Technovare OPS-DRD2 Manuel utilisateur

OPS-DRD2 USERS MANUAL

v1.2

_OPS-DRD2 : OPS Digital Signage Player_

Users Manual

v1.2

03/15/2017

OPS Form Factor Android Player for Commercial Applications

OPS-DRD2 USERS MANUAL

v1.2

The documentation and the software included with this product are copyrighted 2017 by

Technovare Systems Inc. All rights are reserved. Technovare Systems Inc. reserves the right to

make improvements in the products described in this manual at any time without notice. No part

of this manual may be reproduced, copied, translated or transmitted in any form or by any means

without the prior written permission of Technovare Systems Inc. Information provided in this

manual is intended to be accurate and reliable. However, Technovare Systems Inc. assumes no

responsibility for its use, nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

Android is a trademark of Google Corporation.

Technovare is a trademark of Technovare Systems Inc.

All other product names or trademarks are properties of their respective owners.

OPS-DRD2 USERS MANUAL

v1.2

Product Warranty (36 Months)

Technovare warrants to you, the original purchaser, that each of its products will be free from

defects in materials and workmanship for 36 Months from the date of purchase. This warranty

does not apply to any products which have been repaired or altered by persons other than repair

personnel authorized by Technovare, or which have been subject to misuse, abuse, accident or

improper installation. Technovare assumes no liability under the terms of this warranty as a

consequence of such events. Because of Technovare’s high quality-control standards and

rigorous testing, most of our customers never need to use our repair service. If a Technovare

product is defective, it will be repaired or replaced at no charge during the warranty period. For

out of warranty repairs, you will be billed according to the cost of replacement materials, service

time and freight. Please consult your dealer for more details.

Technical Support and Assistance

Visit the NEC Display Solutions Support website at:

http://nec-display-solutions.com/p/hq/en/home.xhtml

Contact your distributor, sales representative, or NEC’s customer service center for technical

support if you need additional assistance. Please have the following information ready before

you call:

•Product name and serial number

•Description of installed peripheral attachments

•Description of installed software

o(operating system, version, application software, etc.)

•A complete description of the problem

•The exact wording of any error messages

If you think you have a defective product, follow these steps:

1. Call your dealer and describe the problem. Please have your manual, product, and any helpful

information readily available.

2. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization)

number from your dealer. This allows us to process your return more quickly.

OPS-DRD2 USERS MANUAL

v1.2

3. Carefully pack the defective product, a fully-completed Repair and Replacement Order Card

and a photocopy proof of purchase date (such as your sales receipt) in a shippable container. A

product returned without proof of the purchase date is not eligible for warranty service.

Technovare shall not be responsible for lost, stolen or misdirected mail or for damage to the

product incurred during shipping.

4. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.

Packing List

Before installation, please ensure the following items have been shipped with the unit:

•1 x OPS-DRD2 Unit

•1 x WiFi Antenna

OPS-DRD2 USERS MANUAL

v1.2

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions for passing

included the equipment being operated within an industrial enclosure. In order to protect the

product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly

recommend the use of CE-compliant industrial enclosure products.

FCC Warning Statement

Changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

-- Consult the dealer or an experienced radio/TV technician for help

FCC Radiation Exposure Statement

The antennas used for this transmitter must be installed to provide a separation distance of at

least 20 cm from all persons and must not be co-located or operating in conjunction with any

other antenna or transmitter.

OPS-DRD2 USERS MANUAL

v1.2

Warnings, Cautions and Notes

Warning!

Warnings indicate conditions, which if not observed, can cause personal injury!

Caution!

Cautions are included to help you avoid damaging hardware or losing data. e.g.

There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to

recharge, force open, or heat the battery. Replace the battery only with the same or equivalent

type recommended by the manufacturer. Discard used batteries according to the manufacturer's

instructions.

Note!

Notes provide optional additional information.

OPS-DRD2 USERS MANUAL

v1.2

Safety Instructions

CARE SHALL BE TAKEN TO STORE AND OPERATE THIS EQUIPMENT ACCORDING TO ITS

SPECIFICATIONS.

DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE

MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C (140° F). THIS COULD DAMAGE THE EQUIPMENT.

THE EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.

•Place this equipment on a reliable surface during installation. Dropping it or letting it fall

may cause damage.

•The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

•All cautions and warnings on the equipment should be noted.

•Never pour any liquid into an opening. This may cause fire or electrical shock.

•Never open the equipment. For safety reasons, the equipment should be opened only by

qualified service personnel.

•If one of the following situations arises, get the equipment checked by service personnel:

oLiquid has penetrated into the equipment.

oThe equipment has been exposed to moisture.

oThe equipment does not work well, or you cannot get it to work according to the

user's manual.

oThe equipment has been dropped and damaged.

oThe equipment has obvious signs of breakage.

Caution!

DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

Table of Contents

OPS-DRD2 USERS MANUAL

v1.2

8 | Page

Product Specifications ........................................................................................9

General.................................................................................................................................................. 9

Power ..................................................................................................................................................10

Mechanical.......................................................................................................................................... 10

Environmental..................................................................................................................................... 10

External Connections ........................................................................................11

Bottom of Card (BOC) ......................................................................................................................... 11

Top of Card (TOC)................................................................................................................................11

Installation .......................................................................................................13

Operating Instructions ......................................................................................15

Power ON ............................................................................................................................................ 15

Power OFF........................................................................................................................................... 16

Navigation Bar..................................................................................................................................... 16

Restore Factory Defaults.....................................................................................................................19

Applications......................................................................................................22

Factory Installed Applications............................................................................................................. 22

Installing New Applications................................................................................................................. 38

Uninstalling Applications .................................................................................................................... 40

Adding/Removing Installed Applications from Desktop..................................................................... 41

System Configuration .......................................................................................43

WLAN Configuration ...........................................................................................................................43

LAN Configuration............................................................................................................................... 47

Backup and Restore ..........................................................................................50

User Data Backup................................................................................................................................ 50

User Data Restore ............................................................................................................................... 51

System Software Updates.................................................................................52

Over-The-Air (OTA) Update.................................................................................................................53

Local Update ....................................................................................................................................... 54

OPS-DRD2 USERS MANUAL

v1.2

9 | Page

Product Introduction

The OPS-DRD2 is a full-featured media player running the Android operating system and

packaged in an OPS form-factor. Targeted for Commercial Applications such as Digital Signage,

Quick Service Restaurant, and/or Display Walls, the OPS-DRD2 is based on a 2.0 GHz Quad Core

ARM processor with an integrated Multi-Media Processor capable of 4k playback and the ability

to run certified third party software.

The OPS-DRD2 supports true 4k / UHD / 1080P video with hardware assisted support for formats

such as H.265, H.264, MPEG4 and WM9. The OPS-DRD2 was designed with display integration in

mind, and can be plugged directly into any LCD supporting the Open Pluggable Specification

(OPS). Power, Video, Audio, and Serial control are all accessible thru the units OPS connector,

thus eliminating the need for external cabling.

The OPS-DRD2’s external connections include 2 USB 2.0 for connection to keyboard, mouse,

flash, or touch screen, 100/1000 LAN, 802.11b/g/n Wifi, Audio, and a SD Card slot for integrated

storage.

Product Specifications

General

Operating System Android Lolipop 5.1

CPU

ARM Cortex A53 Quad-Core @ 2.0 GHz

GPU

Integrated Mali 450

RAM

2 GB DDR3-1333, Dual Channel (2 x 512M)

Flash

32 GB NAND

Video

OPS-HDMI v1.4

4k @ 24 Hz, UHD @ 30 Hz

Audio

OPS-Analog, Stereo

Network

100/1000BT Ethernet

802.11.b/g/n Wireless

I/O

OPS-UART (3.3V LVTTL)

USB 2.0 x 2

SD Card Slot

System Monitor Watch Dog Timer

OPS-DRD2 USERS MANUAL

v1.2

10 | Page

Power

Input Power 12.0 V – 19.0 V (16.0V Nominal)

Power Consumption

Idle : 2.5 Watts

Max : 8.0 Watts

Mechanical

Dimensions

OPS Form Factor (200mm x 119mm x 30mm)

Weight

1.2 lbs / 0.52 kg

Gross Weight

2.2 lbs / 0.98 kg

Environmental

Operating Temperature

0 °C to +40 °C Ambient

Operating Humidity

80 % max, relative humidity, non-condensing

Storage Temperature

-20 °C to +60 °C

EMC FCC Section 15
