Telefunken S440 Manuel utilisateur

MOBILE PHONE

S440

INSTRUCTION MANUAL

DEAR CUSTOMER,

Thank you for choosing our mobile phone. By reading this instruction manual before using the

product you will gain a good understanding of its functions and capabilities.

This product is designed for GSM/GPRS networks. On top of basic functions, it comes equipped

with a phone book, ringtones, clock/alarm, calendar, calculator, audio player, camera, sound

recorder and more.

Our phone set meets the GSM/GPRS standard and has achieved certication from the relevant

organizations worldwide.

We reserve the right to modify the content of this instruction manual without prior notice.

TABLE OF CONTENTS

1. SCOPE OF DELIVERY ..................................................................................................................3

2. CONTROL ELEMENTS .................................................................................................................4

3. GETTING STARTED ......................................................................................................................6

4. NAVIGATING MAIN MENU............................................................................................................8

5. SOS MODE FUNCTION ..............................................................................................................10

6. BASIC FUNCTIONS ....................................................................................................................11

7. USING ADDITIONAL TOOLS ......................................................................................................25

8. SETTINGS GUIDE.......................................................................................................................29

9. SAFETY INSTRUCTIONS............................................................................................................32

10.CLEANING INSTRUCTIONS.......................................................................................................34

11.TECHNICAL DATA.......................................................................................................................35

12.DISPOSAL INSTRUCTIONS .......................................................................................................35

13.WARRANTY AND AFTER-SALES SERVICE ...............................................................................36

1. SCOPE OF DELIVERY

Remove all packaging and dispose of accordingly. Carefully check the below listed package

contents. If anything is missing, contact your retailer immediately.

1. S440 Mobile Phone

2. Hands-free Kit

3. Rechargeable Li-ion Battery

4. Travel charger

5. USB cable

6. Charging cradle

7. Quick start guide

8. EU Declaration of Conformity

2. CONTROL ELEMENTS

* /Symbol Key

In text editing mode:

fPress to access list of special

symbols

fPress and hold to switch to the +

key when dialing a number

Earpiece

Display

Right key:

fBack key

fContact access

fMute a call

Up and Down Direction

keys

fNavigate menu.

fPress to access

shortcut feature

fPress to access

shortcut feature

Power/End key

fHold down to power

On or Off

fPress to end a call

OK key

fUsed to confirm selection

as with the Left Key

fSkips certain context/

confirmation menus

# key

On a main screen:

Press and hold to switch between

currently set, Vibration and Silent

sound profile

In text editing mode:

fPress to change text input

method (Abc, ABC, abc, 123)

and select writing language

Left key:

fOK key

fMain menu key

fAnswer a call

Call key:

fDial a number

fAnswer a call

fShow call history

Voicemail key

fPress and

hold to access

voicemail

Photo key

fAccess camera mode

fIn camera mode,

press to take a photo

Direct memory keys

fPress to dial M1/M2

assigned numbers

fIn menu, used as

left/right direction

keys

0/Space/Flash light key

In text editing mode:

fPress to add space between words

From main screen, press and hold to

open or close the torch

2. CONTROL ELEMENTS

3.5mm earphone jack

Camera Flash/

Torch

Camera/Charging

indicator

Micro-USB charging port

Speaker

SOS button

Microphone

Charging cradle ports

3. GETTING STARTED

3.1 Installing SIM card

Note: This phone supports standard sized SIM cards only. Use a card adaptor

if necessary. If no SIM card is inserted or if the SIM card is damaged, the screen

shows “Please insert SIM card”.

1. Make sure phone is switched off and remove the back cover.

2. Install a SIM card inside the SIM Card slot. Make sure the contacts of the

SIM card are facing downwards and cut corner is orientated towards the

upper, left corner.

3.2 Installing memory card

WARNING: SIM cards and Micro-SD cards are small objects, keep them out of

reach of children. Risk of choking due to ingestion of small parts!

1. To install a Micro-SD card (not provided), open the back cover and

remove the battery.

2. Slide the card holder (beside the SIM slot) to the left to unlock the

hinge. Lift the flap and put the Micro-SD card into the card holder. Slide

the holder back to the right to lock the card in place.

3.3 Installing battery

Note: Use only original battery or a battery approved by the manufacturer. Do not

use any other unauthorized batteries.

1. Remove the back cover.

2. Install battery by sliding it into battery compartment with contacts

facing downwards to the right.

3. Replace the back cover.

3.4 Charging battery

Notes:

The battery comes partially charged.

Charge the battery only indoors and in dry locations.

Insert the Micro-USB plug carefully. It only fits one way.

Normal charge time takes 3-4 hours.

Do not leave the phone charging for more than 12 hours.

To maximise battery life, limit multimedia functions.

Charge the battery between 0°C and 45°C. Charge the battery promptly when

flat.

With poor network conditions (less than 2 bars) battery life is reduced.

When not using the phone for long periods remove the battery.

1. Connect the provided charger to a suitable power outlet.

2. Plug the other end with micro-USB plug to phone's charging port. The charging indicator

starts to flash.

3. Once the battery is fully charged, the charging indicator stops flashing.

4. Once phone has been fully charged disconnect the charger from phone's charging port and

from the power outlet.

Alternatively, use the provided charging cradle.

WARNING: When a travel charger and its accessories are used to charge the battery,

check rst whether they have been made or approved by the manufacturer. Using

other accessories can damage your mobile phone and present a risk.

3.5 Switching phone on for the rst time

1. Press and hold the key.

2. If a SIM card is inserted when the phone is turned on, the phone will ask you to select a display

and writing language. It will then request you input a PIN code.

3. Press the left or key while Display language is selected, use the direction keys ( and

) to select your desired language, then press the left or key again to confirm your

choice.

4. Press the key to select Writing language, then repeat the process from the previous step.

5. Enter the PIN code (provided with the SIM card) and press the left or key.

6. Once the language has been configured, press Done to confirm.

Tip: By default, the date and time are updated automatically by the SIM card.

When you set the date and time manually, this feature is turned o. To turn this

feature back on, go to Menu > Settings > Phone > Date & time > Update time

settings. Select Auto update time, then press the left and keys.

4. NAVIGATING MAIN MENU

4.1 Controls

Left Right

Down

To access the main menu, press the left or key. In general, to confirm a choice (OK) or

see a list of options in a menu, you can also use these keys.

To go back or cancel an option, use the right key. Use the key to go back to the main

screen.

To scroll through the menus, use the and keys.

To move left or right, use the M1 and M2 keys.

4.2 Shortcuts

Tip: The shortcuts are preassigned, however they can be changed.

To change default shortcuts go to: Menu > Settings > Phone > Dedicated keys

You have two shortcut keys ( and keys) to which features can be assigned.

To assign a feature to the shortcut key, from the Dedicated keys menu, press the left or

key to access the feature list. Press and keys to select a feature, then press the left

or key to confirm. Press Done to confirm.

To assign a feature to shortcut key, from Dedicated keys menu, press key, then the left

or key to access the feature list. Press and keys to select a feature, then press

the left or key to confirm. Press Done to confirm.

4.3 Understanding icons

Icon Description

Signal Strength for SIM

Missed Call

Roaming. Dierent rates

apply, check with your

service provider

New SMS Message

New MMS Message

Message Inbox is Full

Silent Mode/Meeting Mode

Icon Description

Vibration Mode

New Voicemail

Bluetooth®Enabled

Alarm is set

Low battery

Earphones connected

(headset mode)

SOS activated

5. SOS MODE FUNCTION

Tip: This phone has a built-in Emergency SOS feature that in case of an accident

can directly connect you with your chosen emergency contacts.

When you request assistance with the Emergency SOS Key, the phone

automatically calls the assigned emergency numbers.

Go to Menu > SOS and press the left or key, you will see following options:

SOS number list Add or edit a list of 5 SOS numbers.

SOS message settings Modify your SOS message (to be sent by SMS).

SOS settings Toggle the SOS button on/off, and customize its behaviour.

Help Displays a detailed explanation of each SOS option.

Making an emergency call

To make an emergency call, press and hold the SOS button on the back of your phone for

3-5 seconds. The phone will emit an audible alarm (if activated), send a customized SOS message

(if activated), then call the numbers on the SOS number list one after the other, ve times. If the

call is not answered and conrmed within 20 seconds, the phone will call the next number, and so

on.

In the SOS message settings menu, you can customize an SOS message that is automatically

send to the contacts on your SOS number list in emergency situations.

In the SOS settings menu, you can toggle the SOS function on/o with the left or key. If

the SOS function is enabled, you can toggle the SOS message, SOS ring alert, and SOS LED alert

on/o in the same manner.

Editing number list

You can add up to ve emergency contacts (relatives, friends, emergency services, etc.) to your

SOS number list. Remember to inform these contacts that they are on your emergency list.

1. Select SOS from the main menu, then select SOS number list.

2. Highlight the first contact spot, then press left key (Options).

3. Select Add from contacts to add a number from your contacts or select Edit to insert a new

number using the keypad. Press the left or key to confirm.

4. Scroll to the next SOS contact and repeat the same procedure to add another number.

5. To edit/delete a SOS contact, select the contact and press the left key, then select Edit or

Clear.

Table des matières

Autres manuels Telefunken Téléphone portable

Telefunken

Telefunken TF-SP4501 Manuel utilisateur

Telefunken

Telefunken TM 28.1 Classy Manuel utilisateur

Telefunken

Telefunken TM350 IZY Manuel utilisateur

Telefunken

Telefunken TM 210 IZY Manuel utilisateur

Telefunken

Telefunken TF-SP4001 Manuel utilisateur

Telefunken

Telefunken TF-SP4001 Manuel utilisateur

Telefunken

Telefunken TF-SP5301 Manuel utilisateur

Telefunken

Telefunken S460 Manuel utilisateur

Telefunken

Telefunken TF-SP4503 Manuel utilisateur

Telefunken

Telefunken TM 140 COSI Manuel utilisateur

Telefunken

Telefunken S540 Manuel utilisateur

Telefunken

Telefunken S560 Manuel utilisateur

Telefunken

Telefunken S740 Manuel utilisateur

Telefunken

Telefunken TM320 IZY Manuel utilisateur

Telefunken

Telefunken TF-SP4002 Manuel utilisateur

Telefunken

Telefunken S520 Manuel utilisateur

Telefunken

Telefunken TM 110 COSI Manuel utilisateur

Telefunken

Telefunken TM 360 COSI Manuel utilisateur

Telefunken

Telefunken S760 Manuel utilisateur

Telefunken

Telefunken S420 Manuel utilisateur

Telefunken

Telefunken TM 240 COSI Manuel utilisateur

Telefunken

Telefunken TM 240 COSI Manuel utilisateur

Telefunken

Telefunken TM 18.1 Classy Manuel utilisateur

Telefunken

Telefunken TF-SP5301 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
