TEFAL MINI MECHANICAL RC RK224 Manuel utilisateur
Mini Rice Cooker
www.tefal.com
EN
ZH
CN
MS
160
120
80
40
4
2
5
7
6
8
7
9
a
c
10
b
d
1
3
4 cups
123
456
7
4
IMPORTANT SAFEGUARDS
SAFETY INSTRUCTIONS
Read and follow the instructions for use. Keep
them safe.
• This appliance is not intended to be operated by
means of an external timer or a separate remote-
control system.
• This appliance can be used by children aged
from 8years and above if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved.Cleaning and user maintenance
shall not be made by children unless they are
older than 8 years and supervised. Keep the
appliance and its cord out of reach of children
aged less than 8years.
1 Lid
2 Lid opening button
3 Steam outlet
4 Removable Inner lid
5 Steam basket
6 Cooking pot
7 Control panel
a “Cook” Indicator
b “Warm” Indicator
c Switch
d Cooking Button
8 Rice spatula
9 Measuring cup
10 Power cord
DESCRIPTION
5
EN
• Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• This appliance is for household use only. It is not
intended for even use in the following applications
and the guarantee will not apply for:
– Staff Pantry areas in shops, offices and other
working environments
– Farm houses
– By clients in hotels, motels and other such kind
of residential type environments
– Bed and breakfast type environments
• If your appliance is fitted with fixed power
cord: if the power supply cord is damage, it
6
must be replaced by the manufacturer, the
manufacturer’s after-sales service department
or similarly qualified person in order to avoid any
danger.
• The appliance must not be immersed in water or
any other liquid.
• Use a damp cloth or sponge with washing up
liquid to clean the accessories and parts in contact
with food. Rinse with a damp cloth or sponge. Dry
carefully.
• If the symbol is marked on the appliance, this
symbol means “Caution: surfaces may become
hot during use”.
• Caution: the surface of heating element is subject
to residual heat after use.
• Caution: risk of injury due to improper use of the
appliance.
• Caution: if your appliance has a removable power
cord, do not spill liquid on the connector.
• Always unplug the appliance:
– immediately after use
– when moving it
– prior to any cleaning or maintenance
– if it fails to function correctly
7
EN
• Burns can occur by touching the hot surface of
the appliance, the hot water, steam or the food.
• During cooking, the appliance gives out heat and
steam. Keep face and hands away.
• Do not obstruct the steam outlet.
• For any problems or queries please contact our
After Sales Care Team or consult our website.
• The appliance can be used up to an altitude of
2000m.
• For your safety, this appliance complies with the safety regulations and
directives in effect at the time of manufacture (Low-voltage Directive,
Electromagnetic Compatibility, Food Contact Materials Regulations,
Environment…).
• Check that the power supply voltage corresponds to that shown on the
appliance (alternating current).
• Given the diverse standards in effect, if the appliance is used in a country
other than that in which it is purchased, have it checked by an approved
service centre.
CONNECTING TO THE POWER SUPPLY
• Do not use the appliance if:
– the appliance or the cord is damaged.
– the appliance has fallen or shows visible damage or does not work
properly.
– In the event of the above, the appliance must be sent to an approved
service centre. Do not take the appliance apart yourself.
• Do not leave the cord hanging.
• Always plug the appliance into an earthed socket.
• Do not use an extension lead. If you accept the liability for doing so, use
only an extension lead which is in good condition, has an earthed plug
and is suited to the power of the appliance.
• Do not unplug the appliance by pulling on the cord.
8
USING
• Use a flat, stable, heat-resistant work surface away from any water
splashes.
• Do not allow the base of the appliance to come into contact with water.
• Never try to operate the appliance when the pot is empty or without
the pot.
• The cooking function/knob must be allowed to operate freely. Do not
prevent or obstruct the function from automatically changing to the
keep warm function.
• Do not remove the pot while the appliance is working.
• Do not put the appliance directly onto a hot surface, or any other source
of heat or flame, as it will cause a failure or danger.
• The pot and the heating plate should be in direct contact. Ensure that
no food or liquid is inserted between the pot and heating plate.
• Do not place the appliance near a heat source or in a hot oven, as
serious damage could result.
• Do not put any food or water into the appliance until the pot is in place.
• Respect the levels indicated in the recipes.
• Should any part of your appliance catch fire, do not attempt to put it
out with water. To smother the flames use a damp tea towel.
• Any intervention should only be made by an authorized or approved
service centre with original spare parts.
• Always disconnect the appliance from the supply if it is left unattended
and before assembling, disassembling or cleaning.
9
ENPROTECT THE ENVIRONMENT
• Your appliance has been designed to operate for many years. However,
when you decide to replace it, remember to think about how you can
contribute to protecting the environment.
• Before discarding your appliance you should remove the battery from
the timer and dispose of it at a local civic waste collection centre
(according to model).
Environment protection first!
Your appliance contains valuable materials which can be
recovered or recycled.
Leave it at a local civic waste collection point.
BEFORE FIRST USE
USING YOUR RICE COOKER
• Open the lid by pressing the lid opening button on the handle– fig.1.
• Remove the cooking pot and inner lid – fig.2.
• Clean the pot and inner lid with a sponge and washing up liquid.- fig.3
• Wipe the outside of the appliance and the lid with a damp cloth.
• Dry off carefully.
• Put all the elements back in their original position. Install the detachable
cord into the socket on the cooker base. – fig. 4.
Measuring the ingredients - Max capacity of the bowl
• The graduated markings on the inside of the pot are given in cups, these
are used for measuring the amount of water when cooking rice and
cereals.
• The maximum quantity of water + rice should not exceed the 4 cups mark
inside the pot – fig.5.
• The plastic cup provided with your appliance is for measuring rice.
• To cook 1 cup of rice (serves 2 small or 1 large portion), use 1 measuring
cup of rice and then add water to the water level indication inside the pot.
To cook other quantity of rice, please refer to relative water level.
• The water quantity can be adjusted depending on your taste.
10
COOKING GUIDE -White RICE For Example
Measuring cups of white rice Water level in the pot (+ the
rice) Serving per person
1 1 cup rice mark 1-2
2 2 cup rice mark 2-3
3 3 cup rice mark 3-4
4 4 cup rice mark 4-5
Note: Always add the rice first otherwise you will have too much water.
COOKING PROGRAM
Rice and Steam
– Use the “Switch” to choose rice or steam function. - Fig 6 When the
program is chosen and then press “Cooking Button” to start the cooking.
The “Cook” indicator is on during the cooking process.
– When cooking rice, at the end of cooking, the “Cooking Button” will be
lifted automatically, and the rice cooker will enter keep warm status with
the “Warm” indicator on.
– Please maintain “Keep Warm” status for several minutes before serving for
good taste of rice.
– When steaming, you need to lift the cooking button manually at the end
of cooking. Then, it will enter keep warm status with the “Warm” indicator
on.
– Please make sure to put enough water inside the pot to avoid dry heating.
Keep Warm
– When the rice cooker is powered on, “Cooking Button” is lifted, it will
enter keep warm status automatically with the “Warm” indicator on.
– You have to stop the keep warm status manually by pulling off the
power cord or cutting off electricity supply.
Note: Please do not keep warm for rice for more than 6 hours.
