Tekkeon MP1500 Manuel utilisateur

MP1500 User Guide

Mobile Power &

Battery Charger

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 1

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 2

USER GUIDE

Contents

Overview ..............................................................................................................2

Getting Started ......................................................................................................2

Unpacking myPower GO ................................................................................2

Getting to Know myPower GO ......................................................................3

Installing Batteries ................................................................................................4

Using myPower GO ..............................................................................................5

Charging a Device ..........................................................................................6

Charging Batteries..........................................................................................8

Troubleshooting ....................................................................................................9

Limited Warranty ................................................................................................10

Customer Support ..............................................................................................12

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 3

myPower GO

Overview

myPower™GO provides emergency power to mobile phones, smartphones,

Bluetooth headsets, iPod/MP3 players, PDAs, digital cameras, and more.

And myPower GO uses AA batteries, so it is always ready to be used. As an

added bonus, myPower GO doubles as a battery charger, so you can charge

your rechargeable AA batteries as needed, so it’s always ready for use.

Adapters for your Blackberry (mini USB), Motorola, Nokia, Samsung (some

models) and Sony Ericsson mobile phones are included with myPower GO.

Other adapters included in the package also may work with your digital cameras,

MP3 players, PDAs, portable media players and other small devices. If the extra

adapter you need isn't in the package, just go to www.tekkeon.com or call us at

888-787-5888 or 714-832-1266 to order more adapters for a nominal fee.

Getting Started

Unpacking myPower GO

Your myPower GO package includes the following:

User guide (not shown)

Universal adapter

kit with tote

(10 adapter tips)

Input/output

cord

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 2

Getting to Know myPower GO

USER GUIDE

DC IN

For connection to computer

to charge AA batteries.

TEST Button

Charging Status Lamps

USB Port

For connection to charge

a portable device.

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 3

Installing Batteries

myPower GO requires four rechargeable

or alkaline AA batteries, which are

housed on the bottom side of the unit.

As myPower GO doubles as a battery

charger, rechargeable batteries can be

recharged in the unit.

(Please note that alkaline and rechargeable batteries should not be used together.)

1. Push down on the lever above

the USB port, slide the cover in

the direction of the arrow, and

then lift the cover to remove

(as shown).

2. Insert the batteries in the

directions indicated.

3. Replace the cover.

4. Press the TEST button. All LEDs will light to indicate the batteries are installed

properly. As the batteries are drained to charge your portable device(s), the LEDs

will turn off in sequence.

Push down

Slide cover forward

and lift

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 4

Using myPower GO

myPower GO can be used to power or charge any portable device that requires 5V

or less, and that supports center positive polarity. If your device has a center

negative polarity, do not power the device with myPower GO as it does not support

center negative polarity.

myPower GO doubles as a battery charger for four AA rechargeable batteries. When

the batteries are empty, you can recharge the batteries without removing them from

myPower GO.

USER GUIDE

Center Negative

Center Positive

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 5

Charging a Device

1. Select the adapter plug that fits

securely into the power jack on

your portable device and plug it

into the input/output cord.

If you are using a UA-xxx

adapter (rather than a PA-xxx),

you must insert the L34 adapter

that came with your myPower GO

between the adapter cord and

UA-xxx adapter as shown.

NOTE: If none of these plugs fits snugly into your portable device power jack, please

go to our web site at: www.tekkeon.com/goadapters to determine which adapter

plug you need for your device. You can obtain most adapters through the web site,

or by contacting Tekkeon by phone at: 1-888-787-5888 or 1-714-832-1266.

If available through Tekkeon, the adapter will be sent to you for a nominal fee.

TIP: You can power and charge your iPod using your own iPod USB cable. Simply

plug the USB plug into the USB port on myPower GO. While iPod is charging, you

can listen to music or watch a slideshow. It is recommended that you do not watch

videos while charging iPod as video playback consumes power faster than

myPower GO will charge.

L34 Adapter for

myPower GO

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 6

USER GUIDE

2. Plug the USB plug on the input/output cord into the USB port on the end of

myPower GO.

3. Connect the adapter plug into the power jack on your portable device.

4. Turn on the portable device and use it as you would normally. While connected,

myPower GO will power or charge your device.

Leave the portable device turned off and myPower GO will charge the device

battery.

5. When finished, unplug the power output cord from myPower GO and your

device.

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 7

Charging Batteries

1. With four rechargeable AA batteries installed in myPower GO, plug the adapter

with the black tip into the input/output cord.

2. Plug the adapter tip into the DC IN jack on the end of myPower GO.

3. Plug the USB plug on the opposite end of the input/output cord into a USB jack

on a computer. The green LEDs will light in sequence to indicate that the batteries

are being charged.

4. After 6 hours, unplug myPower GO. The batteries will be fully charged.

NOTE: It is strongly recommended to recharge the batteries only when completely

empty.

mp1500_ug_revC_fnl 3/12/07 3:34 PM Page 8
