TERK Technologies FDTV2 Manuel utilisateur

FDTV2

Owner’s Manual

FDTV2 Flat Antenna

Indoor Television Antenna

FDTV2

About Your TERK

FDTV2 Flat Antenna

Thank you for choosing the TERK FDTV2. TERK

antennas are designed to deliver sharp, clear

reception of digital signals. At TERK, our engineering

department is dedicated to designing antennas that

enhance both the latest technology and the aesthetics

of any viewing environment. The FDTV2 installs in

minutes and is easy to use. The FDTV2 has a patented

design that lets it receive signals from 360-degrees

and work in both the horizontal and vertical planes,

which means it requires virtually no adjustments once

you’ve put it in place.

Before using your antenna, please remove all parts

from the box and read this owner’s manual carefully.

The FDTV2 antenna package includes the following

items:

1 FDTV2 Antenna Pro with Built-In Coaxial Cable

1 Removable Stand

FDTV2

Installing your FDTV2

antenna

Find the best location for the Antenna

Before you connect the antenna, determine the best

spot in your home for optimum reception. Visit

www.antennaweb.org to see where your local

broadcasts are coming from. Then, try as much

as possible to avoid obstructions between these

transmitters and your antenna.

Positioning the Antenna

Once you’ve found the best place to set up your

antenna, you have three options for placing it—you

can lay it flat, hang it on the wall, or stand it upright.

The antenna is designed to perform equally well in all

three positions. For most settings, the recommended

position is standing. However, the best position for

your antenna may vary depending on your location

and setting. Television signal waves bounce off of

objects, causing signal reflections that might cause

the antenna to perform better in one location or

orientation over others. Test the antenna in the

different positions before putting it in its permanent

position.

Please Note: Do not place your FDTV2 near large

metal objects or appliances that could create

interference.

FDTV2

Installation (continued)

Attaching the Stand

The provided stand attaches to the back of the FDTV2

for standing the antenna upright.

To attach the FDTV2 stand:

1. Line the pegs on the stand with the slots on the

back of the antenna.

2. Insert the pegs in the slots and pull up to lock the

stand into place.

FDTV2

Installation (continued)

Connecting the FDTV2

You can connect the FDTV2 directly to your TV or use

it with a converter box or other tuning device with an

antenna input (such as a cable box or satellite receiver).

FDTV2 Built-In

Coaxial Cable

1. Make sure your TV is turned off.

2. Connect the FDTV2’s built-in

coaxial cable to the antenna input

on your TV.

3. Run your TV’s tuner/channel

setup to scan for available

broadcast channels.

To connect the FDTV2 directly to your TV:

FDTV2

Installation (continued)

1. Make sure your converter box

is turned off.

2. Connect the FDTV2’s built-in

cable to the antenna input on

the converter box.

3. Follow the directions in the

manual that came with your

converter box to connect it to

your TV.

4. Run your converter box’s setup

routine to scan for available

broadcast channels.

FDTV2 Built-In

Coaxial Cable

Coaxial

Cable

Audio/Video

Cables

Converter Box

–or–

To connect the FDTV2 to a converter box:

Note about digital channels

To display digital signals on your TV, you’ll need

to have the right equipment: either a TV that is

capable of decoding digital signals or a digital

converter box.

FDTV2

Troubleshooting

I have a cable ready TV. Why am I not getting any channels

above 13?

The tuners inside of cable ready TVs have two modes. One

mode is for cable and the other mode is for antenna. When

the TV is in cable mode, and you are using an antenna, you

will not be able to receive any channels above 13. To fix this,

simply access the menu of your TV and switch the TV from

Cable/CATV mode to ANT/AIR mode.

I have my TV in a metal cabinet. Will the antenna work for me?

Large metal objects may prevent the antenna signal from

reaching the antenna. Try placing the antenna outside of or

above the metal cabinet. If you decide to keep the FDTV2 on a

metal cabinet, use it in the upright position.

My home has aluminum siding/insulation. Where should I

place my antenna?

If you observe poor performance, place the antenna near a

window to minimize interference and improve your reception.

Can I use my antenna in a basement?

TV signals usually cannot penetrate into basement locations

due to their lower elevation.

Please Note: Other variables, which are not related to

antenna performance, can effect your reception. These

include distance from the source transmitting the desired

station, and man-made and natural conditions. Example:

Obstacles such as buildings between the transmitting source

and your antenna.

12 Month Limited Warranty

Audiovox Electronics Corporation (the “Company”) warrants to the original retail purchaser of this

product that should this product or any part thereof, under normal use and conditions, be proven

defective in material or workmanship within 12 months from the date of original purchase, such

defect(s) will be repaired or replaced (at the Company’s option) without charge for parts and repair

labor. To obtain repair or replacement within the terms of this Warranty, the product along with any

accessories included in the original packaging is to be delivered with proof of warranty coverage (e.g.

dated bill of sale), specification of defects(s), transportation prepaid, to the Company at the address

shown below. Do not return this product to the Retailer.

This Warranty is not transferable and does not cover product purchased, service or used outside

the United States or Canada. The Warranty does not extend to the elimination of externally

generated static or noise. This Warranty does not apply to costs incurred for installation, removal or

reinstallation of the product, or, if in the Company’s opinion, the product has been damaged through

acts of nature, alteration, improper installation, mishandling, misuse, neglect, or accident. This

Warranty does not cover damage caused by an AC adapter not provided with the product.

THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR

OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY

EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT. This Warranty is in lieu

of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED

WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED

TO DURATION OF THIS WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER,

INCLUDING ANY IMPLIED WARRANT, MUST BE BROUGHT WITHIN A PERIOD OF 24 MONTHS

FROM THE DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR

ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. No person or representative is

authorized to assume for the Company any liability other than expressed herein in connection with

the sale of this product.

Some states/provinces do not allow limitations on how long an implied warranty lasts or the

exclusion or limitation of incidental or consequential damage so the above limitations or exclusions

may not apply to you. This Warranty gives you specific legal rights and you may also have other rights

which vary from state/province to state/ province.

U.S.A.: Audiovox Electronics Corporation, 150 Marcus Blvd., Hauppauge, NY 11788

CANADA: Audiovox Return Center, c/o Genco, 6685 Kennedy Road, Unit 3, Door 16, Mississauga,

Ontario L5T 3A5

For Customer Service

Visit Our Website At

www.audiovox.com

Product Information, Photos,

FAQ’s, Owner’s Manuals

For customer service and

technical information::1.800.290.6650

FDTV2 US IB 00
