10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

RF Coaxial Power Standards

Models 1505A and 2505A

Instruction and Service Manual

PN# 1505A/2505A-900

Publication Date: March, 2016

REV. C

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

TEGAM is a manufacturer of electronic test and measurement equipment for metrology, calibration, and

production test. We also provide repair, calibration, and other support services for a wide variety of test

and measurement equipment including RF power sensor calibration systems, RF attenuation measurement

systems, ratio transformers, arbitrary waveform generators, micro-ohmmeters, LCR meters, handheld

temperature calibrators, thermometers, humidity and temperature control devices, and more.

TEGAM also repairs and calibrates test and measurement equipment formerly manufactured by Electro-

Scientific Industries (ESI), Gertsch, Keithley Instruments, Lucas Weinschel, and Pragmatic Instruments. A

complete list can be viewed on our Product Service Directory at www.tegam.com

For more information about TEGAM and our products, please visit our website at www.tegam.com: or

contact one of our customer service representatives at sales@tegam.com or 800-666-1010.

10 Tegam Way,

Geneva, Ohio 44041

Telephone: (440) 466-6100

Fax: (440) 466-6110

E-mail: sales@tegam.com

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

Table of Contents

Section Page

I. Introduction

Purpose and functions..........................................................................1-1

Capabilities.........................................................................................1-1

Performance characteristics..................................................................1-2

Environmental information ...................................................................1-2

List of items furnished .........................................................................1-3

List of additional items required for operation and maintenance................1-3

Preparation for calibration or repair and shipping ....................................1-4

Expedite Repair Form ..........................................................................1-5

Warranty information...........................................................................1-6

TEGAM contact information ..................................................................1-6

II. Preparation for Use and Installation

Unpacking & Inspection........................................................................2-1

Recommended Operating Environment ..................................................2-1

III. Principles of Operation

Power Measurements...........................................................................3-1

Principles of DC Substitution.................................................................3-1

Temperature Variable Resistance ..........................................................3-1

Power Splitters ...................................................................................3-1

Controlling Thermistor Temperature ......................................................3-2

IV. Operating Instructions

Front Panel Connectors........................................................................4-1

Calculating Calibration Factors..............................................................4-2

Relationship between k, gamma. And effective efficiency .........................4-7

V. Maintenance and Servicing

Maintenance.......................................................................................5-1

Care and Handling of Assemblies...........................................................5-1

Connector Torque................................................................................5-2

Connector Care and Cleaning................................................................5-3

VI. Preparation for Shipment

Returning power standard for service.....................................................7-1

Repacking for shipment .......................................................................7-1

VII. Storage

Temperature and other environmental limitations ...................................8-1

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

Safety Information & Precautions:

The following safety information applies to both operation and service personnel. Safety precautions and

warnings may be found throughout this instruction manual and the equipment. These warnings may be in

the form of a symbol or a written statement. Below is a summary of these precautions.

Terms in This Manual:

CAUTION statements identify conditions or practices that could result in damage to the equipment or

other property.

WARNING statements identify conditions or practices that could result in personal injury or loss of life.

Terms as Marked on Equipment:

CAUTION indicates a personal injury hazard not immediately accessible as one reads the marking, or a

hazard to property including the equipment itself.

DANGER indicates a personal injury hazard immediately accessible as one reads the marking.

Symbols:

As Marked in This Manual:

This symbol denotes where precautionary information may be found.

As Marked on Equipment:

CAUTION – Risk of Danger

DANGER – Risk of Electric Shock

Earth Ground Terminal

Off

Frame or Chassis Terminal

Earth Ground Terminal

Alternating Current

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-1

Section I – Introduction

Purpose and Function

These Coaxial RF Power Standards are designed for the precise measurement of microwave power in the

6 kHz to 18 GHz frequency range. These standards can be configured as a Reference Standard or Working

Standard. The Working RF Power Standard (or Feedthrough RF Power Standard) is a thermistor mount

with power splitter combination employed as a Feedthrough standard for the calibration of terminating

power sensors such as thermoelectric, diode and thermistor power sensors. The Reference RF Power

Standard (or Terminating RF Power Standard) is a terminating thermistor mount used for the calibration

of Feedthrough standards and applications that require direct measurement of RF power.

Capabilities

These Coaxial RF Power Standards are designed for the calibration laboratory. These units are highly

accurate, stable with time and temperature, and are designed for use as a standard for the

characterization of calibration factors for other sensors.

Table 1.1 General Specifications

Frequency Range

6 kHz to 18 GHz

Max Power

25 mW (+14 dBm)

RF Impedance

50 Ohms nominal

Power Linearity

Typical Usable Range <0.1% from 1 to 10 mW

-20 dBm to +10 dBm (0.01 to 10 mW) typical

(Depends on noise floor and resolution of DC instruments)

Calibration Factor Drift

<0.5% per year

Individual Calibration factors are

supplied standard at the following

frequencies. Inquire about

additional points.

6 kHz, 9 kHz

20 kHz -100 kHz in 10 kHz steps

200 kHz, 300 kHz, 455 kHz, 500 kHz

1 MHz, 1.25 MHz, 3 MHz, 5 MHz

10 MHz to 90 MHz in 10 MHz steps

100MHz to 1950 MHz in 50 MHz steps

2 GHz to 3.9 GHz in 100 MHz steps

4 GHz to 12.4 GHz in 200 MHz steps

12.75 GHz to 18 GHz in 250 MHz steps

Thermistor DC Bias Power

Approximately 35 mW (nominal)

Thermistor Resistance at Bias

200 Ohms (set by balancer)

Temperature

Operating

Storage

+15° to +30° C (+59° to +86° F)

-55° to +75° C (-67° to +167° F)

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-2

Section I – Introduction

Table 1.2 2505A/1505A Individual Specification

Model

2505A

1505A

Frequency Range

6 kHz to 18 GHz

Typical Equivalent

Source Match

|(V/V)

6 kHz to 6 GHz: 0.03

6 GHz to 15 GHz: 0.05

15 GHz to 18 GHz: 0.07

6 kHz to 1 MHz: 0.03

1 MHz to 100 MHz: 0.02

100 MHz to 2 GHz: 0.03

2 GHz to 8 GHz: 0.12

8 GHz to 12 GHz: 0.15

12 GHz to 18 GHz: 0.25

Loss from Input Port

to DUT Port

8.5 dB (typical)

N/A

Calibration Factor

Accuracy (typical)

+/-0.70% from 6 kHz to 10 MHz

+/-0.80% from 0.01 to 10 GHz

+/-1.00% from 10.0 to 18 GHz

+/-0.90% from 6 kHz to 10 MHz

+/-1.00% from 0.01 to 10 GHz

+/-1.20% from 10.0 to 18 GHz

Test Port

Connectors

Type N Connector Female

Type N Connector Male, ¾”

Weight

2.9 kg (6.3 lb)

544.3 g (1.2 lb)

Physical Dimensions

Height

Width

Depth

10.5 cm (4.1 in)

21.7 cm (8.5 in)

33.8 cm (13.3 in)

7.2 cm (2.8 in.)

8.2 cm (3.2 in.)

13.8 cm (5.4 in.)

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-3

Section I – Introduction

Items Included with 1505A and 2505A

Item

Part Number

Technical (Operation and Maintenance) Manual

1505A/2505A-900

Calibration Certificate with Data

N/A

Table 1.2–Packing List

Additional items (required and optional) for operation and maintenance

Required:

•TEGAM Model 1830A, 1806A, 1806, or 1805B1RF Power Meter

o1830A Cable (CA-21-15/48)

o1806A Cable (CA-28-48)

o1806 Cable (CA-29-48)

o1805B Cable as heater only (CA-29-48)

•RF Signal Generator

o6 kHz to 18 GHz

oMinimum power level 10 dBm at 18 GHz

•Torque Wrench

oTorque wrench, ¾” 12.0 in-lbs (1130-911-01)

Optional:

•RF Amplifier

•SureCAL Software (P/N SureCAL-PM)

•Rack Mount Kit for 2505A

o(Single - P/N 1830-910)

o(Dual - P/N 1830-911)

•VNA

o2-port

o18 GHz

•TEGAM 1505A (For calibration of TEGAM 2505A)

•Transport Case

o1505 RF Power Standard (1500-910)

o1830A, F113X & 2505A (2500-910)

1TEGAM models 2505A and 1505A are designed to be used with TEGAM Models 1830A, 1806A, and 1806. In

addition, the TEGAM Model 1805B can be used to heat the 2505A and 1505A with cable CA-29-48. The

1805B is for heating only and cannot be used for power measurements or biasing of the 2505A or 1505A.

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-4

Section I – Introduction

Preparation For Calibration Or Repair Service

Once you have verified that the cause for the Coaxial RF Power Standards malfunction cannot be solved in

the field and the need for repair and calibration service arises, contact TEGAM customer service to obtain

an RMA, (Returned Material Authorization), number. You can contact TEGAM customer service via the

TEGAM website, www.tegam.com or by calling 440.466.6100 (All Locations) OR 800.666.1010 (United

States Only).

The RMA number is unique to your instrument and will help us identify you instrument and to address the

particular service request by you which is assigned to that RMA number.

Of even importance, a detailed written description of the problem should be attached to the instrument.

Many times repair turnaround is unnecessarily delayed due to a lack of repair instructions or of a detailed

description of the problem.

This description should include information such as measurement range, and other instrument settings,

type of components being tested, are the symptoms intermittent, conditions that may cause the

symptoms, has anything changed since the last time the instrument was used, etc. Any detailed

information provided to our technicians will assist them in identifying and correcting the problem in the

quickest possible manner. Use a copy of the Repair and Calibration Service form provided on the next

page.

Once this information is prepared and sent with the instrument to our service department, we will do our

part in making sure that you receive the best possible customer service and turnaround time possible.

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-5

Section I – Introduction

EXPEDITE REPAIR & CALIBRATION FORM

Use this form to provide additional repair information and service instructions. The Completion of this

form and including it with your instrument will expedite the processing and repair process.

RMA#:

Instrument Model #:

Serial

Number:

Company:

Technical Contact:

Phone Number:

Additional

Contact Info:

Repair Instructions:

Evaluation Calibration Only Repair Only Repair & Calibration Z540 (Extra Charge)

Detailed Symptoms:

Include information such as measurement range, instrument settings, type of components being

tested, is the problem intermittent? When is the problem most frequent?, Has anything changed with

the application since the last time the instrument was used?, etc.

10 TEGAM WAY • GENEVA, OHIO 44041 440-466-6100 • FAX 440-466-6110 • www.tegam.com

1-6

Section I – Introduction

Warranty

TEGAM, Inc. warrants this product to be free from defects in material and workmanship for a period of

three years from the date of shipment. During this warranty period, if a product proves to be defective,

TEGAM Inc., at its option, will either repair the defective product without charge for parts and labor, or

exchange any product that proves to be defective.

TEGAM, Inc. warrants the calibration of this product for a period of 1 year from date of shipment. During

this period, TEGAM, Inc. will recalibrate any product, which does not conform to the published accuracy

specifications.

In order to exercise this warranty, TEGAM, Inc., must be notified of the defective product before the

expiration of the warranty period. The customer shall be responsible for packaging and shipping the

product to the designated TEGAM service center with shipping charges prepaid. TEGAM Inc. shall pay for

the return of the product to the customer if the shipment is to a location within the country in which the

TEGAM service center is located. The customer shall be responsible for paying all shipping, duties, taxes,

and additional costs if the product is transported to any other locations. Repaired products are warranted

for the remaining balance of the original warranty, or 90 days, whichever period is longer.

Warranty Limitations

The TEGAM, Inc. warranty does not apply to defects resulting from unauthorized modification or misuse of

the product or any part. This warranty does not apply to fuses, batteries, or damage to the instrument

caused by battery leakage.

Statement of Calibration

This instrument has been inspected and tested in accordance with specifications published by TEGAM Inc.

The calibration of this instrument is traceable to the International System of Units (SI) through the

National Institute of Standards and Technology (NIST) or other recognized National Metrology Institutes,

by comparison to equipment and standards maintained in the laboratories of TEGAM Inc.

Document publishing dates may lag product changes.

Visit www.tegam.com to download the latest version of this manual.

Contact Information:

TEGAM INC.

10 TEGAM WAY

GENEVA, OHIO 44041

PH: 440.466.6100

FX: 440.466.6110

EMAIL: [email protected]om

WEB: http://www.tegam.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tegam Équipement de test

Tegam

Tegam 94 A Series Manuel utilisateur

Tegam

Tegam 2601A Guide de dépannage

Tegam

Tegam 2510A Guide de dépannage

Tegam

Tegam 2602A Guide de dépannage

Tegam

Tegam F1125 Guide de dépannage

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
