Tesla HS300WX Manuel utilisateur

CORDLESS VACUUM CLEANER

HS300WX

User Manual

ENG HRBG GRBIH/CG HU MK RO SLO SRB

INSTRUCTION MANUAL

READ ALL INSTRUCTIONS BEFORE USING YOUR

VACUUM CLEANER.

WARNING!

To reduce the risk of ﬁre, electrical shock, or injury

1. Do not use outdoors or on wet surfaces

2. Do not allow to be used as a toy. Close attention is

necessary when used by or near children.

3. Use only as described in this manual. Use only

manufacturer’s recommended attachments.

4. Do not use vacuum if it has been dropped, damaged,

left outdoors, or dropped in water. Return it to an

authorized service center.

5. Do not handle plug or appliance with wet hands.

6. Do not put any object into openings. Do not use with

any opening blocked; keep free of dust, lint, hair and

anything that may reduce air ﬂow.

7. Keep hair, loose clothing, ﬁngers, and all parts of body

away from openings and moving parts.

8. Do not pick up anything that is burning or smoking,

such as cigarettes, matches, or got ashes.

9. Use extra care when cleaning on stairs.

10. Do not use to pick up ﬂammable or combustible

liquids such as gasoline or use in areas where they may

be present.

11. Look on your vacuum and follow all label and marking

instructions.

12. Keep end of hose, wands and other openings away

from your face and body.

13. Do not use the vacuum cleaner without dust cup ﬁlter

in place.

14. Always unplug this appliance before connecting or

disconnecting vacuum hose.

15. Store the vacuum indoors. Put the vacuum away after

us to prevent tripping accidents.

16. Use the incorrect battery will damage motor and users.

Please use the recommended batteries.

17. Use only on dry, indoor surfaces.

18. Do not use for any purpose other than described in this

user’s guide.

19. If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualiﬁed

persons in order to avoid a hazard.

Household Use only.

Read this instruction manual carefully before using.

ENG

IMPORTANT SAFETY INSTRUCTION

Plastic Centering

Filter System

Dust Cup

Dust Cup Bottom

1. Motorized Floor Brush head

2. Aluminum tube

3. Tube release button

4. Dust cup release button

5. LED lamp

6. Power switch

7. Battery pack release button

8. Battery Pack

9. Dust cup

10. Dust cup bottom

11. 2in1 crevice nozzle

12. Connecting joint

13. Adapter

14. Blowing

15. Filter set

PARTS DESCRIPTION

PRECAUTIONARY MEASURES

If the opening that sucks in the air, the brush or extension tubes are blocked, you should switch off the vacuum cleaner at

once. First clear the blocked substance before you attempt to start the vacuum cleaner again.

1. Do not operate the vacuum cleaner too close to heaters

and like radiators, cigarette butts etc.

2. Before you start using the vacuum cleaner,please remove

large or sharp objects from the ﬂoor in order to prevent

that the ﬁlter is damaged. Do not use the vacuum to clean

anything that is easy to burning, such as gas and cigarettes.

ASSEMBLING THE VACUUM CLEANER WITH

ACCESSORIES

Install the ﬂoor brush head:

The ﬂoor brush head is suitable for all ﬂoors.

Floor brush head connected directly to the vacuum

cleaner body unit until you hear a audible clicking

noise.

Floor brush head connected with the aluminum tube

until you hear a audible clicking noise.

Disassemble the ﬂoor brush head:

Press the tube release button, then remove the

aluminum tube and ﬂoor brush head.

Install the 2in1 crevice nozzle:

The crevice nozzle is suitable for narrow gaps

cleaning and for using on upholstered surface

cleaning.

Insert the 2 in 1 crevice nozzle into the connecting

joint, then insert the connecting joint to the vacuum

cleaner body unit.

The brush on the crevice nozzle can be pulled

forwards or backwards as need.

Install the blowing device.

The blowing device is used for the blowing function.

The blower function is recommended for use to

gather scattered dry waste such as dust, leaves and

confetti or any new ideas from you.

Insert the blowing device into the vacuum cleaner

body.

You can adjust the blowing direction and blowing

force by adjusting the blowing tube direction and

vacuum cleaner power speed.

Install the extension aluminum tube

Floor brush head connected with aluminum tube for

use to clean the hard ﬂoor or carpet.

2in1 crevice nozzle Connected with aluminum tube

for use to clean the high places such as ceiling,

curtain, and etc.

USE THE VACUUM CLEANER

CHARGE THE VACUUM CLEANER

Install the battery pack:

Slide the battery pack onto the body block

until you hear and feel it click into the place.

Switch the vacuum cleaner on or off:

To switch it on, press the power switch, button, the vacuum

cleaner is ON, and LED light is lighting up. If you need the high

suction for cleaning, press the high mode button.

To switch if off, press the power switch button, the vacuum

cleaner is OFF

The vacuum cleaner must be switched off for charging.

The rechargeable battery is not fully charged upon delivery.

To reach the maximum charging capacity, charge the

appliance up fully before using it for the ﬁrst time.

Charging the product:

Plug the adapter plug into the connection socket on the rear

side of the vacuum cleaner.

The LED indicator light ﬂashes one by one while it is

charging.

Once all the indicator light up, the battery is fully charged.

CLEAN THE VACUUM CLEANER

Filter Assembly

(Plastic Centering

Filter System)

Fig. B

Drop dust:

Push the dust cup bottom release button, then the dust will fall down automatically. Usually you may only do like this to drop

the dust. (ﬁg. A)

Clean the dust cup:

Press the dust cup release button, then remove the dust cup from body.

Press the dust cup cover (for air exhaust) release button, take out the ﬁlter assembly out of the dust cup, then you can clean

them with soft brush or wash them with water. You should dry them completely before you use again. (ﬁg.B).

Assemble the dust cup back after cleaning:

Connect the dust cup set to the body you hear a audible clicking noise. The dust cup will be locked.(pleases pay attention to

the ﬁtting position and direction).

Clean the ﬁlter

Take out the ﬁlter set. (ﬁg. A)

Clean the ﬁlter by soft brush or rinse it in water and dry them

completely before use again. All the ﬁlters are washable. (we

recommend you to clean the ﬁlters when feeling the suction power

becoming weak.) (ﬁg.B)

Note: The above ﬁlters should be equipped in correct places when

work the vacuum machine

Clean the ﬂoor brush head

Remove the ﬂoor brush head from the vacuum cleaner by pressing

the release button.

Slide the locking button slightly.

Take out the brush roller by hand.

If necessary, carefully remove dirt/hair with a pair of scissors.

If need be, the brush roller can be washed. Let it dry completely

before inserting it again.

Push

Fig. A

Fig. A Fig. B

Sponge and

HEPA Filter

REMOVE THE BATTERY PACK

TROUBLESHOOTING GUIDE

Press the battery pack releasing button and pull the battery out.

PROBLEM POSSIBLE REASON POSSIBLE SOLUTION

Machine doesn't work The battery may be no electricity Check the battery for electric or

change the battery.

The machine can't suck ash or

suction is very weak

1. The DUST CUP may be full

2. Lack of battery power

1. Empty dust cup (pic 7).

2. Connect the charger.

Dust escaping from vacuum 1. Dust cup is full.

2. The dust ﬁlter dust cup or cup bottom

there may not be assembled

1. Empty dust cup .

2. Check to see if the dust at the

bottom of the cup lock button

Vacuum brushes will not pick-up Dust cup is full. Empty and clean dust cup container.

Disposal

Do not Dispose of batteries with house-hold waste!

Batteries and packaging should be sorted for environmentally friendly recycling.

Only for EU countries:

according to the Directive 2006/66/EC, defective or used batteries,must be collectes separately and disposed of

in an environmentally correct manner.

TECHNICAL SPECIFICATION

Power motor: 200W

Operating speeds : 2

Power supply: Battery 2200mAh

Battery format: Battery pack

Voltage 18,5V

UPUTSTVO ZA UPOTREBU

Kada koristite električni aparat, uvijek treba poštovati

osnovne mjere predostrožnosti, uključujući sljedeće

PROČITAJTE SVA UPUTSTVA PRIJE KORIŠTENJA

USISIVAČA.

UPOZORENJE!

Da biste smanjili rizik od požara, električnog udara ili

povreda.

1. Ne koristite na otvorenom ili na mokrim površinama

2. Ne dozvolite da se koristi kao igračka. Potrebna je

velika pažnja kada je koriste djeca ili ako su djeca u

njihovoj blizini.

3. Koristite samo onako kako je opisano u ovom uputstvu.

Koristite samo dodatke koje preporučuje proizvođač.

4. Ne koristite usisivač ako je pao, oštećen, ostavljen

na otvorenom ili je pao u vodu. Vratite ga u ovlašteni

servisni centar.

5. Ne rukujte utikačem ili uređajem mokrim rukama.

6. Ne stavljajte nikakve predmete u otvore. Ne koristiti

sa blokiranim otvorima; čuvajte prašine, dlaka, kose i

svega što može smanjiti protok zraka.

7. Držite kosu, široku odjeću, prste i sve dijelove tijela

dalje od otvora i pokretnih dijelova.

8. Ne uzimajte u ruke ništa što gori ili puši, poput cigareta,

šibica ili pepela.

9. Budite posebno pažljivi prilikom čišćenja na

stepenicama.

10. Ne koristite za sakupljanje zapaljivih tečnosti kao što je

benzin…..

11. Pogledajte svoj usisivač i slijedite sva uputstva za

etikete i obilježavanje.

12. Držite kraj crijeva, cijevi i drugih otvora dalje od lica i

tijela.

13. Ne koristite usisivač bez postavljenog ﬁltera za prašinu.

14. Uvijek isključite ovaj uređaj iz struje prije povezivanja ili

otvaranja usisnog crijeva.

15. Čuvajte usisivač u zatvorenom. Sklonite usisavač za

vama kako biste spriječili nezgode spoticanja.

16. Upotreba neispravne baterije oštetiće motor i korisnike.

Koristite preporučene baterije.

17. Koristite samo na suhim, zatvorenim površinama.

18. Ne koristite u bilo koje druge svrhe osim opisanih u

ovom korisničkom vodiču.

19. Ako je kabal za napajanje oštećen, proizvođač, serviser

ili kvaliﬁkovana osoba mora ga zamijeniti kako bi se

izbjegla opasnost.

Samo za domaćinstvo.

Prije upotrebe pažljivo pročitajte uputstvo za upotrebu.

BiH/CG

VAŽNA SIGURNOSNA UPUTSTVA

Plastični centar

Sistem Filtera

Posuda za prašinu

Dno posude za prašinu

1. Papučica sa motornom četkom

2. Aluminijumsk cijev

3. Dugme za otpuštanje cijevi

4. Dugme za skidanje posude za prašinu

5. LED lampa

6. Dugme za paljenje

7. Dugme za skidanje baterije

8. Baterija

9. Posuda za prašinu

10. Dno posude za prašinu

11. 2 u 1 dodatak

12. Dodataka za spajanje

13. Adapter

14. Dodatak za puhanje

15. Set ﬁltera

OPIS DIJELOVA

MJERE PREDOSTROŽNOSTI

Ako je otvor koji usisava zrak, četka ili produžne cijevi začepljen, usisivač treba odmah isključiti. Prvo očistite blokiranu

supstancu prije nego što ponovo pokušate da pokrenete usisivač

1. Ne koristite usisivač preblizu grijačima i poput radijatora,

opušaka itd.

2. Prije nego što počnete da koristite usisivač, uklonite velike

ili oštre predmete sa poda kako biste spriječili oštećenje

ﬁltera. Ne koristite usisivač da očistite sve što je lako

zapaljivo, kao što su gorivo i cigarete.

Table des matières

Langues :

Autres manuels Tesla Aspirateur

Tesla

Tesla PureStar E60 Manuel utilisateur

Tesla

Tesla RoboStar iQ300 Manuel utilisateur

Tesla

Tesla PureStar E70 Aqua Pro Manuel utilisateur

Tesla

Tesla RoboStar T10 Manuel utilisateur

Tesla

Tesla RoboStar iQ300 Manuel utilisateur

Tesla

Tesla AeroStar T500 Manuel utilisateur

Tesla

Tesla RoboStar iQ300 Manuel utilisateur

Tesla

Tesla RoboStar T50 Manuel utilisateur

Tesla

Tesla Cyclone High POWER BGL201BR Manuel utilisateur

Tesla

Tesla AquaStar AQ500 Manuel utilisateur

Tesla

Tesla RoboStar T60 Manuel utilisateur

Tesla

Tesla SILENT PRO BG400W Manuel utilisateur

Tesla

Tesla Ultimate Silent PRO BG600G Manuel utilisateur

Tesla

Tesla PureStar E20 Manuel utilisateur

Tesla

Tesla BGL202BGE Manuel utilisateur

Tesla

Tesla RoboStar iQ600 Manuel utilisateur

Tesla

Tesla RoboStar W20 Manuel utilisateur

Tesla

Tesla LASER AI300 PLUS Manuel utilisateur

Tesla

Tesla HS500GF PRO FLEX Manuel utilisateur

Tesla

Tesla RoboStar iQ100 Manuel utilisateur

Tesla

Tesla RoboStar T30 Manuel utilisateur

Tesla

Tesla AeroStar T700 Manuel utilisateur

Tesla

Tesla HS301WX Manuel utilisateur

Tesla

Tesla Cyclone Silent PRO BGL400BR Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
