Texas Instruments TPA311 Manuel utilisateur

2001 Mixed-Signal Products

TPA311

Audio Power Amplifier

Evaluation Module

User’s Guide

SLOU013A

IMPORTANT NOTICE

TexasInstrumentsanditssubsidiaries(TI)reservetherighttomakechangestotheirproductsortodiscontinue

any product or service without notice, and advise customers to obtain the latest version of relevant information

to verify, before placing orders, that information being relied on is current and complete. All products are sold

subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those

pertaining to warranty, patent infringement, and limitation of liability.

TI warrants performance of its products to the specifications applicable at the time of sale in accordance with

TI’sstandardwarranty.TestingandotherqualitycontroltechniquesareutilizedtotheextentTIdeemsnecessary

to support this warranty. Specific testing of all parameters of each device is not necessarily performed, except

those mandated by government requirements.

Customers are responsible for their applications using TI components.

In order to minimize risks associated with the customer’s applications, adequate design and operating

safeguards must be provided by the customer to minimize inherent or procedural hazards.

TIassumesnoliabilityforapplicationsassistance or customer product design. TI does not warrantorrepresent

thatanylicense,eitherexpressorimplied,isgrantedunderanypatentright,copyright,maskworkright,orother

intellectual property right of TI covering or relating to any combination, machine, or process in which such

products or services might be or are used. TI’s publication of information regarding any third party’s products

or services does not constitute TI’s approval, license, warranty or endorsement thereof.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alterationandisaccompaniedbyallassociatedwarranties,conditions,limitationsandnotices. Representation

or reproduction of this information with alteration voids all warranties provided for an associated TI product or

service, is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.

Resale of TI’s products or services with statements different from or beyond the parameters stated by TI for

that product or service voids all express and any implied warranties for the associated TI product or service,

is an unfair and deceptive business practice, and TI is not responsible nor liable for any such use.

Also see: Standard Terms and Conditions of Sale for Semiconductor Products. www.ti.com/sc/docs/stdterms.htm

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

iii

Chapter Title—Attribute Reference

Preface

Related Documentation From Texas Instruments

TI Plug-N-Play Audio Amplifier Evaluation Platform (literature

number SLOU011) provides detailed information on the evaluation

platform and its use with TI audio evaluation modules.

TPA311 350-mW Low-Voltage Audio Power Amplifier (literature

number SLOS207) This is the data sheet for the TPA311 audio

amplifier integrated circuit.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

testedfor compliance with thelimitsof computing devices pursuanttosubpart

Jofpart 15of FCCrules, whicharedesignedtoprovidereasonableprotection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademarks

TI is a trademark of Texas Instruments Incorporated.

Running Title—Attribute Reference

Chapter Title—Attribute Reference

Contents

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Feature Highlights 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Description 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 TPA311 EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Quick Start 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Precautions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Quick Start List for Platform 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Quick Start List for Stand-Alone 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Details 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Precautions 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 The TPA311 Audio Amplifier Evaluation Module 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.1 TPA311 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.2 BTL Operation 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.3 Single-Ended Operation 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.4 Module Gain 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.5 Shutdown 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Using The TPA311 EVM With The Plug-N-Play Evaluation Platform 3-6. . . . . . . . . . . . . . .

3.3.1 Installing and Removing EVM Boards 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.2 Signal Routing 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.3 Mute/Mode 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.4 Power Requirements 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3.5 Inputs and Outputs 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Using The TPA311 EVM Stand-ALone 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4.1 TPA311 EVM Connected for BTL Output 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4.2 TPA311 EVM Connected for Single-Ended Output 3-13. . . . . . . . . . . . . . . . . . . . . .

3.5 TPA311 Audio Amplifier Evaluation Module Parts List 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference

Figures

1–1 The TI TPA311 Audio Amplifier Evaluation Module 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Quick Start Platform Map 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Quick Start Module Map 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 The TI Plug-N-Play Audio Amplifier Evaluation Platform 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 TPA311 EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–3 TPA311 EVM Schematic Diagram 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–4 TPA311 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–5 Platform Signal Routing and Outputs 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–6 Mute/Mode and Polarity Control 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–7 Typical Headphone Plug 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–8 TPA311 EVM Connected for Stereo BTL Output 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–9 TPA311 EVM Connected for Stereo Single-Ended Output 3-13. . . . . . . . . . . . . . . . . . . . . . . . .

Tables

2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA311 2-1. . . . . . . . . .

2–2 Platform Jumper and Switch Settings for the TPA311 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 TPA311 EVM Parts List 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction

This chapter provides an overview of the Texas Instruments (TI) TPA311

audio amplifier evaluation module (SLOP116). It includes a list of EVM

features, a brief description of the module illustrated with a pictorial diagram,

and a list of EVM specifications.

Topic Page

1.1 Feature Highlights 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Description 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 TPA311 EVM Specifications 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Feature Highlights

1-2 Introduction

1.1 Feature Highlights

TheTITPA311audioamplifierevaluationmoduleandtheTIplug-n-playaudio

amplifier evaluation platform include the following features:

TPA311 Low-Voltage Audio Power Amplifier Evaluation Module

Single channel, bridge-tied load (BTL) or single-ended operation

3.3-V and 5-V operation

350 mW output power into 8 Ωat 5 V, BTL

Ultra-low current consumption in shutdown/mute mode

Internal thermal and short-circuit protection

Module gain adjustable between approximately 2 and 22

Quick and Easy Configuration With The TI Plug-N-Play Audio Amplifier

Evaluation Platform

Evaluation module is designed to simply plug into the platform, auto-

matically making all signal, control, and power connections

Platform provides flexible power options

Jumpers on the platform select power and module control options

Switches on the platform route signals

Platformprovides quick and easy audio inputand output connections

Platform Power Options

Onboard 9-V battery

External 5-V –15-V DC VCC supply inputs

External regulated VDD supply input

Socket for onboard 5 V/3.3 V VDD voltage regulator EVM

Onboard overvoltage and reverse polarity power protection

Platform Audio Input and Output Connections

Left and right RCA phono jack inputs

Miniature stereo phone jack input

Left and right RCA phono jack outputs

Left and right compression speaker terminal outputs

Miniature stereo headphone jack output

Description

1-3

Introduction

1.2 Description

TheTPA311 audiopower amplifierevaluationmoduleisacomplete,low-pow-

er single-channel audio power amplifier. It consists of the TI TPA311 350-mW

low-voltage audio power amplifier IC along with a small number of other parts

mounted on a circuit board that is approximately one and a quarter inches

square (Figure 1–1).

Figure 1–1.The TI TPA311 Audio Amplifier Evaluation Module

C4 R3

IN+

Shutdown

C5 C3 OUT–

GND

OUT+

GND

GNDVDD

R4 EVM

Literature #

SLOP116

TPA311

SE\BTL*

009227

–3

Single in-line header pins are mounted to the underside of the module circuit

board to allow the EVM to be plugged into the TI plug-n-play audio amplifier

evaluationplatform, or to be wired directlyintoexisting circuitsandequipment

when used stand-alone.

The platform has room for a pair of TPA311 evaluation modules and is a

convenient vehicle for demonstrating TI’s audio power amplifier and related

evaluation modules. The EVMs simply plug into the platform, which auto-

matically provides power to the modules, interconnects them correctly, and

connectsthemtoaversatilearrayofstandardaudioinputandoutputjacksand

connectors. Easy-to-use configuration controls allow the platform and EVMs

to quickly model many possible end-equipment configurations.

There is nothing to build, nothing to solder, and nothing but the speakers

included with the platform to hook up.

1.3 TPA311 EVM Specifications

Supply voltage range, VDD 2.5 V to 5.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Supply current, IDD 250 mA, max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Continuous output power, PO:8-ΩBTL, VDD=5 V: 350 mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

32-ΩBTL, VDD=5 V: 75 mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Audio input voltage, VI2 Vpp, max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Minimum load impedance, RL8 Ω. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-4 Introduction

Table des matières

Autres manuels Texas Instruments Amplificateur

Texas Instruments

Texas Instruments SLAU081 Manuel utilisateur

Texas Instruments

Texas Instruments TPA751 MSOP Manuel utilisateur

Texas Instruments

Texas Instruments TAS5102EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPA102 MSOP Manuel utilisateur

Texas Instruments

Texas Instruments TPA2000D4 Manuel utilisateur

Texas Instruments

Texas Instruments THS3001 Manuel utilisateur

Texas Instruments

Texas Instruments LM4910 Boomer Manuel utilisateur

Texas Instruments

Texas Instruments TPA6030A4 Manuel utilisateur

Texas Instruments

Texas Instruments Burr-Brown OPA569 Manuel utilisateur

Texas Instruments

Texas Instruments TPA0243 Manuel utilisateur

Texas Instruments

Texas Instruments THS7002 Manuel utilisateur

Texas Instruments

Texas Instruments TPA3116D2 Manuel utilisateur

Texas Instruments

Texas Instruments LMP7731 Manuel utilisateur

Texas Instruments

Texas Instruments THS4271EVM-UG Manuel utilisateur

Texas Instruments

Texas Instruments THS4031 Manuel utilisateur

Texas Instruments

Texas Instruments TPA3001D1EVM Manuel utilisateur

Texas Instruments

Texas Instruments LM833 Instructions d'utilisation et d'entretien

Texas Instruments

Texas Instruments TPA2018D1YZFEVM Manuel utilisateur

Texas Instruments

Texas Instruments TAS5601 Manuel utilisateur

Texas Instruments

Texas Instruments TPA301 Manuel utilisateur

Texas Instruments

Texas Instruments 2004 Manuel utilisateur

Texas Instruments

Texas Instruments LM3886 Overture Manuel utilisateur

Texas Instruments

Texas Instruments TPA3005D2EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPA0233 Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Sony

Sony XM-S400D Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur
