Brief instructions

en

testo 875i ·Thermal imager

Contact

GREAT BRITAIN / IRELAND

Testo Ltd.

Alton, Hampshire GU34 2QJ

Tel. (14 20) 54 44 33, Fax (14 20) 54 44

E-mail: [email protected]

USA

Testo Inc.

Flanders, NJ. 07836

Tel. (973) 2 52 17 20, Fax (973) 2 52 17 29

E-mail: [email protected]

AUSTRALIA

Testo Pty Ltd

Croydon South VIC 3136

Tel. (3) 98 00 46 77, Fax (3) 98 00 46 99

E-mail: [email protected]

The most up-to-date address details of our subsidiaries and

agencies can be found in Internet at: www.testo.com

Changing assignment of the quick

select buttons

Change the left or right quick select button:

1Call up: Move Joystick ➀to the left or right.

2Navigate: Move Joystick up / down.

3Confirm: Press [OK] ➀.

or

Cancel: Press [Esc] ➁.

Getting to know the quick select

buttons

Using the quick select buttons, the set functions are

called up directly. Factory settings:

Left quick select button ➀: Adjust scaling.

Right quick select button ➁: Select image type.

Warning! Eye damage due to laser beam.

Do not look into the laser beam and do not point

the laser beam at people.

0971 8754 en 02 en

➀

➁

Scale… Image type

➀

➁

Image type

Palette

Emissivity...

Scale...

Adjustment

These short instructions

describe the basic operating

steps. Please refer to the

instruction manual to find out

how to handle the product

safely and for detailed

information.

You can find this at

www.testo.com in the

Downloads section of the

relevant product detail page.

Analysis software testo IRSoft

Use the testo IRSoft software to analyze your thermal images extensively and in

detail, and to create professional reports.

You can download the software free of charge and licence-free via the following

link:

www.testo.com/irsoft

All manuals and user guides at all-guides.com

all-guides.com

Recording the image

1Freeze image: Press trigger button ➁once.

2Save image: Press trigger button again.

or

Discard image: Press [Esc] ➀.

Getting to know the menu

1Open menu: Press [OK] ➀.

2Navigate: Move Joystick ➀up / down.

3Open submenu (only for menu points marked

with ): Move joystick to the right.

4Call up a function: Press [OK].

or

Exit menu: Press [Esc] ➁.

Focusing the picture

Turn lens ➀by hand.

Switching on / off

Remove protection cap ➀from the lens.

Switch on: Press [ ] ➁.

- The measurement view is opened after the warm-

up period.

- The thermal imager performs an automatic

zeroing approx. every 60 sec. This can be

recognized by a “click”. The image is frozen

briefly when this occurs.

Switch off: Press [ ] again.

➆

➅

➂

➃

Apply

➄

➁

➀

➀

➁

➀

➀

➁

Measurement

Image gallery

Scale...

Display...

Emissivity...

Palette

Configuration

Commissioning

1Push the rechargeable battery ➀all the way

into the rechargeable battery slot until this is flush

with the bottom of the handle.

- The thermal imager starts automatically.

2Remove protective film from the display ➁.

- Instrument language (Language) and temperature

unit (Unit) can be set:

3Move Joystick ➂up / down to select the desired

option.

4Press [OK] ➂.

5Move Joystick up / down to change the setting.

6Press [OK].

7Press [Apply] ➃function key to apply the

settings.

8Press []➄ to switch off the thermal imager.

9Connect mains unit ()➅.

10 Completely charge battery (3 hours).

11 Insert Memory card in the card slot (SD) ➆.

- The camera is now ready for operation.

➀

➁
