Taurus FX9.9 Manuel utilisateur

TF-FX99.01.02

Elliptical Trainer FX9.9

Assembly and Operating Instructions

TF-FX9.9

FX9.9

Content

1 GENERAL INFORMATION 7

1.1 Technical Data 7

1.2 Personal Safety 8

1.3 Electrical Safety 9

1.4 Set-Up Place 9

2 ASSEMBLY 10

2.1 General Instructions 10

2.2 Scope of Delivery 11

2.3 Assembly 12

3 OPERATING INSTRUCTIONS 21

3.1 Console display 21

3.2 Button functions 22

3.3 Powering on the crosstrainer 23

3.4 Standby mode 23

3.5 MANUAL (Manual programs) 24

3.5.1 Quick-Start program 24

3.5.2 Target programs 24

3.6 PROGRAM (Prole programs) 25

3.7 USER (User dened program) 27

3.8 H.R.C. (Heart rate controlled programs) 28

3.9 WATT (Watt program) 29

3.10 RECOVERY (Recovery function) 29

3.11 BODY FAT (Body fat analysis) 30

3.12 Bluetooth and tness apps 31

4 STORAGE AND TRANSPORT 32

4.1 General Instructions 32

4.2 Transportation Wheels 32

5 TROUBLESHOOTING, CARE AND MAINTENANCE 33

5.1 General Instructions 33

5.2 Faults and Fault Diagnosis 33

5.3 Error codes and troubleshooting 34

5.4 Maintenance and inspection calendar 34

6 DISPOSAL 34

FX9.9

7 RECOMMENDED ACCESSORIES 35

8 ORDERING SPARE PARTS 36

8.1 Serial Number and Model Name 36

8.2 Parts List 37

8.3 Exploded Drawing 42

9 WARRANTY 43

10 CONTACT 45

FX9.9

Dear customer,

Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and

tness equipment for the sophisticated home sport and the equipment of tness studios and

business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum

performance! Therefore, the equipment is developed in close consultation with athletes and sports

scientists. Because athletes know best what makes perfect tness equipment.

Further information can be found at www.sport-tiedje.com.

Legal Notice

Sport-Tiedje GmbH

Europe’s No. 1 for home tness

International Headquarters

Flensburger Straße 55

24837 Schleswig

Germany

Management:

Christian Grau

Sebastian Campmann

Dr. Bernhard Schenkel

No. HRB 1000 SL

Local Court Flensburg

European VAT Number: DE813211547

Disclaimer

reserved. Any use of this trademark without the explicit written permission of Sport-

Tiedje is prohibited.

Product and manual are subject to change. Technical data can be changed without

advance notice.

Intended Use

The equipment may only be used for its intended purpose.

The equipment is suitable for home use and semi-professional use (e.g. hospitals, clubs, hotels,

schools, etc.). The equipment is not suitable for commercial or professional use (e.g. tness

studio).

FX9.9

ABOUT THIS MANUAL

Please carefully read the entire manual before installation and rst use. The manual will help you to

quickly set up the system and explains how to safely use it. Make sure that all persons exercising with

the equipment (especially children and persons with physical, sensory, mental or motor disabilities)

are informed about this manual and its contents in advance. In case of doubt, responsible persons

must supervise the use of the equipment.

This equipment has been manufactured according to the latest safety knowledge.

As far as possible, potential safety hazards which could cause injury have been

eliminated. Make sure to carefully follow the instructions and that all parts are

securely in place. If required, read through the instructions again to correct any

mistakes.

Please pay close attention to the safety and maintenance instructions given here. The contract

partner cannot be held liable for damage to health, accidents or damage to the equipment when it

is not used in accordance with these instructions.

The following safety instructions may appear in this manual:

࣑ATTENTION

This notice indicates potentially hazardous situations which, if not avoided, may result in

property damage.

⚠CAUTION

This notice indicates potentially hazardous situations which, if not avoided, may result in slight

or minor injuries!

⚠WARNING

This notice indicates potentially hazardous situations which, if not avoided, may result in death

or serious injuries!

⚠DANGER

This notice indicates potentially hazardous situations which, if not avoided, will result in death

or serious injuries!

LNOTICE

This notice indicates further useful information.

Retain these instructions in a safe place for future reference, maintenance or when ordering

replacement parts.

FX9.9

1 GENERAL INFORMATION

1.1 Technical Data

LCD Display:

+ Training duration in min.

+ Speed in km/h

+ Training distance in km

+ Calories in kcal

+ Incline in %

+ Heart rate (using the hand pulse sensors or a chest strap)

+ RPM

+ Watts

Brake system: Electro-magnetic induction brake

Resistance levels: 32

Watt range: 50 - 400W

User proles: 4

Programs in total: 25

Quick-start program: 1

Target programs: 4

Pre-set programs: 12

User dened programs: 1

Heart rate programs: 4

Watt programs: 1

Recovery programs: 1

Fitness programs: 1

Stride length: max. 56cm

Transfer ratio: 1:8.75

Flywheel mass: 10kg

Weight and dimensions:

Packed dimensiosn (LxBxH): 125cm x 65cm x 95cm

Assembled dimensions (LxBxH): 211cm x 82cm x 188cm

Article weight (gross, incl. packaging): 150.6kg

Article weight (net, without packaging): 127.3kg

Maximum user weight: 180kg

FX9.9

1.2 Personal Safety

⚠DANGER

+ Before you start using the equipment, you should consult your physician that this type of

exercise is suitable for you from a health perspective. Particularly aected are persons who:

have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,

smoke, have high cholesterol values, are overweight and/or have not exercised regularly in

the past year. If you are under medical treatment that aects your heart rate, medical advice

is absolutely essential.

+ Note that excessive training can seriously endanger your health. Please also note that

heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,

nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising

immediately and seek advice from your doctor if necessary.

⚠WARNING

+ This equipment may not be used by children under the age of 14.

+ Children should not be allowed unsupervised access to the equipment.

+ Persons with disabilities must have a medical license and must be under strict observation

when using the equipment.

+ The equipment is strictly for use by one person at a time.

+ If your equipment provides a safety key, the clip of the safety key must be attached to your

clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the

equipment can be initiated.

+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well

clear of moving parts.

+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing

sports shoes, make sure they have suitable soles, preferably made of rubber or other non-

slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise

barefoot.

⚠CAUTION

+ If your equipment needs to be connected to the power supply with a mains cable, make

sure that the cable is not a potential tripping hazard.

+ Make sure that nobody is within the range of motion of the equipment during training so as

not to endanger you or other persons.

࣑ATTENTION

+ Do not insert any objects of any kind into the openings of the device.

FX9.9

1.3 Electrical Safety

⚠DANGER

+ In order to reduce the risk of an electric shock, always unplug the equipment from the

mains socket immediately after your workout, before assembly or dismantling, and before

maintenance or cleaning. Do not pull on the cable.

⚠WARNING

+ Do not leave the equipment unattended while the mains cable is plugged into the mains

socket. During your absence, the mains cable must be removed from the mains socket to

prevent improper use by third parties or children.

+ If the mains cable or plug is damaged or defective, contact your contract partner. Until

repair, the equipment must not be used.

࣑ATTENTION

+ The equipment requires a mains connection of 220-230V with 50Hz mains voltage.

+ The equipment may only be connected directly to an earthed socket using the supplied

mains cable. Extension cables must conform to VDE guidelines. Always completely unwind

the mains cable.

+ The socket must be protected by a fuse with a minimum fuse rating of "16A, slow blow".

+ Do not make any changes to the mains cable or the mains plug.

+ Keep the mains cable away from water, heat, oil and sharp edges. Do not route the mains

cable underneath the equipment or under a carpet or rug, and do not place any objects on

top of it.

1.4 Set-Up Place

⚠WARNING

+ Do not place the equipment in main corridors or escape routes.

⚠CAUTION

+ The training room should be well ventilated during training and not be exposed to any

draughts.

+ Choose the place in which to set up the equipment such that there is enough free space/

clearance to the front, the rear and to the sides of the equipment.

+ The set-up and mounting surface of the equipment should be at, loadable and solid.

࣑ATTENTION

+ The device may only be used in one building, in suciently tempered and dry rooms

(ambient temperatures between 10°C and 35°C). The equipment should not be used

outdoors or in rooms with high humidity (over 70%) like swimming pools.

+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings

(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight

unevenness.

FX9.9

2 ASSEMBLY

2.1 General Instructions

⚠DANGER

+ Do not leave any tools, packaging materials such as foils or small parts lying around,

as otherwise there is a danger of suocation for children. Keep children away from the

equipment during assembly.

⚠WARNING

+ Pay attention to the instructions attached to the equipment in order to reduce the risk of

injuries.

⚠CAUTION

+ Do not open the packaging when it is lying on its side.

+ Ensure to have sucient room for movement in each direction during assembly.

+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek

the help of a third technically skilled person.

࣑ATTENTION

+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or

packaging board.

LNOTICE

+ In order to make the assembly as simple as possible, some screws and nuts to be used can

already be pre-assembled.

+ Ideally, assemble the equipment at its later set-up place.
