Teac MP-10 Manuel utilisateur

MP3/WMA/CD Player MP-10

User Manual

To ensure the smooth handling of your warranty please write the serial number

of your device into the box. In the case of warranty you are expected to send it

together with a copy of your invoice to your nearest TEAC sales representative.

reserved. Edition: March 2005

•Company and product names provided herein are

trademarks of their respective companies.

•Changes in specifications and features may be made

without notice or obligation.

17 | MP-10

Contents

CONTENT OF PACKAGE ............................................................. 18

LOCATION OF CONTROLS ......................................................... 18

POWER SOURCES ....................................................................... 19

Using Nickel-metal-hydride batteries: ............................... 19

Using AC/DC adaptor ........................................................ 20

Using external battery case (supply for some

models only) ........................................................................ 20

To recharge the Nickel-metal-hydride rechargeable

batteries ............................................................................... 20

GENERAL OPERATIONS ............................................................... 21

To disable/resume the buttons functions .......................... 23

To select a track by the navigational search function ... 23

To skip at directory level for MP3 and WMA playback

only ....................................................................................... 24

To disable the Electronic Shock Protection (ESP)

for CD-DA playback only ................................................... 24

To select the preset equalizer modes ............................... 24

ADVANCE OPERATIONS ............................................................. 25

SPECIFICATIONS .......................................................................... 26

WARRANTY .................................................................................. 27

18 | MP-10

CONTENT OF PACKAGE

MP3/WMA/CD player MP-10, adapter, earphone, 2 recharge-

able batteries, remote control unit, external batterie pack,

manual

LOCATION OF CONTROLS

19 | MP-10

1 External battery connec-

tion

2 DC input socket

3 Lid open switch

4 "Next" button 

5 "Previous" button 

6. Play / Pause button

7 Stop button 

8 Volume up button Vol +

9 Volume down button Vol -

10 Audio out socket

11 Remote control &

earphone socket

12 LCD display

13 ESP On / Off andDirectory

/ file level button (DIR/ESP)

14 Equalizer preset button

(EQ)

15. Earphone socket

16 Mode button

17 Hold function On / Off

switch

18 Navigational search

button (NAV)

POWER SOURCES

Using Nickel-metal-hydride batteries:

1. Open the lid of the player and open the battery compart-

ment door. Insert two pieces of the Nickel-metal-hydride bat-

tery following the polarity as indicated on the unit, and close

the battery compartment door.

2. Do not mix using new battery with old battery.

3. Batteries should be recharged or replaced when the battery

level indicator on the LCD display shows empty continuously.

4. When the batteries are fully discharged, the battery level in-

dicator will blink for about 5 seconds and the unit will be shut

off automatically.

20 | MP-10

Remark: To remove the Nickel-metal-hydride batteries from

the battery compartment, press the negative pole of the

battery downward. The positive pole of the battery will be

tilted up and the battery can be taken out easily.

Using AC/DC adaptor

Use only DC output between 4.5V and 6.0V with positive pole to

the center pin, and make sure that the AC input voltage of the

adaptor matches with the domestic supply. Any other adaptor

may cause damage to the unit.

Remark:

Stop the player before connect (or disconnect) the adap-

tor DC jack to the player.

Using external battery case (supply for some models only)

Insert two pcs of AA (UM-3/R06) size battery into the battery

case (optional accessory) following the polarity as indicated.

Then close the battery case. Plug the jack of the battery case

to the external battery connection socket of the player.

To recharge the Nickel-metal-hydride rechargeable

batteries

Switch off the player with the Stop button and connect the AC/

DC adaptor to the player. The rechargeable batteries inside the

battery compartment will be recharged automatically.

PUSH

21 | MP-10

If the player is operating by the power source of AC/DC adap-

tor, while the rechargeable batteries are kept inside the battery

compartment, switch off the player by pressing the Stop but-

ton. Leave the player idle for about 60 sec., the batteries will be

recharged automatically.

The recharging will be cut off automatically when the batteries

are fully recharged. The LCD shows the recharging status or the

cut off status.

Recharging status Recharging cut off status

Remarks:

The batteries will be recharged only when the player is at

the off (idle) status. If the Play/Pause button is pressed dur-

ing recharging, the player will perform playback function

and the recharging will be interrupted.

GENERAL OPERATIONS

1. Insert the disc into the player and close the lid securely.

2. Connect the LCD line remote control unit to the player, and

the earphone to the LCD line remote control unit.

3. Press and hold the Play/Pause button for one second, the

player scans the disc and then starts playing.

22 | MP-10

Remark:

The title of song, artist’s name, and album’s name can be

displayed if the MP3 disc is with the ID3 versions V1, V1.1, V2

2.0, or V2 3.0 information.

4. Adjust the volume to the desire level by pressing the “VOL -”

or “VOL +” button.

To Press Display Example

(for MP3 format)

Pause

Resume play after pause

Skip to the next track 

Go to the beginning 

of the current track

Skip to the previous track 2x

Stop 

23 | MP-10

Remarks:

A. To enhance power saving at the MP3 and WMA formats,

the spinning motor stops when the buffer memory is full.

B. The unit will be switched off automatically approx. 60 sec-

onds after the playback is stopped.

To disable/resume the buttons functions

Slide the HOLD switch to the direction of the arrow and the

function of buttons are disabled.

To resume the function of buttons, slide the HOLD switch to

the opposite direction of the arrow.

To select a track by the navigational search function

Press the NAV. button once and the display will show selec-

tion levels [Dir] and [File], if the files are sorted into different

directories. Otherwise, the track numbers or names will be dis-

played.

Use the Play/Pause button or the Stop button to move

the cursor upwards or downwards on the display, and use the

Next button to confirm the selection.

If no selection has been made, press the NAV button again

to resume normal operation.

24 | MP-10

To skip at directory level for MP3 and WMA playback only

Press the DIR/ESP button once, the “Album SKIP” indicator

appears on the display for about two seconds.

At this status, press the Next button or Previous button, the skip

function is on directory level.

Press the DIR/ESP button again to go back to file level.

To disable the Electronic Shock Protection (ESP) for CD-DA

playback only

During playback, the ESP indicator shows on the display and

the ESP is in operation.

Press the DIR/ESP button once to disable the ESP function, and

the CDA indicator shows on the display.

Press the DIR/ESP button again to resume the ESP function.

To select the preset equalizer modes

Press the EQ button to select from Classic, Pop, Jazz, Rock, X-

Bass, and Normal modes.
