TRAILEADER INSTRUCTIONS

TABLE OF CONTENT

OVERVIEW

TIME MENU / SYSTEM SETTING

1.0 TIME/DATE MODE: p. 5

2.0 ALARM MODE: p. 9

3.0 CHRONOGRAPH MODE: p. 11

4.0 COUNTDOWN TIMER MODE: p. 13

5.0 DUAL TIME MODE: p. 14

TRaIl MENU

6.0 SPEED & DISTANCE. MODE: p. 15

7.0 ALTIMETER MODE: p20

8.0 BAROMETER MODE: p 26

9.0 COMPASS MODE: p. 29

10.0 TROUBLESHOOTING: p. 32

11.0 REGISTRATION: p. 37

12.0 WARRANTY: p. 37

13.0 FUNCTION INDEX: p. 38

see for ready reference

Thank you for purchasing the Tech4O Traileader. The Traileader represents the next generation of

outdoor watches in style and technology. The Traileader combines key outdoor functions as well as

your speed and distance measurements via accelerometer technology.

Follow this manual to guide you through the initial setup and calibration. Keep it for later reference as

you learn the more advanced features.

Your new Traileader watch contains many advanced sensors and components. In enjoying your new

watch, please use it in the manner in which it was intended and avoid exposing the watch to

extreme temperatures, impacts, and moisture. In addition, avoid using the watch near magnets,

or objects and appliances that contain magnets, as the watches sensors may be damaged and

inaccurate results may occur.

The Traileader has several functions per button. To see what they do, refer to ﬁg.1.

ESC

Displays time or trail menu

Returns to previous screen

LIGHT

Illuminates backlight

MODE

Selects modes

Conﬁrms selections

Enters settings modes

ST/STP

Toggles display up

Increases values

View alternative displays

Starts/stops timers

LAP/RESET

Toggles display down

Decreases values

Changes units

Starts/stops speed & distance mode

Enters laps and resets timers

ST/STP

ESC

LIGHT

MODE

PLUS

MINUS

DOWN

OVERVIEW

ﬁg. 1

Note: The Traileader watch has

two main menus. See ﬁg. 2 & 3.

Understanding the two menus

and their corresponding functions

will be the key to navigating and

understanding your new watch

and to aid you in your initial setup

and future use.

ESC

ﬁg. 2

ﬁg. 3

TImE mEnu TRaIl mEnu

1.0 TIME/DATE MODE

The TraiLeader’s Time/Date mode not only

displays the current time and date , but also a

quick check of four other key environmental

elements: Altitude, Pressure, Weather, and

Temperature. The Time/Date mode is also

where many of the TraiLeader’s system

setting are adjusted.

1.1 TIME/DATE DISPLAy

• To access the Time/Date display while

currently in a:

* Time Menu function - continue

pressing Muntil the display in ﬁg. 4 is

visible

* Trail Menu function - press ESC twice

to access the Time Menu and press ST/

STP(uP) or LAP/RST(DOwn) to scroll

to the TIME icon

• Display Features:

* Top Row: One of the following: (day

of week, weather forecast, current

temperature, altitude graph, pressure

graph)

* Press ST/STP to scroll through the

various top row displays

* Middle Row: Current Time

* Bottom Row: Current Date

Note: The Traileader’s weather

forecasting system uses changes in

air pressure to predict future weather

conditions. Keep in mind that changes in

altitude also effect air pressure and will

skew the weather forecasting system’s

accuracy. The weather forecasts will be

most accurate when a relatively stable ¬

Pressure

ﬁg.4

TImE/ DaTE mODE

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/

System set menu

• Press Mto select the Time

* Press ST/STP or LAP/RST to reset the

seconds to 00.

* Press Mto conﬁrm your selection

* Press ST/STP(+) or LAP/RST( - )

to adjust the minutes

* Press Mto conﬁrm your selection

* Press the ST/STP(+) or LAP/RST( - )

to adjust the hour

* Press Mto conﬁrm your selection

* Press the ST/STP(+) or LAP/RST( - )

to adjust the time format (12 / 24hr)

* Press Mto conﬁrm your selection

• Press ESC to exit Time

• Press ESC to exit the Time/Date/System set

1.3 ADJuST DATE

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/

System set menu ¬

ﬁg.5

altitude is maintained for several hours. For

a more in depth explanation of the altitude/

pressure/weather relationship, reference

section 10.0 Troubleshooting.

SySTEM SETTInG See ﬁg.5

1.2 ADJuST TIME

• Press LAP/RST(DOwn) to scroll to Date

• Press Mto select the Date

* Press ST/STP(+) or LAP/RST( - )

to adjust the year

* Press M to conﬁrm your selection

* Press ST/STP(+) or LAP/RST( -

to adjust the month

* Press Mto conﬁrm your selection

* Press ST/STP(+) or LAP/RST( - )

to adjust the day

* Press M to conﬁrm your selection

• Press ESC to exit Date

• Press ESC to exit the Time/Date/System set

1.4 ADJuST LCD SCREEn COnTRAST

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/

System set menu

• Press LAP/RST(DOwn) to scroll to General

* Press Mto select General

* Press Mto select LCD

* Press ST/STP(+) or LAP/RST( - ) to

adjust contrast level of the display

* Press ESC to conﬁrm your selection

and exit LCD

• Press ESC to exit General

• Press ESC to exit the Time/Date/System set

1.5 TuRn On/OFF SOunD

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

•Hold Mfor 3 seconds to enter Time/Date/

System set menu

• Press LAP/RST(DOwn) to scroll to General

• Press Mto select General

* Press LAP/RST(DOwn) to scroll

to Sound

* Press Mto select Sound

* Press Mto select Keytone

* Press ST/STP(+) or LAP/RST( - )

to select keytone preference

* Press ESC to conﬁrm your selection

and exit Keytone

*Press ESC to exit Sound

• Press ESC to exit General

• Press ESC to exit the Time/Date/System set

TImE mEnu SYSTEm SETTInGS

1.6 TuRn On/OFF HOuRLy CHIME

Access the Time/Date display (See section 1.1 for

how to access the Time/Date display)

•Hold Mfor 3 seconds to enter Time/Date/System

set menu

• Press LAP/RST(DOwn) to scroll to General

• Press M to select General

* Press LAP/RST(DOwn) to scroll to Sound

* Press Mto select Sound

* Press LAP/RST(DOwn) to scroll to Chime

* Press Mto conﬁrm your selection

* Press ST/STP(+) or LAP/RST( - ) to select

hourly chime preference

* Press ESC to conﬁrm your selection and

exit Chime

* Press ESC to exit Sound

• Press ESC to exit General

• Press ESC to exit the Time/Date/System set menu

1.7 ADJuST BACKLIGHT SETTInG

Access the Time/Date display (See section 1.1 for

how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/System

set menu

• Press LAP/RST(DOwn) to scroll to General

• Press Mto select General

* Press LAP/RST(DOwn) to scroll

to Light

* Press Mto conﬁrm your selection

* Press ST/STP(+) or LAP/RST( - )

to select light preference

* Press ESC to conﬁrm your selection

and exit Light

• Press ESC to exit General

• Press ESC to exit the Time/Date/System set

1.8 ADJuST TEMPERATuRE unITS

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold M for 3 seconds to enter Time/Date/

System set menu

• Press LAP/RST(DOwn) to scroll to Unit

• Press Mto select Unit

* Press Mto select Temp.

* Press ST/STP(+) or LAP/RST( - )

to select preferred unit of measure

* Press ESC to conﬁrm your selection

and exit Temp ¬

• Press ESC to exit Unit

• Press ESC to exit the Time/Date/System set

menu.

1.9 ADJuST PRESSuRE unITS

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/

System set menu

• Press LAP/RST(DOwn) to scroll to Unit

• Press Mto select Unit

* Press LAP/RST(DOwn) to scroll

to Pressure

* Press Mto select Pressure

* Press ST/STP(+) or LAP/RST( - ) to

select the preferred unit of measure

* Press ESC to conﬁrm your selection

and exit Pressure

• Press ESC to exit Unit

• Press ESC to exit the Time/Date/System set

1.10 ADJuST SPEED & DISTAnCE unITS

Access the Time/Date display (See section 1.1

for how to access the Time/Date display)

• Hold Mfor 3 seconds to enter Time/Date/

System set menu

• Press LAP/RST(DOwn) to scroll to Unit

• Press M to select Unit

* Press the LAP/RST(DOwn) to scroll

to Other

* Press M to select/other

* Press ST/STP(+) or LAP/RST( - ) to

select your preferred unit of measure

* Press ESC to conﬁrm your selection

and exit Other

• Press ESC to exit Unit

• Press ESC to exit the Time/Date/System set

2.0 ALARM MODE

The Traileader has several alarm features.

Alarm mode can be set for a speciﬁc day

of the week, daily, or turned off entirely

• To access the Alarm display while currently

in a:

* TIME MEnu function - continue

pressing Muntil the display in ﬁg. 6 is

visible ¬

alaRm

TImE mEnu SYSTEm SETTInGS

* Press ST/STP(+) or LAP/RST( - )

to adjust the alarm hour

* Press Mto conﬁrm your selection

* Press ST/STP(+) or LAP/RST( - )

to adjust the alarm minute

* Press ESC to conﬁrm your selection

• Repeat the above steps to set additional

alarms

or or

ST/STP ALARM 1 OR 2

ﬁg.7

* TRAIL MEnu function -

press ESC twice to access

the Time Menu and press

ST/STP(uP) or LAP/

RST(DOwn) to scroll to

the ALM icon

• Display Features:

* Top Row: Alarm number 1 or 2

* Press ST/STP to select between the

two alarms

* Middle Row: Alarm Time

* Bottom Row: Alarm Status

2.2 ALARM SETTInG See ﬁg. 7

Access the Alarm display (See section 2.1 for how to

access the Alarm display)

• Press ST/STP to select the alarm you wish to set

• Hold Mfor 3 seconds to enter Alarm set mode

* Press ST/STP or LAP/RST to select the

frequency of the alarm or turn the alarm off

* Press Mto conﬁrm your selection

* When an alarm is scheduled, the alarm

icon will appear at the bottom

of the display

ﬁg.6
