MPI2-10 Front Panel Assembly Installation Instructions

CAUTION. Replacement of the front-panel assembly should be performed only by

qualiﬁed personnel. The instrument hardware can be damaged performing this

procedure.

Servicesafetysummary

The Service safety summary section contains additional information required to

safely perform service on the product. Read this Service safety summary before

performing any service procedures.

To avoid electric shock. Do not touch exposed connections.

Do not service alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering ﬁrst aid and resuscitation is

present.

Disconnect power. To avoid electric shock, switch off the product power and

disconnect the power cord from the mains power before removing any covers or

panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist

in this product. Disconnect power, remove battery (if applicable), and disconnect

test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric

strength after performing a repair.

Terms in this manual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

www.tek.com

*P075110800*

075-1108-00

MPI2-10 Front Panel Assembly Installation Instructions

Kit parts list

The following table lists the parts that are supplied with the front panel assembly

installation kit.

Quantity Part Number Description

1 850-0336-XX FRONT PANEL ASSY

4 211-0734-XX SCREW, MACHINE; 6-32 X 0.250, FLH100, STEEL, ZINC

FINISH,T-10TORXDR

1 075-1108-XX PRISM FIELD UPGRADE INSTRUCTIONS

Recommended tool list

Table 1: Recommended tool list

Name Description

Screwdriver handle Accepts Torx-driver bits

T-10 TORX tip Used for removing instrument screws.

TORX-driver bit for T-10 size screw heads.

Torque driver Used to apply precisely a speciﬁc torque to

a fastener.

Remove and replace the front panel assembly

These instructions are for personnel who are familiar with servicing the product.

Contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service

for installation assistance.

WARNING. Dangerous voltages may be present. To prevent electrical shock,

disconnect the power cord from the unit before starting the upgrade procedure.

Failure to do so could cause serious injury or death.

CAUTION. Many components within the instrument are susceptible to static-static

discharge damage. To prevent static discharge damage, service the product

only in a static-free environment. Observe standard handling precautions for

static-sensitive devices while installing this kit. Always wear a grounded wrist

strap, grounded foot strap, and static resistant apparel while installing this kit.

2 MPI2-10 Front Panel Assembly Installation Instructions

MPI2-10 Front Panel Assembly Installation Instructions

1. Set the instrument so that the bottom is down on a static-free work surface.

CAUTION. Dislodging or cracking the bezel can cause damage to the display. To

prevent damage to the display, do not put excessive pressure on the bezel when

removing, replacing or installing modules.

2. Remove the top cover as follows:

a. Use a TORX-driver with a T-10 TORX tip to remove the twelve screws

securing the cover to the instrument.

b. Slide the cover back and then lift it from the back to remove it from the

instrument; set the cover aside.

3. UseaTORXdriverwithaT-10TORXtiptoremovethetwoscrewsoffeach

side of instrument.

MPI2-10 Front Panel Assembly Installation Instructions 3

MPI2-10 Front Panel Assembly Installation Instructions

4. Tip the instrument up on the back panel and pull the Display up until the

connector is disconnected.

5. To reinstall the display, reverse the steps.

CAUTION. The touch display will not operate correctly if connector is not lined

up. To avoid this issue, line up the connectors before engaging.

4 MPI2-10 Front Panel Assembly Installation Instructions
