ZNP-H750 Release Notes
Updates
Always use the most recent firmware for this device.
Please visit the TEAC website (http://audio.teac.com/support/downloads/) to check for the latest firmware.
Maintenance items
May 2013 fixes
Fixes from version s9267.10051.0 to version s9267.10057.0
o Some CDs with pre-emphasis would have low volume when
played back. This has been fixed.
o When turning the unit on again after it had been in standby, the
tone settings (BASS and TREBLE) would be changed. This has
been fixed.
o The digital input frequency display would occasionally blink
during playback. This has been fixed.
o The number of characters used was insufficient for some wire-
less security types. This has been fixed.
Number of characters that can be used: 63 ASCII
Number of input characters: 64 hexadecimal digits (256-bit)
Contents
Updates ......................................................................................................................................1
Maintenance items ...........................................................................................................................1
Checking the firmware version................................................................................................................2
Firmware update procedures .................................................................................................................3
0513 MA-1969A
ZNP-H750 Release Notes
2
Checking the firmware version
Check the firmware version of your NP-H750 before starting firm-
ware updating procedures.
1 Press the SOURCE button repeatedly to select net-
work mode.
o You can also use the remote control's NET button.
2 Press the NET button to select“Internet Radio”.
Each time you press the NET button, the source switches
between Internet radio and media player.
o You can also use the remote control's NET button.
3 Press the MENU button to select “Setup Menu”.
4 Turn the MULTI JOG knob to select “Information”,
and then press the ENTER button.
The menu item changes as follows:
Device Name Edit qNet work qInformation qSoftware
Update q(Return to) Device Name Edit
or
5 Turn the MULTI JOG knob to select “Firmware
Version”, and then press the ENTER button.
The firmware version will appear on the display.
Firmware Version
s9267.10057.0
3
ZNP-H750 Release Notes
Firmware update procedures
Copy the “TEAC_NPH750_MCU_BCO_20B0505_S9267_V10057.fw”
updater file to an empty USB flash drive in advance.
NOTE Uncompress the downloaded file.
1 Press the SOURCE button repeatedly to select net-
work mode.
o You can also use the remote control's NET button.
2 Press the NET button to select“Internet Radio”.
Each time you press the NET button, the source switches
between Internet radio and media player.
o You can also use the remote control's NET button.
3 Press the MENU button to select “Setup Menu”.
4 Turn the MULTI JOB knob to select “Software
Update”, and then press the ENTER button.
Device Name Edit qNet work qInformation qSoftware
Update q(Return to) Device Name Edit
or
Setup Menu
›Software Update
5 Turn the MULTI JOG knob to select “USB”, and then
press the ENTER button.
“Check USB Memory”will appear on the display.
6 Connect the USB ash drive that contains the“TEAC_
NPH750_MCU_BCO_20B0505_S9267_V10057.fw”
updater le to the USB port in the unit's front panel.
Setup Menu
›Check USB Memory
When the firmware update is completed, the unit will restart
automatically.
7 When the unit has nished restarting, unplug the
power cord from the outlet, and turn the unit on
again.
You will need to adjust the clock and set the timer again.
