TBS TANGO FPV REMOTE Manuel utilisateur
TBS TANGO FPV Remote
Revision 2016-07-16
All‐in‐one Remote Control System for FPV
The TBS TANGO FPV remote control is an all-in-one system made for FPV enthusiasts. It features built-in
video receiver and a slot for JR-compatible radio modules. Input controls are provided by quality quad
ball-bearing gimbals and camera operation is possible using smooth spring-loaded dials and rocker-switch. A
huge display shows the video stream right on the remote, with an option to connect external goggles.
Key features
• All-in-one FPV remote control with R/C radio and video receiver built-in
• JR-compatible slot for any R/C radio module
• Large 4.2-inch display for live video stream
• Quality ball-bearing gimbals for control and spring-loaded dials for smooth camera operation
• High capacity built-in Lithium-ion cells, charges via USB
• External port for goggles
1
Table of content
Attention
Overview
Detailed overview
Powering up
Remote Control Channel Mapping
Configuration menu
Main menu
Drone menu
Remote menu
Display menu
Setup
Installing R/C radio module
Transmitter stick mode
Connecting goggles
Usage
Changing video receiver frequency
Remote LED status indicator
Battery protection
Alert prompts
Opening up the remote
Changing the flight stick mode
Adjusting throttle ratchet strength
Replacing battery
Swapping antenna
Factory mode
FrSky XJT
Firmware upgrade
Installing TBS Agent
Good practices
2
Specifications
Type:
All-in-one FPV Remote Control
RC system:
JR-compatible expansion module, e.g. TBS CROSSFIRE
FPV system:
5G8 VRX receiver, 40CH
Antenna:
R/C: module specific
VTX: 5G8 5dBi patch antenna, optional external SMA port
FPV Channels:
Boscam A, B, E, Fatshark, Raceband
Display:
LCD 4.2-inch, 640x480p
R/C module
compatibility:
JR-compatible RF module with CRSF or PPM stream (absolute max. ratings:
-0.3V to 15V), e.g. Crossfire, JR, FrSky and similar radio modules
Battery:
Li-Ion 18650 3.6V 6000mAh internal battery, USB-charging
Operating range:
Variable depending on output power and radio environment
Ports:
RJ45 connector for connecting video goggles, e.g. FatSharks
DSC for trainer connection
USB for software updates and charging
Controls:
2x Quad ball-bearing gimbals
2x Two-position switches
2x Three-position switches
2x Spring-loaded dials
2x Digital trims
3x Video RX buttons
1x Rocker switch
Working temperature:
0 - 40°C
Size:
150 x 80 x 20 mm
Weight:
340 grams, without R/C radio module
Kit contents:
1x TBS Tango Remote Controller
1x TBS Tango Neckstrap
1x RJ45 Audio/Video cable
3
Attention
These Long Range Systems are capable to use radio frequency transmissions and output power that may be
not allowed in your country.
Please always check your local RF legislation to set the frequency and output power according with
the regulation.
A general rule for RC aircrafts is that they must be controlled always under sight of view, check your RC
regulation to keep up to date with regulations.
4
Overview
The following diagram indicates the essential input controls and features of the radio.
5
Detailed overview
JR-module slot, DSC, micro-USB, TBS-port (for
goggles), power button and speaker
Display and neck-strap connector
Left gimbal for throttle and yaw, and digital pad for
trims
Right gimbal for aileron and elevator, and digital
pad for trims
Three-position (A/L2), two-position (B/L1) switch,
spring-loaded dial (SW E) and video receiver bay
Two-position (C/R1) switch, three-position (D/R2)
switch and spring-loaded (SW F) dial
6
Powering up
Getting set up and ready to fly is a quick and simple task. In most cases plug&play when using TBS
equipment.
Power up
Press and hold the Power-button for half a second to turn on the remote. The TBS TANGO screen will
welcome you and the power button starts to flash green.
Factory mode
Press the Power-button and Down-button for 2 seconds to enter the factory mode (not factory reset), a
confirmation tone will sound. This is where you can calibrate control inputs, change test settings, read ADC
and PPM values, and change LCD display settings.
No-JR Module mode
Press the Power-button and Scan-button for 2 seconds to disable JR module power, a confirmation tone will
sound. This is handy when you want to conserve battery while watching your friends fly.
PitMode
Press the Power-button and Rocker-button for 2 seconds to enter the PitMode, a confirmation tone will
sound. This will set the video receiver to 5584 Mhz, which is the TBS PitMode frequency. For more
information about PitMode, please consult the TBS UNIFY PRO manual.
7
Remote Control Channel Mapping
The channel arrangement of the PPM output to the RF module is dependant on the kind of flight controller
that is hooked-up on the receiver side.
In the configuration menu, you can change the mapping by changing the model type to match your particular
setup.
PPM
Channel
Flight Control Model
DJI
3DR
BLADE
CROSSFIRE
TAULABS
1
AIL
AIL
THR
AIL
AIL
2
ELE
ELE
AIL
ELE
ELE
3
THR
THR
ELE
THR
THR
4
RUD
RUD
RUD
RUD
RUD
5
Tuner L (E)
3-Pos Right (D)
3-Pos Right (D)
3-Pos Right (D)
3-Pos Right (D)
6
Tuner R (F)
Tuner R (F)
2-Pos Right (C)
2-Pos Right (C)
2-Pos Right (C)
7
3-Pos Right (D)
2-Pos Right (C)
2-Pos Left (A)
2-Pos Left (A)
2-Pos Left (A)
8
2-Pos Right (C)
2-Pos Left (A)
3-Pos Left (B)
3-Pos Left (B)
3-Pos Left (B)
9
3-Pos Left (B)
Tuner L (E)
Tuner L (E)
Tuner L (E)
Tuner L (E)
10
2-Pos Left (A)
3-Pos Left (B)
Tuner R (F)
Tuner R (F)
Tuner R (F)
8
Configuration menu
Changing settings on the TBS TANGO is done using the LCD display and controlled using the rocker-switch
and VRX buttons.
To enter and navigating the configuration menu system:
• Enter configuration menu - long press on the rocker-switch, 3 seconds
• Menu navigation - scroll back and forth using the rocker-switch
• Select/enter change - short press the rocker-switch
• Back/confirm change - long press the rocker-switch
Main menu
Main configuration menu when entering the system
•Exit - Leave menu system
•Drone - Models and details about the remote
flight system (name, flight control, switch map)
•Remote - Everything related to the remote
(stick mode, RF module, idle alarm, default
channel)
•Display - Fine tune the visual parameters
•Battery - The battery icon is permanently
shown to indicate how much power is left, 0 to
4 bars - see battery protection section
9
Drone menu
Specific profile for the model you are controlling
•Back - Return to previous menu
•Name - Unique name for the model profile
•Type
[CleanFlight, DJI NAZA, PixHawk,
OP-Taulabs]
- Flight controller used on the
model, allows further switch/dial mapping on
supported FCs (DJI/PX)
•SW E
[ANG, SPD]
- (DJI, PX) Specify the function
mapped to the SW E dial on the remote, angle
(ANG) or speed (SPD)
•SW F
[ANG, SPD]
- (DJI, PX) Specify the function
mapped to the SW F dial on the remote, angle
(ANG) or speed (SPD)
Remote menu
Specifics about the remote itself
•Back - Return to previous menu
•Stick Mode
[1 to 4]
- Stick allocation mode,
maps throttle, yaw, pitch and roll to the gimbals
- Mode 2 is most common
•RF Module
[Standard PPM (10Ch), TBS Crossfire
(10Ch), FrSky XJT (8Ch)]
- Radio module plugged
into the radio, dictates the communication
protocol and PPM channel size
•Idle Warn
[ON, 5 to 30min, OFF]
- When the
remote is left powered on without any input
after a specific amount of time, sound an alarm
•Home CH
[Band, Channel (1 to 8)]
- Default
video channel to tune into after long pressing
the UP-button (VRX controls)
•SW Speed
[1 to 15]
- Set the speed of SW E and
SW F dial, if SW is set to angle (ANG)
10
