TELIKOU Intercom System

TM-800 with Tally Main Station

Instruction Manual

TELIKOU TM-800 with Tally Eight Channel Main Station

I. Introduction

Thank you for choosing TELIKOU intercom product. TM-800 with Tally main station is suitable for

television station, communication center, UB truck, live performance and any other environment

which requires communication. We recommend you read through this manual to better understand

the functions of TM-800 with Tally.

This system adopts wired connection, and has following features, free of external emission

interference, stable and reliable performance, flexible configuration, full-duplex communication,

clear and loud communication sound, easy operation, and strong noise resistance.

II. Characteristics

Remote Microphone Kill Switch (RMK).

IFB function.

Announcement output

Controllable background input

Automatic circuit short protection and indication.

Supports Tally Input

Supports Dynamic and Electret Gooseneck Microphone

III. Basic operations

Front Panel

1. Panel Microphone Connector

Ø6.35mm microphone jack can be used as unbalanced Dynamic or Electret microphone.

Pin definition is as follow:

TELIKOU TM-800 with Tally Eight Channel Main Station

TRS

S --- Shield

R --- Common

T --- Microphone Hot

2. Headset connector

4-pin XLR Male or 5-pin XLR Female

Earphone: Dynamic 8-300 ohm

Microphone: Dynamic 200 ohm

The wiring of headset is as follow:

Pin 1 -- Microphone Common

Pin 2 -- Microphone Hot

Pin 3 -- Earphone -

Pin 4 -- Earphone +

Pin 5 -- Null

3. Mic Select Switch

Mic select switch is used to select panel microphone or headset microphone.

4. Announcement Button (ANN)

When this button is pressed on, microphone signal is sent to ANN. Out connector at rear panel.

5. Call Button

Before use call function, please turn on the channel which want to talk. Turn up or down the call

switch handle will sent a call signal to all the connected channels. The call LED above lights red.

This switch is without self-locking function, release and reset.

6. TALK / IFB Button

These buttons are involved with DIP-switch which is at rear panel.

A) When DIP10 is OFF

The function of channel 5-8 is same as channel 1-4. When any channel TALK button is

pressed, the button lights green color.

B) When DIP10 is ON

TELIKOU TM-800 with Tally Eight Channel Main Station

IFB function is activated. Channels 5-8 become four IFB channels. Any channel TALK

button of 5-8 is pressed ON, the channel 1-4 are turned off automatically, also background

input. Only microphone signal is sent to the channel.

The working mode for TALK / IFB Button:

PTT: Hold the button, the channel is connected, release the button, the channel is cut off;

LATCH: Quick single press the button in 200ms, the channel is latched on. Press button again,

the channel is cut off.

7. TALK Button

Press channel TALK button, the microphone signal is sent to corresponding channel. The

button lights GREEN.

The working mode for TALK Button:

PTT: Hold the button, the channel is connected, release the button, the channel is cut off;

LATCH: Quick single press the button in 200ms, the channel is latched on. Press button again,

the channel is cut off.

8. Program Feed

Turn the switch up or down will send the external input signal to intercom channel.

ON: Activated channel always receives external program signal.

OFF: External program signal can not be sent into system.

INT: Activated channel receives external program signal. Activated channel receives

external program signal. It will be interrupted when microphone is turned on.

9. Program Feed LED

This LED lights when Program Feed function works.

10. Program Level Control

Adjust program audio level which goes into TM-800 with Tally, by clockwise or

counterclockwise direction.

11. Power

Power switch

12. Power LED

This green LED constantly lights on when power supply working properly. If TM-800 with Tally

has any circuit short problem, it will keep on flashing until the problem has been solved.

TELIKOU TM-800 with Tally Eight Channel Main Station

13. Tone Alert Level Control

When TM-800 with Tally receives external call signal, the internal buzzer will sent a hum to

panel speaker and earphone. This knob adjusts the hum level.

14. Program Listen Level Control

This knob is used to adjust the volume level of background program level which heard from

earphone and speaker.

15. Remote Mic Kill Switch

Microphone on belt pack may forget to be turned off by operators. Noise will disturb the whole

intercom system.

The Remote Microphone Kill (RMK) switch will turn off the microphone of every beltpack

remotely. If the Talk Functions of a large number of beltpacks have inadvertently been left

activated, incidental noise and talking can make it difficult or impossible to communicate on the

intercom system. The Remote Microphone Kill switch can be pressed to quiet the line in this

situation.

16. Listen Level Control

This control is to set the listening level of audio signal in headset or panel speaker. Turn the

control on counterclockwise completely will silence the channel.

17. Sidetone zero-adjusting

The TM-800 with Tally uses full-duplex audio in which the talk and listen audio are sent and

received on the same line. Thus, when you talk on a channel, you will also here your own voice

back in the speaker or earphone. This is called sidetone. Sidetone could cause unwanted

feedback, since the microphone may pick up your returned voice audio and re-amplify it. In

either of these cases, you should minimize the amount of sidetone.

Typically, different sidetone null settings are needed depending upon whether you are using the

gooseneck panel microphone along with the speaker or not. Use one the following procedures

to correctly set the sidetone level controls.

A) Sidetone Adjustment Procedure for Gooseneck Microphone with Speaker turned on:

1 Turn on the Mic switch. Set Mic select switch to panel.

2 Turn the level control to a comfortable level.

3 Speak into the microphone while turning the sidetone null control slowly back and forth. There

should be a point where your voice (and any accompanying acoustic feedback) is the lowest.

This is the null point.

TELIKOU TM-800 with Tally Eight Channel Main Station

B) Sidetone Adjustment Procedure for Headset:

1 Turn on the Mic switch. Set Mic select switch to headset.

2 Turn the level control to a comfortable level by having someone talk to you from another

station.

3 Speak into the microphone while turning the sidetone null control slowly back and forth. There

should be a point where your voice (and any accompanying acoustic feedback) is the lowest.

This is the null point.

C) System Sidetone Adjustment

1 Turn off all the microphones on sub-stations and belt packs.

2 Followed by A) and B), adjust sidetone on TM-800 with Tally main station.

3 Turn on the microphone on sub-station and belt packs one by one, and then adjust the

Sidetone to satisfied level.

The different cable length effects the result.

Please reference the following table, to have proper DIP 11 and DIP 12 setting.

18. Panel Mic Gain

It is used to adjust panel microphone gain to achieve proper microphone output level. It does

not affect headset microphone’s sensitivity.

The gain has pre-set as electrets microphone as default. If panel microphone is changed,

please re-adjust panel Mic. gain.

19. AC Power Connection and Power Switch

Input 90V-260V, 50-60Hz AC, and the power consumption is less than 45VA.

20. Termination switch

When this switch is turned to ON position, one 300ohm termination resistor will be connected to

intercom line. If the intercom system is not terminated, the level of intercom line will be too high,

and the system stability will be influenced. However, only one termination point is allowed within

same intercom line. If multiple termination points are used incorrectly, the driving load will be

aggravated, and the level of intercom line will be too low.

This switch is set to ON position by factory default. Before using, you should set it to ON or OFF

Cable Length

<100m

100-200m

200-400m

>400m

DP11

OFF

DP12

OFF

TELIKOU TM-800 with Tally Eight Channel Main Station

position according to the actual connection of intercom line.

21. Channel 1-4 Intercom Line connector

Four 5-pin XLR male sockets corresponding to 1-4 channels; The pin-out of the intercom

connectors is as follows:

Pin 1 --- Common (Shield)

Pin 2 --- Power (+24 VDC)

Pin 3 --- Audio

Pin 4 --- Green Tally Signal

Pin 5 --- Red Tally Signal

22. Channel 5-8 Intercom Line connector and IFB Output

5-pin XLR male socket, The pin-out of the intercom connectors is as follows:

Pin 1 --- Common (Shield)

Pin 2 --- Power (+24 VDC)

Pin 3 --- Audio

Pin 4 --- Green Tally Signal

Pin 5 --- Red Tally Signal

23. Function DIP Setting

12 digits dipper has following settings:

DIP1 - DIP8 (Program Feed into):

On: Enable background program signal sent to Intercom channel

Off: Disable background program signal sent to Intercom channel

DIP9 (Call on Talk)

On: Enable auto call function. When Talk switch is turned on, it automatic sent a call signal

to Intercom channel

Off: Disable auto call function.

DIP10 (IFB Enable):

On: Enable IFB function. Channel 5-8 become IFB channel. If talk button of any IFB channel

is turned on, channel 1-4 will be turned off automatic. Microphone signal is only sent to

the IFB channel which is turned on.

Off: Disable IFB function.

DIP11 (Long line1)

On: Sidetone compensate for long distance intercom line cable

Off: disable compensate (default)

DIP12(Long line2)

TELIKOU TM-800 with Tally Eight Channel Main Station

On: Sidetone compensate for long distance intercom line cable

Off: disable compensate (default)

24. Program Input

This connector is 3-pin XLR Female. Differential input: 1Vp-p.

The pinout is as follows:

Pin 1 --- Common (Shield)

Pin 2 --- + Audio

Pin 3 --- - Audio

25. Announce Out

This connector is 3-pin XLR male. Differential output: 1Vp-p.

The pinout is as follows:

Pin 1 --- Common (Shield)

Pin 2 --- +Audio

Pin 3 --- -Audio

26. Tally In 5-8

There are two DB9 connectors at rear panel to receive tally signal.

This DB9 connector is beside Channel 8 XLR connector.

It receives Green and Red Tally signal for Channel 5 to 8.

DB9 connector pin definition:

Pin 1 --- Green tally signal to channel 5

Pin 2 --- Red tally signal to channel 5

Pin 3 --- Green tally signal to channel 6

Pin 4 --- Red tally signal to channel 6

Pin 5 --- Green tally signal to channel 7

Pin 6 --- Red tally signal to channel 7

Pin 7 --- Green tally signal to channel 8

Pin 8 --- Red tally signal to channel 8

Pin 9 --- Common

27. Tally In 1-4

There are two DB9 connectors at rear panel to receive tally signal.

This DB9 connector is beside Channel 1 XLR connector.

It receives Green and Red Tally signal for Channel 1 to 4.

Cable Length

<100m

100-200m

200-400m

>400m

DP11

OFF

DP12

OFF

TELIKOU TM-800 with Tally Eight Channel Main Station

DB9 connector pin definition:

Pin 1 --- Green tally signal to channel 1

Pin 2 --- Red tally signal to channel 1

Pin 3 --- Green tally signal to channel 2

Pin 4 --- Red tally signal to channel 2

Pin 5 --- Green tally signal to channel 3

Pin 6 --- Red tally signal to channel 3

Pin 7 --- Green tally signal to channel 4

Pin 8 --- Red tally signal to channel 4

Pin 9 --- Common

IV. Installation and cable

1. Installation

TM-800 with Tally main workstation adopts 19-inches 1U cabinet, and this workstation can be

mounted on rack.

2. Intercom cable

A). Rules for cable selection

TELIKOU intercom 2-Wire systems adopts 2-core shielded audio cable, one core is used for

transmitting audio signal, another core is used for transmitting DC power or control signal, and the

shielded layer is used as common line for audio and power supply. To decrease resistance of

common line and crosstalk interference, the cable with larger cross section area should be used.

The cross section area of single line should be at least 0.75mm2. When the cable is longer, the

cross section area of cable should be larger. If the cable has more than 2 cores, it is recommended

to use the additional core as common line.

B). Cable connection

The TM-800 with Tally main station requires 5-pin XLR cable. If longer cable is required, you can

connect several cables together with head-end method.

The wiring of connector is as follows:

Pin 1 --- Common

Pin 2 --- Power DC

Pin 3 --- Audio Signal

Pin4 --- Tally Green Light Driving Signal

Pin5 --- Tally Red Light Driving Signal

Notice: the pin-1 GND connection for each XLR connector must be insulated from cabinet, and

cannot be connected to shell of XLR connector.

TELIKOU TM-800 with Tally Eight Channel Main Station

V Troubleshooting

Problem: Power LED wink

Cause 1: Direct short on the intercom channel

Solution 1: Remove all the intercom cables from TM-800 with Tally. Check each channel one by one,

until find the short channel.

Cause 2: Overload

Solution 2: Decrease the amount of remote stations.

Problem: System feedback (Acoustical)

Cause 1: Listen level control at this station or a remote station is set too high

Solution 1: Reduce the volume.

Cause 2: Sidetone null control at this station or a remote station is not adjusted correctly

Solution 2: Adjust sidetone again.

Cause 3: Channel un-terminated.

Solution 3: Set the TM-800 with Tally termination switch to the ON position.

Cause 3: A headset cord is too long or jointing quality.

Solution 3: Check headset cord

Problem: Excessive crosstalk

Cause 1: High DC resistance in ground return.

Solution 1: Use heavier cable; add additional conductor(s) to ground return.

Cause 2: Headset cables are not wired properly or shielded properly.

Solution 2: Correct wiring. Use headsets with properly shielded wiring.

Problem: Hum or buzz in system

Cause 1: Inductive pickup caused by close proximity of this main station or connected remote

stations to power lines or transformers.

Solution 1: Relocate the offending unit.

Cause 2: Intercom line cable is not wired properly; the shield of microphone cable is not connected

to Pin-1 of XLR

Solution 2: Check intercom line cable. Make sure all the cables’ Pin-1 of XLR connects correct.

Autres manuels pour TM-800

Autres manuels Telikou Système d'interphone

Telikou

Telikou FM-804 Manuel utilisateur

Telikou

Telikou MS-200 Manuel utilisateur

Telikou

Telikou BK-104 Manuel utilisateur

Telikou

Telikou BK-501 Manuel utilisateur

Telikou

Telikou TM-200 Manuel utilisateur

Telikou

Telikou WS-200 Manuel utilisateur

Telikou

Telikou BK-501 Manuel utilisateur

Telikou

Telikou FM-804 Manuel utilisateur

Telikou

Telikou BK-101 Manuel utilisateur

Telikou

Telikou SKYLINE SK-100 Manuel utilisateur

Telikou

Telikou BK-804 Manuel utilisateur

Telikou

Telikou UTS-200 Manuel utilisateur

Telikou

Telikou TM-800 Manuel utilisateur

Telikou

Telikou IP-1X Manuel utilisateur

Telikou

Telikou BK-104 Manuel utilisateur

Telikou

Telikou TM-200 Manuel utilisateur

Telikou

Telikou MS-500 Manuel utilisateur

Telikou

Telikou FT-800 Manuel utilisateur

Telikou

Telikou MS-800 Manuel utilisateur

Telikou

Telikou FT-800 Manuel utilisateur

Telikou

Telikou DT-100 Manuel utilisateur

Telikou

Telikou BK-2400 Manuel utilisateur

Telikou

Telikou BK-1200 Manuel utilisateur

Telikou

Telikou TF-204 Manuel utilisateur

Manuels Système d'interphone populaires d'autres marques

Bticino

Bticino LINEA 3000 Manuel utilisateur

MSI

MSI MSI-140 Manuel utilisateur

golmar

golmar Stadio Plus Manuel utilisateur

CyberData

CyberData 011211 series Manuel

Vidos

Vidos duo M1021 Manuel utilisateur

Vimar

Vimar ELVOX 7539/E Manuel utilisateur

SSS Siedle

SSS Siedle BTSV 850-03 Manuel utilisateur

Dahua

Dahua VTO Series Manuel utilisateur

Elvox

Elvox 5651 Manuel utilisateur

Videx

Videx VIDEOKIT Series Manuel utilisateur

Rocom

Rocom Doortello Business FW T2.05W2.04 Manuel utilisateur

Viking

Viking E-35-EWP Manuel utilisateur

Safeguard Supply

Safeguard Supply LRA-EX1000 Manuel utilisateur

SSS Siedle

SSS Siedle BFCV 850 Series Manuel utilisateur

GRD

GRD MAX V2 Manuel utilisateur

Alecto

Alecto ADI-250 Manuel utilisateur

Aiphone

Aiphone IE-8MD Manuel utilisateur

Perel

Perel EDB4 Manuel utilisateur
