the device. Read and

follow all safety notes and all instructions. Save this manual for future reference. Make sure

that it is available to all persons using this device. If you sell the device to other users, be sure

that they also receive this manual.

Our products are subject to a process of continuous development. We therefore reserve the

right to make changes without notice.

This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words

General notes

power amplifier

Signal word Meaning

DANGER! This combination of symbol and signal word indicates an

immediate dangerous situation that will result in death or

serious injury if it is not avoided.

CAUTION! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in minor injury if it

is not avoided.

NOTICE! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in material and

environmental damage if it is not avoided.

Warning signs Type of danger

Warning – high-voltage.

Warning – danger zone.

General notes

Proline 3000

2 Safety instructions

Use the device only as described in this user manual. Any other use or use under other oper‐

ating conditions is considered to be improper and may result in personal injury or property

damage. No liability will be assumed for damages resulting from improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual

abilities and having corresponding knowledge and experience. Other persons may use this

device only if they are supervised or instructed by a person who is responsible for their safety.

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not

within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Intended use

Safety

Safety instructions

power amplifier

DANGER!

Electric shock caused by high voltages inside

Within the device there are areas where high voltages may be present. Never

remove any covers.

There are no user-serviceable parts inside.

DANGER!

Electric shock caused by short-circuit

Always use proper ready-made insulated mains cabling (power cord) with a pro‐

tective contact plug. Do not modify the mains cable or the plug. Failure to do so

could result in electric shock/death or fire. If in doubt, seek advice from a regis‐

tered electrician.

Safety instructions

Proline 3000

CAUTION!

Possible hearing damage

With loudspeakers or headphones connected, the device can produce volume

levels that may cause temporary or permanent hearing impairment.

Do not operate the device permanently at a high volume level. Decrease the

volume level immediately if you experience ringing in your ears or hearing

impairment.

CAUTION!

Risk of injury due to heavy weight

Due to the heavy weight of the device, at least two persons are required for trans‐

port and installation.

Safety instructions

power amplifier

NOTICE!

Risk of fire

Do not cover the device nor any ventilation slots. Do not place the device near

any direct heat source. Keep the device away from naked flames.

NOTICE!

Operating conditions

This device has been designed for indoor use only. To prevent damage, never

expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and

strong vibrations.

Safety instructions

Proline 3000

NOTICE!

Power supply

Before connecting the device, ensure that the input voltage (AC outlet) matches

the voltage rating of the device and that the AC outlet is protected by a residual

current circuit breaker. Failure to do so could result in damage to the device and

possibly injure the user.

Unplug the device before electrical storms occur and when it is unused for long

periods of time to reduce the risk of electric shock or fire.

NOTICE!

Magnetic fields

The device generates strong magnetic fields that can interfere with the function

of poorly shielded devices. The strongest magnetic fields are directly above and

below the power amplifier. Therefore, never place sensitive devices such as pre-

amplifiers, radio transmission systems, or tape decks directly above or below the

power amplifier. When installing the power amplifier into a rack, you should place

it in the lowest position, and further equipment such as pre-amplifiers in the

highest position.

Safety instructions

power amplifier
