Raptor 2100T Features

•2048 x 2048 Resolution

•8/16/24/32-Bits Per Pixel

•64 MB Frame Buffer

•32 Independent Overlays

•2560 Dynamic Colors

•Single Slot PCI Card

•Supports Transparency &

Translucency

Markets

•Air Traffic Management

•Vessel Traffic Control

•Command & Control

•Remote Auction Art

Platforms

•Sun Desktops/Servers

•Digital Alpha Workstations

•Linux based PCs

•Windows 2000

Product Brief

Raptor 2100T

2048 x 2048 Color Video Graphics Adapter

The Tech Source Raptor 2100T graphics

accelerator combines on a single slot PCI

card, a comprehensive array of high-end

display subsystem features. The Raptor

2100T uses Tech Source's state-of-the-art

graphics technology and addresses all the

specific requirements of target markets

like Air Traffic Management, Vessel

Traffic Control and other Command &

Control applications. Its high level of

integration achieves extreme flexibility

over a wide range of functions. With a

resolution of 2048x2048, it is designed to

work well with the Sony DDM monitors.

With 64MB of on-board memory and an

efficient memory manager, the card

offers excellent drawing performance

with minimum host CPU usage. The

card provides 2560 independent

dynamic colors. That's ten times the

number of indexed colors available on

traditional graphics systems. Specialized

layering hardware allows for complete

control of up to 32 independently

addressable overlays with dynamic layer

priority adjustment. This hardware

supports both transparency & translu-

cency (blending). The card can also be

configured in a 24-bit True Color mode

for Remote Auction Art and other high

resolution image viewing applications.

The Raptor 2100T offers excellent 2D

acceleration for polygons, text, lines, copy

and other windowing operations. This

provides seamless ability to manage over

5000 targets/tracks in real time. Another

feature of this high performance product

is the specialized fill hardware that

performs back buffer screen erases at an

extremely high speed. The video output

quality of the Raptor 2100T has been

meticulously fined tuned and is easily the

best amongst all graphics products in its

category.

3340 Edgewater Dr.

Orlando, FL 32804

407.262.7100

www.techsource.com

Tech Source, the Tech Source logo, and Raptor 2100T are trademarks of Tech Source, Inc. All other trademarks are the property

without notice. Tech Source, Inc. assumes no responsibility for errors or omissions that may appear in this document.

Raptor 2100T Technical Specifications

Raptor 2100T PCI video graphics adapter, 2048 by 2048 color resolution, 64 MB frame buffer, includes DB-5-W5 to

5BNC video cable, operating system specific device driver software and manuals.

Raptor OpenWindows for Solaris Loadable drivers for Sun PCI systems running Solaris 2.6, 7, 8 and 9.

Raptor X Servers for Digital UNIX Loadable drivers for the Digital/Compaq Alpha workstations running Tru64

UNIX 4.0f, 5.0, 5.1.

Raptor Drivers for Linux Loadable drivers for Red Hat & SUSE Linux on x86 based machines

Raptor Drivers for Windows Loadable drivers for Windows 2000

Specifications

Frame Buffer Size 64MB

Color Lookup Table 2048 entries from a palette of 16.7 million colors + 2 AUX 256

Bits Per Pixel 8, 16, 24 or 32 (software configurable)

Dynamic Color Plane Groups 32

PCI Interface 33/66 MHz 32/64-bit Revision 2.2

Video Interface Red, green and blue at RS-343 levels (50 ohm)

Video Sync Separate sync at TTL levels (75 ohm)

Video Connector DB-5-W5

Temperature Rating 100to 500C (operating)

-100to 700C (non-operating)

Humidity Rating 10% to 90% (non-condensing)

Power Rating Less than 25 watts

Physical 12.283 inches x 4.2 inches (PCI long format)

Software Available

March 8, 2006
