Guide To Using

TASCAM Handheld Recorders

For DSLR Filmmaking

TASCAM has been a leader in audio recording for lmmak-

ers for over 30 years. Our DR-05, DR-07mkII and DR-100

are perfect high-quality audio recorders to match with DSLR,

HDV and other prosumer cameras that are missing great

audio. Capture every moment on-set to give your productions

the polish and legibility your clients demand.

Feature DR-05 DR-07mkII DR-100

Built-in stereo condenser

microphones

Omni Cardioid,

adjustable

Omni & Cardioid

Recording resolution MP3 or WAV,

up to 96k/24-bit

MP3 or WAV,

up to 96k/24-bit

MP3 or WAV,

up to 96k/24-bit

Recording media MicroSD card MicroSD card SD Card

Batteries AA AA AA or Li-ion

rechargeable

Microphone input Stereo 1/8” mini Stereo 1/8” mini (2x) XLR with

phantom power

Remote Control – – Wired/Wireless

Adjustable speed/pitch playback Yes Yes Yes

Stereo limiter on input Yes Yes Yes

Built-in speaker Yes Yes Yes

Line output Combo Phones/Line Out Combo Phones/Line Out Separate Line &

Phones outputs

Battery life 17 hours 17 hours 9+ hours

Optional windscreen WS-DR2 WS-DR2 (Included)

Included accessories 2GB card 2GB card 2GB card, Li-ion battery,

remote, case, windscreen

Advantages Full-featured

stereo recorder

Directional

microphones avoid back-

ground noise

XLR inputs to connect

external mics, dual

batteries

Estimated street price $99 $149 $329

Handheld Recorder Comparison

06/28/11

Page 2 of 2

Guide To Using

TASCAM Handheld Recorders

For DSLR Filmmaking

7733 Telegraph Rd • Montebello, CA • 90640 • 323.726.0303 • www.tascam.com

Connecting to your Camera

Advantages of Audio Recorders

1. Attach the recorder to your camera using a hot shoe

mount (sold separately)

2. Connect an 1/8” cable from the line/headphone output of

the recorder to the MIC IN of your camera (also sold sepa-

rately, use an attenuator cable if available)

3. Set your camera to use the line/mic input, if necessary

4. To automatically synchronize your video clips with the DR-

series recordings, use software like Adobe Premiere Pro

CS5.5, Apple Final Cut Pro X or Singular Software

PluralEyes.

• Youcanassignsomeonetojustrecordaudio,sotheycanget

closer to the talent with a microphone for a better recording.

• TASCAMrecordersarepurpose-builtforaudio,sosettingaudio

levels and adjusting settings is often as easy as a single button

press or switch

• Youcansettheaudiorecordingleveltobemanualorautomatic

• TASCAMhandheldrecordershavealimiterduringrecording,so

that sudden loud sounds won’t be distorted.

• TheseparatelineoutandheadphoneoutontheDR-100allows

you to listen in headphones while you send a copy of the signal

to your camera to sync up later.

• Aselectablelowcutlterallowsyoutocutbassrumbleorwind

noise while recording

• DualbatteriesontheDR-100allowyoutoswapbatteriesfor

extended battery life – even while recording

Optional WS-DR2 Windscreen
