Teac MD-5 Manuel utilisateur

md-5

MINIDISC DECK

3D0020100A

This appliance has a serial number located

on the rear panel. Please record the model

number and serial number and retain them

for your records.

Model number

Serial number

WARNING: TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature

accompanying the appliance.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure

that may be of sufficient magnitude to constitute a risk of electric shock to persons.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Thanks for buying a TEAC. Read this manual carefully to get the

best performance from this unit.

Nous vous remercions pour l’achat d’un appareil TEAC.

Lire ce manuel avec attention pour obtenir les meilleures perfor-

mances possibles de cet appareil.

Vielen Dank für den Kauf dieses TEAC-Geräts.

Bitte lesen Sie diese Anleitung sorgfältig durch, um die Leistungs-

fähigkeit dieses Geräts optimal nutzen zu können.

Grazie per aver acquistato un prodotto TEAC.

Leggere attentamente questo manuale per ottenere le migliori

prestazioni da questo apparecchio.

Enhorabuena por la adquisición de un TEAC.

Lea detenidamente este manual a fin de obtener el mejor rendi-

miento de esta unidad.

OWNER’S MANUAL ..................................4

MANUEL DUPROPRIETAIRE .................23

BEDIENUNGSANLEITUNG......................42

MANUALE DI ISTRUZIONI......................61

MANUAL DEL USUARIO.........................80

ENGLISHFRANÇAISDEUTSCHITALIANO

ESPAÑOL

IMPORTANT SAFETY INSTRUCTIONS

– 2 –

CAUTION:

●Read all of these Instructions.

●Save these Instructions for later use.

●Follow all Warnings and Instructions marked on the audio

equipment.

1) Read Instructions — All the safety and operating instructions should be

read before the product is operated.

2) Retain Instructions — The safety and operating instructions should

be retained for future reference.

3) Heed Warnings — All warnings on the product and in the operating

instructions should be adhered to.

4) Follow Instructions — All operating and use instructions should be

followed.

5) Cleaning — Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning.

6) Attachments — Do not use attachments not recommended by the

product manufacturer as they may cause hazards.

7) Water and Moisture — Do not use this product near water _for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet

basement; or near a swimming pool; and the like.

8) Accessories — Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing serious injury to a

child or adult, and serious damage to the product. Use only with a cart,

stand, tripod, bracket, or table recommended by the manufacturer, or sold

with the product. Any mounting of the product should follow the

manufacturer’s instructions, and should use a mounting accessory

recommended by the manufacturer.

9) Aproduct and cart combination should be moved with care. Quick

stops, excessive force, and uneven surfaces may cause the product and

cart combination to overturn.

10) Ventilation — Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the product and to protect

it from overheating, and these openings must not be blocked or covered.

The openings should never be blocked by placing the product on a bed,

sofa, rug, or other similar surface. This product should not be placed in a

built-in installation such as a bookcase or rack unless proper ventilation is

provided or the manufacturer’s instructions have been adhered to.

11) Power Sources — This product should be operated only from the

type of power source indicated on the marking label. If you are not sure of

the type of power supply to your home, consult your product dealer or

local power company. For products intended to operate from battery

power, or other sources, refer to the operating instructions.

12) Grounding or Polarization — This product may be equipped with a

polarized alternating-current line plug (a plug having one blade wider than

the other). This plug will fit into the power outlet only one way. This is

a safety feature. If you are unable to insert the plug fully into the outlet, try

reversing the plug. If the plug should still fail to fit, contact your electrician

to replace your obsolete outlet. Do not defeat the safety purpose of the

polarized plug.

13) Power-Cord Protection — Power-supply cords should be routed so

that they are not likely to be walked on or pinched by items placed upon or

against them, paying particular attention to cords at plugs, conve-nience

receptacles, and the point where they exit from the product.

14) Outdoor Antenna Grounding — If an outside antenna or cable

system is connected to the product, be sure the antenna or cable system

is grounded so as to provide some protection against voltage surges and

built-up static charges. Article 810 of the National Electrical Code,

ANSI/NFPA 70, provides information with regard to proper grounding of

the mast and supporting structure, grounding of the lead-in wire to an

antenna discharge unit, size of grounding conductors, location of

antenna-discharge unit, connection to grounding electrodes, and re-

quirements for the grounding electrode.

"Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to

Section 820-40 of the NEC which provides guidelines for proper

grounding and, in particular, specifies that the cable ground shall be

connected to the grounding system of the building, as close to the point of

cable entry as practical.

ANTENNA

LEAD IN

WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250. PART H)

NEC - NATIONAL ELECTRICAL CODE

ELECTRIC

SERVICE

EQUIPMENT

Example of Antenna Grounding as per

National Electrical Code, ANSI/NFPA 70

GROUND

CLAMP

15) Lightning — For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect the antenna or cable

system. This will prevent damage to the product due to lightning and

power-line surges.

16) Power Lines — An outside antenna system should not be located in

the vicinity of overhead power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits. When installing an

outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be fatal.

17) Overloading — Do not overload wall outlets, extension cords, or

integral convenience receptacles as this can result in risk of fire or electric

shock.

18) Object and Liquid Entry — Never push objects of any kind into this

product through openings as they may touch dangerous voltage points or

short-out parts that could result in a fire or electric shock. Never spill liquid

of any kind on the product.

19) Servicing — Do not attempt to service this product yourself as

opening or removing covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified service personnel.

20) Damage Requiring Service — Unplug this product from the wall

outlet and refer servicing to qualified service personnel under the

following conditions:

a) when the power-supply cord or plug is damaged.

b) if liquid has been spilled, or objects have fallen into the product.

c) if the product has been exposed to rain or water.

d) if the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating

instructions as an improper adjustment of other controls may result in

damage and will often require extensive work by a qualified technician to

restore the product to its normal operation.

e) if the product has been dropped or damaged in any way.

f ) when the product exhibits a distinct change in performance _ this

indicates a need for service.

21) Replacement Parts — When replacement parts are required, be

sure the service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

22) Safety Check — Upon completion of any service or repairs to this

product, ask the service technician to perform safety checks to

determine that the product is in proper operating condition.

23) Wall or Ceiling Mounting — The product should be mounted to a

wall or ceiling only as recommended by the manufacturer.

24) Heat — The product should be situated away from heat sources such

as radiators, heat registers, stoves, or other products (including

amplifiers) that produce heat.

SAFETY INFORMATION

…CAUTION …ACHTUNG …OBSERVERA …ADVARSEL

– 3 –

This product has been designed and manufactured according to FDA regulations "title 21, CFR, chapter 1, subchapter J, based on the Radiation

Control for Health and Safety Act of 1968", and is classified as class 1 laser product. There is no hazardous invisible laser radiation during operation

because invisible laser radiation emitted inside of this product is completely confined in the protective housings.

The label required in this reguration is shown 1.

…CAUTION

-DO NOT REMOVE THE PROTECTIVE HOUSING USING SCREWDRIVER.

-USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

-IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A CONTACT WITH OUR SERVICEMAN, AND DO NOT USE THE PRODUCT IN A

TROUBLED STATE.

CERTIFICATION

THIS PRODUCT COMPLES WITH DHHS

RULES 21 CFR SUBCHAPTER J APPLI-

CABLE AT DATE OF MANUFACTURE

TEAC CORPORATION

3-7-3 NAKA-CHO, MUSASHINO-SHI, TOKYO, JAPAN

MANUFACTURED TIF

Optical pickup: Type : KMS-260A

Manufacturer : SONY Corporation

Laser output : 4.55 mW

Wavelength : 78520 nm

For U.S.A.

1THIS LABEL IS ATTACHED TO THE PLACE AS ILLUSTRATED TO INFORM THAT THE

APPARATUS CONTAINS A LASER COMPONENT.

1DIESE AUFKLEBEMARKE IST AN DEM IN DER ABBILDUNG GEZEIGTEN ORT

ANGEBRACHT UM DARAUF HINZUWEISEN, DASS IM INNERN DES GERÄTS

EINE LASER-KOMPONENTE BEFINDET.

1PÅSKRIFTEN SITTER PÅ APPARATEN SOM VISAS SOM UPPMANING OM ATT

APPARATEN OMFATTAR EN INBYGGD LASERKOMPONENT.

1DETTE MÆRKAT ER ANBRAGT SOM VIST I ILLUSTRATIONEN FOR AT ADVARE

BRUGEREN OM AT APPARATET INDEHOLDER EN LASERKOMPONENT.

2DETTE MÆRKAT ER SOM VIST PÅ ILLUSTRATIONEN ANBRAGT PÅ INDERSIDEN AF

TOPDÆKSLET FOR AT ADVARE BRUGEREN OM AT YDERLIGERE FREMTRÆNGEN

VIL VÆRE FORBUNDET MED FARE FOR AT UDSÆTTE SIG FOR LASERSTRÅLING.

ADVARSEL — BETJENING AF ANDRE KONTROLLER OG REGULATORER ELLER

BENYTTELES AF ANDRE FREMGANGSMÅDER END BESKREVET HERI ER FOR-

BUNDET MED FARE FOR UDSÆTTELSE FOR LASERSTRÅLING.

VARING: APPARATEN INNEHÅLLER LASER KOMPONENT MED

STRÅLNING ÖVERSTIGANDE KLASS 1.

"ADVARSEL: USYNLIG LASERSTRÅLING VED ÅBNING NAR

SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ

UDSAETTELSE FOR STRÅLING"

"VAROITUS! SUOJAKOTELOA EI SAA AVATA. LAITE SISÄLTÄÄ

LASERDIODIN. JOKA LÄHETTÄ (NÄKYMÄTÖNTÄ) SILMILLE

VAARALLISTA LASERSÄTEILYÄ".

ADVARSEL: USYNLIG LASERBESTRÅLING NÅR DENNE

DELEN ER ÅPEN OG SIKKERHETSSPERREN ER UTKOBLET

UNNGÅ UTSETTELSE FOR STRÅLING.

CLASS 1 LASER PRODUCT

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

VORSICHT! UNSICHTBARE LASERSTRAHLUNGTRITT AUS.

WENN DECKEL GEÖFFNET UND WENN

SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT IST.

NICHT DEM STRAHL AUSSETZEN !

VARNING - OSYNLIG LASERSTRÅLNING NÄR DENNA DEL

ÄR ÖPPNAD OCH SPÄRR ÄR URKOPPLAD.

STRÄLEN ÄR FARLIG.

ADVARSEL - USYNLIG LASERSTRÅLING VED ÅBNING, NÅR

SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.

UNDGÅ UDSÆTTELSE FOR STRÅLING.

VAROITUS! SUOJAKOTELOA EI SAA AVATA. LAITE SISÄLTÄÄ

LASERDIODIN, JOKA LÄHETTÄÄ (NÄKYMÄTÖNTÄ)

SILMILLE VAARALLISTA LASERSÄTEILYÄ.

ADVARSEL - USYNLIG LASERBESTRÅLING NÅR DENNE DELEN ER

ÅPEN OG SIKKERHETSSPERREN ER UTKOBLET.

UNNGÅ UTSETTELSE FOR STRÅLING.

Before UseContents

…Place the unit on a hard flat surface.

…Avoid placing it in direct sunlight or

close to a source of heat. Also avoid

locations subject to vibrations and

excessive dust, heat, cold or moisture.

…Do not open the cabinet, as this might

result in circuitry damage or electrical

shock.

…Do not attempt to clean the unit with

chemical solvents, as this might damage

the finish. Use a clean, dry cloth.

…When removing the power plug from the

wall outlet, always pull directly on the

plug, never yank the cord.

…Keep this manual in a safe place for

future reference.

IMPORTANT SAFETY INSTRUCTIONS ................................................................ 2-3

Before Use ................................................................................................................. 4

ReadThis Before Operating .............................................................................. 4

Handling MDs .............................................................................................. 5

Memory back-up function ........................................................................... 5

When "Protected !!" is displayed................................................................ 5

While "UTOC Writing" is blinking ............................................................... 5

When "D-IN UNLOCK !" blinks.................................................................... 5

Remote Control Unit........................................................................................... 5

Name of Each Control .............................................................................................. 6

Connections .............................................................................................................. 7

Connection with a stereo amplifier/receiver ............................................ 7

Notes on power sources ............................................................................ 7

Recording .................................................................................................................. 8

Recording an MD ............................................................................................... 8

Notes on Recording ........................................................................................... 8

Playback .................................................................................................................... 9

Normal Playback ................................................................................................ 9

UsefulTips for Recording ....................................................................................... 10

Monitoring the Input Signal ............................................................................ 10

Adjusting the Recording Level ........................................................................ 10

AssigningTrack Numbers During Recording ................................................. 10

Recording Over ExistingTracks (Over Write) ................................................. 10

Sync Recording ................................................................................................ 11

Checking the Remaining MD RecordingTime ............................................... 11

Checking the RecordedTracks ......................................................................... 11

Timer Recording ............................................................................................... 11

UsefulTips for Playback ......................................................................................... 12

Using the Display Window .............................................................................. 12

Selecting the DesiredTrack .............................................................................. 12

PlayingTracks in Random Order (Shuffle Playback) ..................................... 12

When Recording to AnalogTape .................................................................... 13

PlayingTracks in the Desired Order (Program Playback) .............................. 13

RepeatingTrack(s) (Repeat Playback) ............................................................. 14

Timer Playback ................................................................................................. 14

Editing Recorded MDs ........................................................................................... 15

Notes on Editing .............................................................................................. 15

ErasingTrack(s) (ERASE Function) ................................................................. 15

Dividing aTrack (DIVIDE Function) ................................................................. 16

CombiningTracks (COMBINE Function) ......................................................... 16

Moving aTrack (MOVE Function) .................................................................... 16

AssigningTitles (TITLE Function) ................................................................... 17

AssigningTitles to the Disc and AllTracks Successively

(TITLE AUTO INC Function)......................................................................... 17-18

Changing entered characters.................................................................... 18

Copying aTitle (TITLE COPY Function)........................................................... 18

Canceling the Last Operation (UNDO Function) ............................................ 18

Optional Functions.................................................................................................. 19

Correspondence between deck buttons and keyboard keys.................. 19

Editing keys ................................................................................................ 19

Title entry keys ........................................................................................... 19

System Restrictions .......................................................................................... 19-20

Display Messages ................................................................................................... 20

Guide to the Serial Copy Management System .................................................. 21

Serial Copy Management System .................................................................. 21

Troubleshooting ...................................................................................................... 22

Specifications ......................................................................................................... 22

– 4 –

IMPORTANT (for U.K. Customers)

DO NOT cut off the mains plug from this

equipment. If the plug fitted is not

suitable for the power points in your

home or the cable is too short to reach a

power point, then obtain an appropriate

safety approved extension lead or

consult your dealer.

If nonetheless the mains plug is cut off,

remove the fuse and dispose of the plug

immediately, to avoid a possible shock

hazard by inadvertent connection to the

mains supply.

If this product is not provided with a

mains plug, or one has to be fitted, then

follow the instructions given below:

IMPORTANT. DO NOT make any

connection to the larger terminal which

is marked with the letter E or by the

safety earth symbol ç or coloured

GREEN or GREEN-and-YELLOW.

The wires in the mains lead on this

product are coloured in accordance

with the following code:

BLUE: NEUTRAL

BROWN: LIVE

As these colours may not correspond

with the coloured markings identifying

the terminals in your plug proceed as

follows:

The wire which is coloured BLUE must

be connected to the terminal which is

marked with the letter N or coloured

BLACK.

The wire which is coloured BROWN

must be connected to the terminal

which is marked with the letter L or

coloured RED.

When replacing the fuse only a

correctly rated approved type should be

used and be sure to re-fit the fuse cover.

IF IN DOUBT — CONSULT A

COMPETENT ELECTRICIAN.

Read This Before Operating

ªHandling MDs

The MiniDisc (MD) measures 64 mm in

diameter. Although the MD is housed in a

protective cartridge (68 mm x 72 mm x 5 mm)

and can be handled easily, deck

malfunctions may result if the cartridge

gets dust on it or is damaged. To protect the

disc, always take the following precautions:

…Be sure that the MD is taken out of the

deck and put back in its MD case after

using it.

…Do not touch the disc inside the

cartridge. Do not open the shutter to

expose the MD.

…Do not place MDs in direct sunlight, high

temperatures, or high levels of humidity.

…Use a dry, soft cloth to clean the

cartridge.

…When attaching a label to the MD

cartridge, be sure to apply it correctly to

the specified position. If the label is

rolled up or partially detached, the MD

cartridge may get stuck inside the deck.

…Do not place one label on top of another.

ªMemory back-up function

This unit is provided with a memory back-up

function. When you use the deck for the

first time, leave it on for about 5 minutes to

allow the back-up circuit to be charged and

become operational. When not using the

deck for a while, try to turn the power on

every 3 or 4 days.

ªSerial Copy Management System

This deck complies with the SCMS (Serial

Copy Management System). As a result, it is

not possible to digitally record from a

source MD which has been recorded

digitally.

Cartridge

Shutter

ªWhen "Protected !!" is

displayed

…A playback-only MD is loaded.

…The MD is record-protected against

accidental erasure. To make recording

(or editing) possible, slide the record-

protect tab to close the hole.

ªWhile "UTOC Writing" is

blinking:

"UTOC Writing" blinks while the MD is

being ejected after recording (or editing).

While it is blinking, the recorded data is

being written on the MD. Do not pull out

the power cord or vibrate the deck.

Otherwise the recorded data may not be

written correctly on the MD.

If the power is turned off with the MD left

in the deck (" " lights up) after

recording, the UTOC cannot be recorded.

Turn the power back on within 3 or 4 days

and eject the MD. The recorded data

might be lost if the MD is left in the deck

for a long time.

ªWhen "D-IN UNLOCK !" blinks

…The program source is not connected to

the [DIGITAL IN 1] or [DIGITAL IN 2]

terminal even though you have selected

[DIGITAL 1] or [DIGITAL 2] with the

[INPUT SELECTOR]. Either make the

digital connection or select [ANALOG]

with the [INPUT SELECTOR] and perform

analog recording.

…This message also appears when the

digital signal input is interrupted during

digital recording. To continue recording,

restart the digital program source.

– 5 –

ENGLISH

When operating the remote control unit,

point it towards the remote sensor on the

front panel of the unit.

ªBattery installation

1. Remove the battery compartment

cover.

2. Insert two "AA" (R6, SUM-3) dry

batteries.

Make sure that the batteries are inserted

with their positive ±and

negative —poles positioned correctly.

3. Close the cover until it clicks.

Battery replacement

If you notice that the distance between the

remote control unit and the player for

correct operation becomes shorter, it

indicates that the batteries are exhaust-

ed. In this case replace the batteries with

new ones.

Precautions concerning batteries

…Be sure to insert the batteries with

correct positive ±and negative —

polarities.

…Use batteries of the same type. Never

use different types of batteries

together.

…Rechargeable and non-rechargeable

batteries can be used. Refer to the

precautions on their labels.

…When the remote control unit is not to be

used for a long time (more than a month),

remove the batteries from the remote

control unit to prevent them from leaking.

If they leak, wipe away the liquid inside

the battery compartment and replace the

batteries with new ones.

…Do not heat or disassemble batteries and

never dispose of old batteries by

throwing them in fire.

Remote Control Unit

Name of Each Control

– 6 –

1[POWER] button

2[TIMER PLAY/OFF/REC] switch

3[REC MODE MONO/STEREO] switch

4[REC LEVEL] control

5Remote sensor

6Disc insertion slot

7[øEJECT] button

8[ºRECORD] button

9[DISPLAY] button

0[∆/˚SEARCH] buttons

q[PLAY MODE] button

w[µTRACK≤] dial / [PUSH ENTER]

e[EDIT/NO] button

r[YES] button

t[INPUT SELECTOR] switch

y[PHONES] jack

u[LEVEL] control

iDisplay window

o[ªSTOP] button

p[¥PLAY] button

a[πPAUSE] button

s[DIGITAL IN 2] terminal

d[KEYBOARD] terminal

fNumeric buttons (1 to 9, 0, +10)

g[REPEAT/A-B] buttons

h[TITLE EDIT] button

j[CLEAR] button

k[INSERT] button

l[DELETE] button

;[SYNC REC] button

zUpper/Lower case button [Aß∑a]

x[AUTO SPACE] button

c[SCROLL] button

vCharacter select button [CHAR SELECT]

b[ENTER] button

n[µSKIP≤] buttons

Connections

…Turn off power for all equipment before

making connections.

…Read instructions of each component

you intend to use with the MD deck.

ªConnection with a stereo

amplifier/receiver

LINE (ANALOG) IN/OUT jacks

Connect the amplifier to the LINE IN/OUT

jacks using the pin-plug cord (provided),

making sure to match the color-coded

plugs to the appropriate jacks on the

components — white to white (L), and red

to red (R).

…Be sure to insert each plug securely. To

prevent hum and noise, do not bundle the

connection cords with the power cord or

speaker cord.

DIGITAL IN 1/OUT terminals

Use these terminals to connect the deck to

a digital component (such as a CD player,

DAT deck, digital amplifier, or another MD

deck).

…Use a digital optical (TOS) cable

(optional) for digital recording. Connect

the [DIGITAL IN 2] jack located on the

front panel to a digital component such

as a DAT/MD deck.

…When making a digital connection,

remove the caps from the terminals.

When the terminals are not in use, leave

the caps in place.

ªNotes on power sources

Before operating the deck, check that the

operating voltage of the deck is identical to

your local power supply. The operating

voltage is indicated on the nameplate at the

rear panel of the deck.

ªPower cord

Be sure to connect the power cord to an AC

outlet which supplies the correct voltage.

…Hold the power plug when plugging or

unplugging the power cord.

– 7 –

ENGLISH

– 8 –

Recording

1. Press the [POWER] button.

…"NO DISC" appears on the display.

…Turn on the source component and the

amplifier. Set the input selector to the

source component.

2. Insert a recordable MD.

…When a blank MD is inserted, the display

shows "Disc Loading", "TOC Reading",

"No Track !!" and "Blank Disc" in

sequence.

…When a partially recorded MD is

inserted, the deck will automatically

start recording from the end of the last

recorded track.

3. Select the input with the [INPUT

SELECTOR].

Display Selected Input

ANALOG LINE IN

DIGITAL 1 DIGITAL IN 1 (OPTICAL)

DIGITAL 2 DIGITAL IN 2 (OPTICAL)

(front panel)

4. Select the recording mode with the [REC

MODE] switch.

…When [STEREO] is selected, stereo

recording will be performed.

…When [MONO] is selected, monaural

recording will be performed using only

the left (L) channel. "L" appears on the

level meter, but the output is sent to both

channels.

Recording an MD

Insert in the direction of

the arrow.

Hold the MD with the

label side up.

…The maximum amount of time available

with monaural recording is twice that of

stereo recording.

5. Press the [ºRECORD] button.

…The deck enters the Record-Pause mode

(" "lights up).

…"Disc Full !!" or "Track Full !!" is displayed

when no room is available on the MD for

recording.

6. Adjust the recording level.

…If [ANALOG] was selected above,

adjust the recording level with the [REC

LEVEL] control.

…When adjusting the recording level,

adjust so that the "OVER" segments of the

peak level meter do not light up.

7. Start recording.

Press the [¥PLAY] button or the

[π PAUSE] button ( "¥"lights up).

Start playing the source program.

8. To stop recording, press the [ªSTOP]

button.

ªTo stop recording temporarily (pause)

Press the [πPAUSE] button.

…Press the [¥PLAY] or [πPAUSE] button

to resume recording.

…Whenever you pause recording, the

track number increases by one.

ªTo eject the MD

Press the [øEJECT] button.

If the power is turned off with the MD left

in the deck (" " lights up) after

recording, the UTOC cannot be recorded.

Turn the power back on within 3 or 4 days

and eject the MD. The recorded data might

be lost if the MD is left in the deck for a long

time.

Notes on Recording

ªTo protect an MD against

accidental erasure

…After recording an MD, slide the record-

protect tab to open the hole.

…To record on the MD again, slide the tab

to close the hole.

ªWhen "Disc Full !!" or "Track

Full !!" is displayed

The MD has no more available space for

recording or the MD has used up all its

track numbers. Erase unnecessary tracks

or record music on another MD.

ªThe way track numbers are

assigned varies depending on

the source

When a CD or MD is played and recorded

digitally by selecting [DIGITAL 1/2] with the

[INPUT SELECTOR]:

…Track numbers on the recorded MD are

assigned to match those on the source

CD or MD. However, in the

circumstances listed below only one

track number may be assigned to a

recorded section.

·A section composed of the repeated

playback of a single track on a disc

(e.g. using single track repeat

playback).

·A section composed of the

successive recording of tracks with

the same track number from more

than one disc. Also, if the source is an

MD, track numbers may not be

marked for tracks shorter than 3

seconds.

When the source is recorded with

[ANALOG] or when a digital source other

than a CD or MD is recorded with [DIGITAL

1] or [DIGITAL 2] while the Auto Track

function is OFF:

…The entire recording may be counted as

a single track with only one track

number assigned to it.

·Track numbers can be assigned

manually at the desired points by

pressing the [ºRECORD] button

during recording.

·Track numbers can be assigned

automatically by switching the Auto

Track function to "A_TRACK > ON"

before starting recording.

Buttons used on this page

1. Press the [POWER] button.

…"NO DISC" appears on the display.

…Turn on the amplifier and set the input

selector to MD.

2. Insert an MD.

…After the TOC (Table Of Contents) data

has been read, the disc title (when the

disc has a title assigned to it), the total

number of tracks and the total playing

time of the disc are displayed.

Total number of tracks Disc title

Music calendar

…The disc or track title can be scrolled on

the display with the [SCROLL] button on

the remote control unit. After scrolling,

the title returns to its original display.

– 9 –

ENGLISH

Playback

Insert in the direction

of the arrow.

Hold the MD with the

label side up.

Normal Playback 3. Start playback.

Press the [¥PLAY] button ("¥" lights up).

Playback starts from the first track and

"001" appears on the "TRACK NO."

display.

…When the disc finishes playback, the

track numbers disappear from the music

calendar.

…If the total number of tracks exceeds 20

(" " lights up), the track number

should be confirmed on the TRACK NO.

display.

…Press the [¥PLAY] button immediately

after recording is stopped (within 10

seconds) to play back a track which has

just been recorded from the beginning.

…If ten seconds or more have passed after

recording is stopped, or if the [¥PLAY]

button is pressed after pressing the

[ªSTOP] button, playback starts from

the first track of the disc.

4. To stop playback, press the [ªSTOP]

button.

ªTo stop playback temporarily (pause)

Press the [πPAUSE] button ("π" lights up).

…Press the [¥PLAY] or [πPAUSE] button

to resume playback.

ªTo play a track located before or after

the current track

Turn the [µTRACK≤] dial.

…If you are operating the remote control

unit, select the desired track by pressing

the [µSKIP≤] buttons or entering the

track number with the numeric buttons.

…The selected track number starts

playing.

ªTo eject the MD

Press the [øEJECT] button.

ªHeadphones

When using headphones, connect the

headphone plug into the PHONES jack.

…Adjust the level of the signals output

from the phones jack.

Condensation

When the deck is moved directly from a

cold to a warm location or when the

temperature is raised suddenly in the

room where the deck is installed,

moisture may condense inside the

mechanism. This will prevent the deck

from operating normally and may result

in damage to the MD or to precision

parts. If condensation occurs, turn on

the deck and leave it for an hour or two

until the moisture evaporates.

Buttons used on this page

Useful Tips for Recording

– 10 –

You can monitor the input signal of the

component connected to each input

terminal before recording.

1. Press the [øEJECT] button to eject the

disc.

2. Select the input source with the [INPUT

SELECTOR].

3. Press the [ºRECORD] button.

("Monitor Mode" appears.)

…Even when the [REC MODE] is set to

[MONO], the output is sent to both

channels.

…Insert an MD or press the [ªSTOP]

button to cancel the Monitor mode.

When recording with [ANALOG] selected

with the [INPUT SELECTOR] and the signal

input through the [LINE IN] jacks, adjust the

recording level with the [REC LEVEL]

control.

1. Insert a recordable MD and press the

[ºRECORD] button to enter the Record-

Pause mode (" " lights up).

2. Play the highest-level section of the

program source and turn the [REC

LEVEL] control so that the "OVER"

segments of the peak level meters do not

light.

…Recording level adjustment is not

necessary for digital recording.

3. Play the program source again.

…Press the [¥PLAY] or [πPAUSE] button

to start recording.

Adjusting the Recording Level

Monitoring the Input Signal

Assigning track numbers at specific points

will make it easy to quickly locate those

points later using the playback or editing

functions.

ªTo assign track numbers automatically

(Auto Track function)

Track numbers can be assigned

automatically during recording by setting

the Auto Track function to ON.

1. In the Record or Record-Pause mode,

press the [EDIT/NO] button until

"A_TRACK >" appears.

2. Turn the [µTRACK≤] dial to select

"A_TRACK > ON".

3. Press the [YES] button to end the setting

function.

…While the Auto Track function is "ON", the

signal level must remain low for 2 or

more seconds before a new track

number is advanced.

…During digital recording from a CD or

MD, the track numbers are advanced

automatically according to the CD or MD

data.

…Once the Auto Track function is "ON", this

mode will not be released even after the

power is turned off.

Press the [YES] button after selecting

"A_TRACK > OFF" to release it.

ªTo assign track numbers manually

Press the [ºRECORD] button at every point

where you want to assign a track number

during recording. Each press of the button

advances the track number.

ªTo assign track numbers after recording

A track number is added when a track is

divided in editing. (See "Dividing a track" on

page 16.)

Note:

Changing the input or mode with the [INPUT

SELECTOR] or [REC MODE] switch during

recording activates the Record-Pause

mode.

Assigning Track Numbers During

Recording

The Over Write function allows you to

record music by erasing a previously

recorded track.

1. Perform steps 1 to 4 of "Recording an

MD" on page 8.

2. Turn the [µTRACK≤] dial (or press

the [µSKIP≤] buttons on the remote

control unit) until the track number to be

recorded over appears.

3. Press the [ºRECORD] button (" "

lights up).

…After "Over Write" appears, the

remaining recording time is displayed.

…The track numbers which come after the

track being recorded over blink on the

music calendar.

4. Adjust the recording level.

…If [ANALOG] was selected above, adjust

the recording level with the [REC LEVEL]

control.

5. Press the [¥PLAY] button or [πPAUSE]

button to start recording.

…The deck records over the existing track.

The track number is updated.

ªRecording over an existing track from

the middle

1. Select the track number to be erased

then press the [¥PLAY] button to start

playback.

2. Press the [πPAUSE] button where you

want to start recording.

3. Press the [ºRECORD] button.

…The track number is updated and blinks

on the music calender.

4. Press the [¥PLAY] or [πPAUSE] button

to start recording.

…The deck records over the existing track.

[CAUTION]

…It is not possible to record from the

middle of an existing track when

""or " " is lit.

Recording Over Existing Tracks

(Over Write)

Buttons used on this page

Table des matières

Langues :

Autres manuels Teac Lecteur Mini Disc

Teac

Teac MD-H500i Manuel utilisateur

Manuels Lecteur Mini Disc populaires d'autres marques

Sony

Sony ZS-M30 Manuel utilisateur

Sony

Sony MZ-DH10P Hi-MD Music Transfer Version 1 for Mac (User... Manuel utilisateur

Sony

Sony MDX-F5800 Guide produit

Sony

Sony MZ-E32 Manuel utilisateur

Sony

Sony MDX-C7900 Manuel utilisateur

Sony

Sony MXD-D40 - Md Player Manuel utilisateur

Sony

Sony PMC-MD55 - Md Boombox Manuel utilisateur

Sony

Sony MDS-JE480 Manuel utilisateur

Panasonic

Panasonic SJ-MJ70 Manuel utilisateur

Sony

Sony MDS-W1 Manuel utilisateur

Sony

Sony Hi-MD WALKMAN MZ-DH710 Manuel utilisateur

Sony

Sony Walkman MZ-E707 Manuel utilisateur

Nilox

Nilox 13NXM3SU2B001 Manuel utilisateur

Sony

Sony PMC-MD55 - Md Boombox Manuel utilisateur

Sharp

Sharp MD-ST600 Manuel utilisateur

Sony

Sony ZS-M50 Manuel utilisateur

Sony

Sony MDS-JB920 Manuel utilisateur

Sony

Sony MD Walkman MZ-EP11 Manuel utilisateur
