Introduction
Additional equipment and parts needed:
•
2 Channel radio and receiver
•
1/10th scale ESC and motor system
•
Low prole or standard size high torque steering servo (at least 180 oz/in)
* Running less than the recommended rating will increase the chance of premature servo failure.
•
2S (2 cell, 7.4v) shorty LiPo battery
•
Paint for body
•
1/10th scale 4x4 buggy wheels & tires, CA glue (or premounts)
•
48 pitch pinion 15 tooth - 30 tooth
Tools needed:
•
Hex drivers 1.5mm, 2.0mm, 2.5mm
•
Nut drivers 5.5mm (TKR1108), 7.0mm (TKR1109)
•
Hobby knife
•
Needle-nose pliers
•
Shock tool (TKR1115) OR adjustable (Crescent) wrench (for shock assembly)
•
4mm turnbuckle wrench (TKR1103) AND 5.5/7.0 two sided wrench (TKR1119)
•
Body reamer
Take your time! When you work your way through these building instructions, keep an eye out
for the following important indicators below:
•
RED TEXT - This indicates important areas of the build process that should be observed.
•
YOUTUBE - We also have many useful build videos on Youtube, so be sure to check these out!
https://www.youtube.com/c/teknorc
Thread Lock icons
Thread lock is always used when a screw is inserted into any metal part. (Included with kit)
Thread
Lock
Grease icons
Grease is usually used on areas with movement and for sealing. (Included with kit)
Grease
Disclaimer: Tekno RC is not responsible or liable for any property or personal damage, loss, or injury incurred as a
result of using this product. This kit is meant for use by persons 14 years of age or older and in the strict connes of
a legally permitted RC track or facility.
Warnings: Always double-check that your radio gear is working properly before operating vehicle. Never operate the
vehicle indoors (unless the RC track is an indoor facility). Use caution while operating vehicle so as not to collide with
people who may be turn marshalling or who might otherwise not be aware that a fast moving RC vehicle is in the vicinity.
Warranty: We warrant that the parts included in this kit are free from defects. If you nd a defective part in your kit,
please
contact
us
at
[email protected] and
we
will
help
to
resolve
the
issue.
If
you
modify
any
part
prior
to
contacting
us, the warranty claim will be void. We do not warranty parts that may be broken during operation of the vehicle
or otherwise. Refer to the end of this instruction manual for a listing of spare/replacement and option parts.
All spare parts and other info are available on our website (www.teknorc.com) and through our network of
domestic and international dealers and distributors.
Thank you for purchasing the Tekno RC EB410.2 10th 4WD competition electric buggy kit.
We are always working on new projects, so please check our website regularly at www.teknorc.com
or visit us on Facebook at www.facebook.com/teknorc for all the latest news, parts, and kits.
