MPPT charge controller User Manual
MPPT charge controller User Manual
Disclaimer
Unless specially agreed in writing, TBB Power Co.,Ltd
Take no warranty as to the accuracy, sufficiency of suitability of any technical or other
information provided in this manual or other documentation.
Assumes no responsibility or liability for loss or damage, whether direct, indirect,
consequential or incidental, which might arise out of the use of such information.
TBB offer standard warranty with its products, taking no responsibility for direct or indirect loss
due to equipment failure.
About this Manual
This manual describes our product features and provides procedure of installations. This manual is
for anyone intending to install our equipment.
General Instruction
Thanks for choosing our products and this manual were suitable for Solar Mate series MPPT.
This chapter contains important safety and operation instructions. Read and keep this User Guide
well for later reference.
MPPT charge controller will have high voltage inside, Solar Mate MPPT charge controller needs to
be installed by professionals and only authorized electrician can open the case.
MPPT charge controller User Manual
Contents
Contents
1. General Safety Instruction............................................................................................................1
1.1 Safety Instruction.................................................................................................................1
1.2 General Precaution..............................................................................................................1
1.3 Precaution regarding battery operation................................................................................1
2. Instruction.....................................................................................................................................2
2.1 Brief Instruction....................................................................................................................2
2.1.1 General Description...................................................................................................2
2.1.2 Naming Rules............................................................................................................3
2.2 Structure..............................................................................................................................3
2.2.1 Front
2.2.1 Front..........................................................................................................................3
2.2.2 Control panel
2.2.2 Control panel.............................................................................................................4
2.2.3 Connection compartment...........................................................................................5
2.2.4 Dimension..................................................................................................................6
2.3 Function...............................................................................................................................7
2.3.1 Maximum Power Point Tracking.................................................................................7
2.3.2 Battery charging control.............................................................................................7
2.3.3 Auxiliary Output..........................................................................................................7
2.3.4 TBB premium III charging algorithm...........................................................................8
2.3.5 Comprehensive Protection.........................................................................................9
2.3.6 Equalization Charging (EQ charging).......................................................................10
3. Installation and Wiring................................................................................................................11
3.1 Pre-installation inspection..................................................................................................11
3.1.1 Check outer packing.................................................................................................11
3.1.2 Check deliverables...................................................................................................11
3.2 Instrument Preparation......................................................................................................11
3.3 Select installation location.................................................................................................12
3.3.1 Requirement............................................................................................................12
3.3.2 Installation space requirements...............................................................................12
3.3.3 Installation Angle......................................................................................................13
3.4 Installation.........................................................................................................................14
3.5 Preparation Before Wiring.................................................................................................15
3.5.1 Wiring Diagram
3.5.1 Wiring Diagram........................................................................................................15
3.5.2 PV Array Preparation
3.5.2 PV Array Preparation...............................................................................................15
3.5.3 Breaker Preparation
3.5.3 Breaker Preparation.................................................................................................17
3.5.4 Cable Preparation
3.5.4 Cable Preparation....................................................................................................18
3.5.5 Preparation before wiring.........................................................................................19
MPPT charge controller User Manual
3.6 Grounding Connection.......................................................................................................20
3.7 PV Array Connection.........................................................................................................20
3.8 Battery Connection............................................................................................................21
3.9 Communication Connection...............................................................................................22
3.10 Connecting the multiple units...........................................................................................22
4. Configuration..............................................................................................................................24
4.1 Check Before Operation....................................................................................................24
4.2 Power ON Test...................................................................................................................24
4.3 Power OFF........................................................................................................................25
4.4 Setup Wizard
4.4 Setup Wizard.....................................................................................................................25
5. Operation...................................................................................................................................26
5.1 Menu introduction
5.1 Menu introduction..............................................................................................................26
5.2 Initial interface
5.2 Initial interface...................................................................................................................27
5.3 Real-time information interface
5.3 Real-time information interface..........................................................................................27
5.4 Information query interface
5.4 Information query interface................................................................................................28
5.5 Parameter setting interface
5.5 Parameter setting interface................................................................................................30
5.6 User Config
5.6 User Config........................................................................................................................34
6. FAQ............................................................................................................................................35
6.1 Fault code..........................................................................................................................35
7. Specification...............................................................................................................................38
1
MPPT charge controller User Manual
1. General Safety Instruction
1.1 Safety Instruction
As dangerous voltage and high temperature exist within the charge controller, only qualified and
authorized maintenance personnel are permitted to open and repair it.
This manual contains information concerning the installation and operation of the charge controller.
All relevant parts of the manual should be read prior to commencing the installation. Please follow
the local stipulation meantime.
Any operation against safety requirement or against design, manufacture, safety standard, and are
out of the manufacturer warranty.
1.2 General Precaution
Do not expose to rain, snow or liquids of any type，it is designed for indoor use.
To avoid fire and electric shock, make sure all cables selected with right gauge and being
connected well. Smaller diameter and broken cable are not allowed to use.
Please do not put any inflammable goods near to charge controller.
Never place unit directly above batteries, gases from a battery will corrode and damage the
charge controller.
Do not place battery over charge controller.
1.3 Precaution regarding battery operation
Use plenty of fresh water to clean in case battery acid contacts skin, clothing, or eyes and
consult with doctor as soon as possible.
The battery may generate flammable gas during charging. Never smoke or allow a spark or
flame in vicinity of a battery.
Do not put the metal tool on the battery, spark and short circuit might lead to explosion.
Remove all personal metal items such as rings, bracelets, necklaces, and watches while
working with batteries. Batteries can cause short-circuit current high enough to make metal
melt, and could cause severe burns.
2
MPPT charge controller User Manual
2. Instruction
2.1 Brief Instruction
2.1.1 General Description
Solar Mate is a solar charge controller with built in Maximum Power Point Tracking (MPPT)
technology, which can optimize the PV’s output eliminate the fluctuation due to shading or
temperatures variables. It tracked the maximum power point of a PV array to deliver the maximum
charging current for battery, enabling PV array to increase the output by as much as 30%
compared with PWM design.
Solar Mate is a multi-voltage MPPT with built in sophisticated battery charging algorithm for various
kinds of lead acid batteries, including AGM, GEL, Traction. Data management with a year of history
record was offered as well. Meantime, version for Lead-Carbon battery and lithium ion battery were
available upon request.
SP can operate at their full rating in ambient temperatures as high as 40℃.
Maximum MPPT efficiency up to 99.9%, Maximum dynamic MPPT efficiency up to 99%.
Maximum efficiency up to 98%, and European weighted efficiency up to 97.3%.
Maximum charging current up to 120A.
High reliability with electronic protections.
Wide MPPT operating voltage range.
℃Up to 6720W of charging power at 40 .
Parallel function, up to 4 units can operate in parallel.
Easy installation and commissioning.
Flexible charge algorithm.
Extensive networking and communication capabilities.
Auxiliary contact RS485 : communication among TBB products or with other.
3
MPPT charge controller User Manual
2.1.2 Naming Rules
Field Characte Description
SP SP SP series MPPT solar charge controller
XXX 150 PV open circuit voltage:(V) 150
250 250
YYY
120
Maximum output current:(A)
120
100 100
80 80
70 70
60 60
2.2 Structure
2.2.1 Front
2.2.1 Front
SPXXX-YYY
PV open circuit voltage
Maximum output current
Series
SP 150-120
4
MPPT charge controller User Manual
Figure 2-1 MPPT charge controller structure in front view
2.2.2 Control panel
2.2.2 Control panel
Fig
Figure
ure 2-2 MPPT Control buttons
2-2 MPPT Control buttons
Tab
Table
le 2-1 Control Buttons
2-1 Control Buttons
Button
Button Function
Function
Cancel the selection
Display the previous level of menu
Display the previous page
Increase the value of the selected item
Press the button for more than 2 seconds to scroll the page up
Display the next page
Decrease the value of the selected item
Press the button for more than 2 seconds to scroll the page down
Enter into this menu, displaying the next level
Select and confirm the selection of a menu item
Table 2-2 LED directive function
Table 2-2 LED directive function
LED
LED Function
Function
Charge It Flash when SP is in standby.
It Flash when SP is in float charging state.
It illumirate when SP is perform charging .
Warning It Flash when SP have warning.
5
MPPT charge controller User Manual
Fault It Flash when SP have error.
