TEKNIX TKW10142HW Instructions de montage
TKW10142HW
TKW12142HW
SAFETY INFORMATION
EMERGENCY DOOR OPENING
INSTALLATION GUIDE
INSTRUCTIONS FOR USE
BEFORE USING THE WASHING MACHINE
PRECAUTIONS AND GENERAL
RECOMMENDATIONS
DESCRIPTION OF THE WASHING MACHINE
BEFORE THE FIRST WASH CYCLE
PREPARATION OF THE WASHING
DETERGENTS AND ADDITIVES
CARE AND MAINTENANCE
TROUBLESHOOTING GUIDE
TRANSPORT / HANDLING
ELECTRICAL CONNECTION
The manufacturer reserves the right for any modifications
on the product which might be deemed necessary or
useful without informing about it in this IFU.
Before operating your new washing machine, please read
this instruction carefully, and keep it for future reference. If
you have lost it accidentally, ask customer service for e-
copy or hard copy.
Please make sure the socket is grounded securely, the
water source connection is reliable.
4. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
5. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
6. Children should be supervised to ensure that they do not
play with the appliance.
7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
8. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
SAFETY INFORMATION
1.
2.
3.
1
9. For appliances with ventilation openings in the base, that a
carpet must not obstruct the openings.
10. Children of less than 3 years should be kept away unless
continuously supervised.
11.The maximum permissible inlet water pressure, 1 MPa, for
appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure, 0.1 MPa, if
this is necessary for the correct operation of the appliance.
2
12.
13.
14.
The maximum washing capacity is 10/12kg.
For private domestic use only.
staff kitchen areas in shops, offices and other working
environments;
farm houses;
by clients in hotels, motels and other residential type
environments;
bed and breakfast type environments;
areas for communal use in blocks of flats or in
launderettes.
This appliance is intended to be used in household and
similar applications such as:
3
After unpacking, ensure that the washing machine is undamaged. If in doubt, do
not use the washing machine. Contact After-Sales Service or your local retailer.
Connect the water supply inlet hose in accordance with the regulations of your local
water company.
Single inlet - Cold water only
Water inlet - Depending on models:
Ensure that the ventilation openings in the base of the washing machine
(if available on your model) are not obstructed by a carpet or other material.
BEFORE USING THE WASHING MACHINE
Removing the packaging and inspection
Check that the accessories and supplied parts are all present.
Keep the packaging materials (plastic bags, polystyrene parts, etc.) out of reach of
children, as they are potentially dangerous.
Remove the transport bolts
The washing machine is fitted with transport bolts to avoid any possible damage to
the interior during transport. Before using the machine, it is imperative that the
transport bolts are removed.
After their removal, cover the openings with the 4 enclosed plastic caps.
Install the washing machine
Move the appliance without lifting it by the worktop.
Install the appliance on a solid and level floor surface, preferably in a corner of the
room
Ensure that all four feet are stable and resting on the floor and then check that the
washing machine is perfectly level (use a spirit level).
Water inlet
Dual inlet - Hot and cold water
Water tap: 3/4 threaded hose connector
4
Connect the drain hose to the siphon or hook it over the edge of a sink by
means of the “U” bend supplied.
Width: 615 mm
Height: 855 mm
Drain
If the washing machine is connected to an integrated drainage system,
ensure that the latter is equipped with a vent to avoid simultaneous
loading and draining of water (siphoning effect).
Fix the drain hose securely to prevent scalding during machine drainage.
Electrical connection
Electrical connections must be carried out by a qualified technician in compliance
with the manufacturer's instructions and current standard safety regulations.
Data regarding voltage, power consumption and protection requirements is given
on the inside of the door.
The appliance must be connected to the mains by means of a socket with an earth
connection in accordance with current regulations. The washing machine must be
earthed by law. The manufacturer declines all liability for damage to property or
injury to persons or animals due to non-compliance with the directions given above.
Do not use extension leads or multiple sockets. Make sure the capacity of the
socket is powerful enough to drive the machine during heating.
Before any maintenance on the washing machine disconnect it from the
mains supply.
After installation, access to the mains plug or to disconnection from the mains
supply must be ensured at all times via a double-pole switch.
Do not operate the washing machine if it has been damaged during transport.
Inform After-Sales Service.
Mains cable replacement is only to be carried out by After-Sales Service.
The appliance must only be used in the household for the prescribed uses.
Minimum housing dimensions:
Depth:refer to programme chart
5
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for there cyclingof electrical
and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
PRECAUTIONS AND GENERAL RECOMMENDATIONS
Packaging
The packaging material is entirely recyclable, and marked with the recycling symbol
Adhere to current local regulations when disposing of packaging material.
Disposing of packaging and scrapping old washing machines
The washing machine is built from reusable materials. It must be disposed of in
compliance with current local waste disposal regulations.
Before scrapping, remove all detergent residues, break the door hook, and cut
off the power cable so that the washing machine is made unusable.
This appliance is marked according to the European directive on Waste is
Electrical and Electronic Equipment (WEEE). By ensuring that this
product disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product.
Location and surroundings
The washing machine must only be installed in enclosed spaces. Installation in the
bathroom or other places where air is humid is not recommended.
Do not store flammable fluids near the appliance.
Safety
Do not leave the appliance plugged in when not in use. Never plug or unplug the
power from the mains supply, if your hands are wet.
Turn off the tap.
Before any cleaning and maintenance, switch off the machine or disconnect it from
the mains.
Control panel layout and
appearance will depend on the model.
6
Clean the outside of the washing machine with a damp cloth. Do not use abrasive
detergents.
Never open the door forcibly or use it as a step.
DESCRIPTION OF THE WASHINGMACHINE
EMERGENCY DOOR OPENING
In case of failure to open the door due to power outage or other special
circumstances, the door lock lever at the drainage pump door can be used for
emergency opening.
Note:
1. Do not operate when the machine is working normally;
2. Before operation, please make sure that the inner barrel has stopped turning,
without high temperature, and the water level is lower than the clothing inlet. If the
water level is higher than the clothing inlet, drain off water through the drain-away
pipe (if available) or by slowly unscrewing the filter.
3. Operation method: Open the cover of drainage pump door, pull down the lock
lever with the help of a tool, and then the door can be opened(indicated in the figure).
Door lock lever
1 Worktop
2 Control panel
3 Detergent dispenser
4 Door
5 Plinth covering pump access
6 Adjustable feet
7
1. Sort the laundry according to...
Type of fabric / care label symbol
Cottons, mixed fibres, easy care/synthetics, wool, handwash items.
Colour
Separate coloured and white items. Wash new coloured articles separately.
Loading
Wash items of different sizes in the same load to improve washing efficiency and
distribution in the drum.
Delicates
Wash small items (e.g. nylon stockings, belts etc.) and items with hooks (e.g. bras)
in a cloth bag or pillow case with zip. Always remove curtain rings or wash curtains
with the rings inside a cotton bag.
2. Empty all pockets
Coins, safety pins etc. can damage your laundry as well as the appliance drum and
tub.
3.Fasteners
Close zips and fasten buttons or hooks; loose belts or ribbons should be tied
together.
Stain removal
Blood, milk, eggs etc. are generally removed by the automatic enzyme phase of the
programme.
To remove any residual water used during testing by the manufacturer, we
recommend that you carry out a short wash cycle without laundry.
1 Open the tap.
2 Close the door.
3 Pour a little detergent (about 30 ml) into the main wash chamber of the deter-
gent dispenser .
4 Select and start a short programme (see separate quick reference guide).
BEFORE THE FIRST WASH CYCLE
PREPARATION OF THE WASHING
4.
