User Manual
Version V1.0-20210714
Tersus TC50 Controller
User Manual
©2021 Tersus GNSS Inc. All rights reserved.
More details, please visit www.tersus-gnss.com
User Manual for Tersus TC50 Controller v1.0
1
Revision History
Version
Revision Date
Change summary
1.0
20210714
Initial Release
User Manual for Tersus TC50 Controller v1.0
2
Table of Content
Revision History....................................................................................................................... 1
Table of Content.......................................................................................................................2
List of Figures........................................................................................................................... 3
List of Tables.............................................................................................................................4
1. Introduction...........................................................................................................................5
1.1 Overview......................................................................................................................... 5
1.2 Specification...................................................................................................................6
1.3 Accessories of TC50 Controller.................................................................................. 8
2. General Operation.............................................................................................................10
2.1 Starting to use TC50 Controller................................................................................ 10
2.2 Charge the battery...................................................................................................... 10
2.3 Insert SIM card and SD card.....................................................................................11
2.4 Using of Touch Screen...............................................................................................12
2.5 Home Screen operations........................................................................................... 13
2.6 Extend battery life....................................................................................................... 26
2.7 Firmware Upgrade...................................................................................................... 26
2.8 Cautions........................................................................................................................34
3. Terminology........................................................................................................................35
User Manual for Tersus TC50 Controller v1.0
3
List of Figures
Figure 1.1 TC50 controller................................................................................. 5
Figure 1.2 TC50 outlook.....................................................................................7
Figure 1.3 TC50 Lithium Battery.......................................................................8
Figure 1.4 TC50 Charger................................................................................... 8
Figure 1.5 Type-C Cable.................................................................................... 9
Figure 2.1 Insert SIM card and SD card........................................................ 11
Figure 2.2 Home screen.................................................................................. 13
Figure 2.3 Main screen.................................................................................... 14
Figure 2.4 List of applications......................................................................... 15
Figure 2.5 Choose the applications or widgets to be added......................15
Figure 2.6 Drag the icon to the area.............................................................. 16
Figure 2.7 Release hand and icon is added................................................. 16
Figure 2.8 Tap the icon to be deleted............................................................ 17
Figure 2.9 Hold and drag the icon..................................................................17
Figure 2.10 The object becomes gray........................................................... 18
Figure 2.11 The shortcut is deleted................................................................18
Figure 2.12 Home screen................................................................................ 19
Figure 2.13 Wallpapers & Widgets & Home Settings..................................20
Figure 2.14 Select wallpapers from various resources...............................20
Figure 2.15 Locked home screen...................................................................21
Figure 2.16 Slide up..........................................................................................21
Figure 2.17 Unlocked home screen............................................................... 22
Figure 2.18 Status bar on the screen............................................................ 23
Figure 2.19 Message board............................................................................ 23
Figure 2.20 Settings interface......................................................................... 24
Figure 2.21 Recently used applications........................................................ 25
User Manual for Tersus TC50 Controller v1.0
4
Figure 2.22 Flash tool interface...................................................................... 27
Figure 2.23 Prompt........................................................................................... 28
Figure 2.24 Select file for Download Agent...................................................28
Figure 2.25 Load Scatter file........................................................................... 29
Figure 2.26 Select Firmware Upgrade mode................................................29
Figure 2.27 Click Download button................................................................ 30
Figure 2.28 Upgrading is ready to start......................................................... 30
Figure 2.29 Upgrading in progress.................................................................31
Figure 2.30 Upgrading is completed.............................................................. 31
Figure 2.31 Download port is recognized in the Computer Management33
List of Tables
Table 1 TC50 technical specification................................................................6
User Manual for Tersus TC50 Controller v1.0
5
1. Introduction
This chapter mainly introduces the overview and specification of the Tersus
TC50 Controller.
1.1 Overview
The Tersus TC50 Controller is a rugged multi-functional data controller with
design of 5 inch sunlight readable HD touch screen and an alphanumerical
keypad. Equipped with powerful processor and android operating system, it is
perfect to adapt with Tersus survey software. With professional IP68 rating, it is
robust and reliable for harsh operating conditions. The large capacity lithium
battery guarantees more than 10 hours of field working for a whole day of
multiple surveying tasks.
Figure 1.1 TC50 controller
User Manual for Tersus TC50 Controller v1.0
6
1.2 Specification
Table 1 TC50 technical specification
System
Operating System
Android 8.1
CPU
MT6763 Octa-Core 2.0GHz
Memory
4GB RAM + 64GB ROM
External storage
Micro SD, up to 128GB
Display
5“ sunlight-readable capacitive touch screen
Resolution
720x1280
Camera
5MP front, 13MP rear
Flash Light
High light Flash LED
Electrical
Battery
7000mAh 3.8V
Battery Life
14 hours
Charging Time
<4 hours (fast charge)
Communication
Wi-Fi
IEEE 802.11a/b/g/n 2.4G&5G
Cellular Mode
Dual SIM Dual Standby
SIM1 & SIM2
FDD-LTE B1/B3/B5/B7/B8
TD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
CDMA1x/CDMA2000 BC0/BC1
GSM B2/B3/B5/B8
Bluetooth
BT4.1 (BLE)
USB
USB Type-C (supports OTG)
NFC
Protocol of ISO14443A/B, and ISO15693
Readable Distance 0~5cm
User Manual for Tersus TC50 Controller v1.0
7
GNSS
GPS/GLONASS/BeiDou
Physical
Dimension
207mmx84mmx20mm
Weight
370g (include battery)
Reliability
Operating Temperature
-20C ~ +55C
Storage Temperature
-30C ~ +70C
Humidity
5% ~ 95%
Dustproof & Waterproof
IP68
Shock
1.5m drop onto concrete
Figure 1.2 TC50 outlook
User Manual for Tersus TC50 Controller v1.0
8
1.3 Accessories of TC50 Controller
The accessories of TC50 Controller are listed below.
TC50 Lithium Battery (3.8V/7000mAh)
Figure 1.3 TC50 Lithium Battery
TC50 Charger (5V/1.67A, 7V/1.67A, 9V/1.67A)
Figure 1.4 TC50 Charger
User Manual for Tersus TC50 Controller v1.0
9
Type-C Cable
Figure 1.5 Type-C Cable
Functions: 1. Connect to the USB port of computer for data downloading;
2. Connect to the charger to charge TC50 controller.
