Technics OTTAVA S Manuel utilisateur

Operating Instructions

Wireless Speaker System

SC-C50 / SC-C30

(Image: SC-C50)

Music is borderless and timeless, touching

people’s hearts across cultures and

generations.

Each day the discovery of a truly emotive

experience from an unencountered sound

awaits.

Let us take you on your journey to rediscover

music.

Delivering the Ultimate Emotive

Musical Experience to All

At Technics we understand that the listening

experience is not purely about technology but

the magical and emotional relationship between

people and music.

We want people to experience music as it was

originally intended and enable them to feel the

emotional impact that enthuses and delights

them.

Through delivering this experience we want to

support the development and enjoyment of

the world’s many musical cultures. This is our

philosophy.

With a combination of our love of music and the

vast high-end audio experience of the Technics

team, we stand committed to building a brand

that provides the ultimate emotive musical

experience by music lovers, for music lovers.

Director

Michiko Ogawa

Thank you for purchasing this product.

Please read these instructions carefully before using

this product, and save this manual for future use.

•About descriptions in these operating instructions

Pages to be referred to are indicated as “⇒○○”.

The illustrations shown may differ from your

unit.

Sales and Support Information

Customer Communications Centre

•For customers within the UK: 0333 222 8777

•For customers within Ireland: 01 447 5229

•Monday–Friday 9:00 am – 5:00 pm, (Excluding

public holidays).

•For further support on your product, please visit

our website: www.technics.com/uk/

Features

Amazingly clear and deep sound

in room-filling soundstage

Speakers are optimally positioned in its

compact, arc form design. These are

powerfully driven by a 2.1-channel full digital

amp to obtain room-filling Hi-Fi sound.

Optimising sound for any music

listening environment

Space Tune™ optimises the sound no matter

where it is placed or where you are listening.

A built-in microphone enables a new Auto

function to optimise the listening environment

from the main unit or a smartphone app with

a simple operation.

Broad selection of streaming

services, easy-to-use controls

An easy-to-use connectivity supports USB,

analogue input (AUX), optical input, AirPlay,

Bluetooth®, Chromecast built-in, Spotify,

TIDAL, Deezer, internet radio and Network

Playback (access stored music), allowing

comfortable playback of a diverse range of

music sources from a single unit.

Table of contents

Read first 06

Please carefully read the “Safety precautions” of

this manual before use.

Control reference guide 15

This unit (front/top/rear)

Connections 20

AC mains lead connection, Network settings

Operations 30

Streaming online music, etc.

Settings 48

Favourite function, Other settings

Others 52

Troubleshooting, Specifications, etc.

AC mains lead (1)

K2CT3DR00009

•The smartphone on the cover page is not supplied

with this unit.

•Product numbers provided in these operating

instructions are correct as of August 2019.

•These may be subject to change.

•Do not use AC mains lead with other equipment.

Accessories

Read first

Safety precautions............................... 07

Warning.................................................... 07

Caution..................................................... 07

Installation ........................................... 12

Installation .................................................12

Notes on the speakers................................12

For optimum sound effects ........................12

Unit care ....................................................13

Using “Technics Audio Center”...................13

Firmware updates ......................................13

To dispose of or transfer this unit .............. 14

Table of contents ... 04

Read first

Safety precautions

(Continued)

Warning

Unit

•To reduce the risk of fire, electric shock or product

damage,

Do not expose this unit to rain, moisture,

dripping or splashing.

Do not place objects filled with liquids, such as

vases, on this unit.

Use the recommended accessories.

Do not remove covers.

Do not repair this unit by yourself. Refer

servicing to qualified service personnel.

Do not let metal objects fall inside this unit.

Do not place heavy items on this unit.

AC mains lead

•To reduce the risk of fire, electric shock or product

damage,

Ensure that the power supply voltage

corresponds to the voltage printed on this unit.

Insert the mains plug fully into the socket outlet.

Do not pull, bend, or place heavy items on the

lead.

Do not handle the plug with wet hands.

Hold onto the mains plug body when

disconnecting the plug.

Do not use a damaged mains plug or socket

outlet.

•The mains plug is the disconnecting device.

Install this unit so that the mains plug can be

unplugged from the socket outlet immediately.

•Ensure the earth pin on the mains plug is securely

connected to prevent electrical shock.

An apparatus with CLASS I construction shall

be connected to a mains socket outlet with a

protective earth connection.

Caution

Unit

•Do not place sources of naked flames, such as

lighted candles, on this unit.

•This unit may receive radio interference caused by

mobile telephones during use. If such interference

occurs, please increase separation between this

unit and the mobile telephone.

•This unit is intended for use in moderate and

tropical climates.

•Do not put any objects on this unit. This unit

becomes hot while it is on.

(Continued)

Placement

•Place this unit on an even surface.

•To reduce the risk of fire, electric shock or product

damage,

Do not install or place this unit in a bookcase,

built-in cabinet or in another confined space.

Ensure this unit is well ventilated.

Do not obstruct this unit’s ventilation openings

with newspapers, tablecloths, curtains, and

similar items.

Do not expose this unit to direct sunlight, high

temperatures, high humidity, and excessive

vibration.

•Keep magnetised items away. Magnetised cards,

watches, etc., can be damaged if placed too close

to this system.

(Continued)

Caution for AC Mains Lead

(For the AC mains plug of three pins)

For your safety, please read the following text

carefully.

This appliance is supplied with a moulded three pin

mains plug for your safety and convenience.

A 3-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure

that the replacement fuse has a rating of 3-ampere

and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark or the BSI mark on

the body of the fuse.

If the plug contains a removable fuse cover you

must ensure that it is refitted when the fuse is

replaced.

If you lose the fuse cover the plug must not be used

until a replacement cover is obtained.

A replacement fuse cover can be purchased from

your local dealer.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type

of AC mains plug (figures A and B). Confirm the AC

mains plug fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1.Open the fuse cover with a screwdriver.

Figure A Figure B

Fuse cover

2.Replace the fuse and close or attach the fuse

cover.

Figure A Figure B

Fuse

(3 ampere)

Fuse

(3 ampere)

(Continued)

Panasonic Corporation, a company having

its registered office of 1006, Oaza Kadoma,

Kadoma City, Osaka 571-8501, Japan,

automatically collects personal data such as IP

address and/or Device ID from your device as

soon as you connect it to the Internet. We do

this to protect our customers and the integrity

of our Service as well as to protect the rights or

property of Panasonic.

You have a right of access, rectification and

objection to in certain circumstances, a right

of erasure, restriction of processing, data

portability and a right to object to other forms

of processing. If you wish to exercise any of

the above rights and/or wish to know more

about the processing of your personal data in

this context, please refer to the full text of our

your device, http://panasonic.jp/support/global/

cs/audio/, http://www.technics.com/support/

or contact our customer communications/

support number or address described in the Pan

European Guarantee included in your device box

to send you the full text of our privacy policy.

Disposal of Old Equipment

Only for European Union and countries

with recycling systems

This symbol on the products,

packaging, and/or accompanying

documents means that used

electrical and electronic products

must not be mixed with general

household waste.

For proper treatment, recovery and

recycling of old products, please

take them to applicable collection

points in accordance with your

national legislation.

By disposing of them correctly, you

will help to save valuable resources

and prevent any potential negative

effects on human health and the

environment.

For more information about

collection and recycling, please

contact your local municipality.

Penalties may be applicable for

incorrect disposal of this waste, in

accordance with national legislation.
