Taurus TF-K22604 Manuel utilisateur

TFK22604.01.02

Assembly and Operating Instructions

Exercise Bike Ergo-X Classic

TF-K22604

Ergo-X

Content

1 GENERAL INFORMATION 7

1.1 Technical Data 7

1.2 Personal Safety 8

1.3 Set-Up Place 9

2 ASSEMBLY 10

2.1 General Instructions 10

2.2 Scope of Delivery 11

2.3 Assembly 12

3 OPERATING INSTRUCTIONS 15

3.1 Console Display 15

3.2 Button Functions 16

3.3 First Steps 17

3.4 Sleep Mode 17

3.5 Programmes 18

3.5.1 Quick Start Programme 18

3.5.2 Interval 10/20 and Interval 20/10 19

3.5.3 Interval Custom 20

3.5.4 Target Time, Target Distance and Target Calories 22

3.5.5 Target HR 23

3.6 Changing the Units 24

4 STORAGE AND TRANSPORT 25

4.1 General Instructions 25

4.2 Transportation Wheels 25

5 TROUBLESHOOTING, CARE AND MAINTENANCE 26

5.1 General Instructions 26

5.2 Faults and Fault Diagnosis 26

5.3 Maintenance and Inspection Calendar 27

6 DISPOSAL 27

7 RECOMMENDED ACCESSORIES 28

Ergo-X

8 ORDERING SPARE PARTS 29

8.1 Serial Number and Model Name 29

8.2 Parts List 30

8.3 Exploded Drawing 33

9 WARRANTY 34

10 CONTACT 36

Ergo-X

Dear customer,

Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and

tness equipment for the sophisticated home sport and the equipment of tness studios and

business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum

performance! Therefore, the equipment is developed in close consultation with athletes and sports

scientists. Because athletes know best what makes perfect tness equipment.

Further information can be found at www.sport-tiedje.com.

Legal Notice

Sport-Tiedje GmbH

Europe’s No. 1 for home tness

International Headquarters

Flensburger Straße 55

24837 Schleswig

Germany

Management:

Christian Grau

Sebastian Campmann

Dr. Bernhard Schenkel

No. HRB 1000 SL

Local Court Flensburg

European VAT Number: DE813211547

Disclaimer

reserved. Any use of this trademark without the explicit written permission of Sport-

Tiedje is prohibited.

Product and manual are subject to change. Technical data can be changed without

advance notice.

Intended Use

The equipment may only be used for its intended purpose.

This tness equipment is suitable for home use, light commercial use and full commercial or

professional use. The light commercial sector includes, for example, institutional facilities such

as hospitals, schools, hotels and associations. Full commercial use refers to commercial use, e.g.

in a tness studio.

Ergo-X

ABOUT THIS MANUAL

Please carefully read the entire manual before installation and rst use. The manual will help you to

quickly set up the system and explains how to safely use it. Make sure that all persons exercising with

the equipment (especially children and persons with physical, sensory, mental or motor disabilities)

are informed about this manual and its contents in advance. In case of doubt, responsible persons

must supervise the use of the equipment.

Due to ongoing changes and software optimisations, the manual may have to be

updated. If you notice any discrepancies during assembly or use, please refer to

the manual uploaded to the webshop. The latest manual is always available there.

This equipment has been manufactured according to the latest safety knowledge. As far as possible,

potential safety hazards which could cause injury have been eliminated. Make sure to carefully follow

the instructions and that all parts are securely in place. If required, read through the instructions

again to correct any mistakes.

Please pay close attention to the safety and maintenance instructions given here. The contract

partner cannot be held liable for damage to health, accidents or damage to the equipment when it

is not used in accordance with these instructions.

The following safety instructions may appear in this manual:

࣑ATTENTION

This notice indicates potentially hazardous situations which, if not avoided, may result in

property damage.

⚠CAUTION

This notice indicates potentially hazardous situations which, if not avoided, may result in slight

or minor injuries!

⚠WARNING

This notice indicates potentially hazardous situations which, if not avoided, may result in death

or serious injuries!

⚠DANGER

This notice indicates potentially hazardous situations which, if not avoided, will result in death

or serious injuries!

LNOTICE

This notice indicates further useful information.

Retain these instructions in a safe place for future reference, maintenance or when ordering

replacement parts.

Ergo-X

1 GENERAL INFORMATION

1.1 Technical Data

LCD display of:

+ Time in min

+ Speed in km/h

+ Distance in km

+ Calories in kcal

+ Heart rate (when using a chest strap)

+ Watt

Weight and Dimensions

Article weight (gross, incl. packaging): 62.5 kg

Article weight (net, excl. packaging): 53.5 kg

Package dimensions (LxWxH): 132 cm x 27.5 cm x 89 cm

Set-up dimensions (LxWxH): 140 cm x 61 cm x 126 cm

Maximum user weight: 150 kg

Ergo-X

1.2 Personal Safety

⚠DANGER

+ Before you start using the equipment, you should consult your physician that this type of

exercise is suitable for you from a health perspective. Particularly aected are persons who:

have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,

smoke, have high cholesterol values, are overweight and/or have not exercised regularly in

the past year. If you are under medical treatment that aects your heart rate, medical advice

is absolutely essential.

+ Note that excessive training can seriously endanger your health. Please also note that

heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,

nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising

immediately and seek advice from your doctor if necessary.

⚠WARNING

+ This equipment may not be used by children under the age of 14.

+ Children should not be allowed unsupervised access to the equipment.

+ Persons with disabilities must have a medical license and must be under strict observation

when using the equipment.

+ The equipment is strictly for use by one person at a time.

+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well

clear of moving parts.

+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing

sports shoes, make sure they have suitable soles, preferably made of rubber or other non-

slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise

barefoot.

⚠CAUTION

+ If your equipment needs to be connected to the power supply with a mains cable, make

sure that the cable is not a potential tripping hazard.

+ Make sure that nobody is within the range of motion of the equipment during training so as

not to endanger you or other persons.

࣑ATTENTION

+ Do not insert any objects of any kind into the openings of the device.

Ergo-X

1.3 Set-Up Place

⚠WARNING

+ Do not place the equipment in main corridors or escape routes.

⚠CAUTION

+ Choose a location in which to place the equipment such that there is enough free space/

clearance to the front, the rear and to the sides of the equipment. Make sure that you leave

at least 30 cm on each side of the equipment and at least 15 cm in front of and behind the

equipment as a training zone. This is the minimum required area in order to safely use the

equipment. The recommended free zone around the equipment should be at least 60 cm on

each side and 45 cm in front of and behind the equipment.

+ The training room should be well ventilated during training and not be exposed to any

draughts.

+ Choose the place in which to set up the equipment such that there is enough free space/

clearance to the front, the rear and to the sides of the equipment.

+ The set-up and mounting surface of the equipment should be at, loadable and solid.

࣑ATTENTION

+ The device may only be used in one building, in suciently tempered and dry rooms

(ambient temperatures between 10°C and 35°C). The equipment should not be used

outdoors or in rooms with high humidity (over 70%) like swimming pools.

+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings

(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight

unevenness.

Ergo-X

2 ASSEMBLY

2.1 General Instructions

⚠DANGER

+ Do not leave any tools, packaging materials such as foils or small parts lying around,

as otherwise there is a danger of suocation for children. Keep children away from the

equipment during assembly.

⚠WARNING

+ Pay attention to the instructions attached to the equipment in order to reduce the risk of

injuries.

⚠CAUTION

+ Do not open the packaging when it is lying on its side.

+ Ensure to have sucient room for movement in each direction during assembly.

+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek

the help of a third technically skilled person.

࣑ATTENTION

+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or

packaging board.

LNOTICE

+ In order to make the assembly as simple as possible, some screws and nuts to be used can

already be pre-assembled.

+ Ideally, assemble the equipment at its later set-up place.
