Tascam HD-R1 Mode d’emploi

HD-R1

Technical Documentation

PRODUCT OVERVIEW

The HD-R1 records in WAV or MP3 files (mono or stereo) at sample rates 44.1/48/88.2/96 kHz; 16 or 24 bit.

Remote control ability is provided via RS-232, Parallel, and RJ45 100M/bit Ethernet. File transfer is

accomplished via Ethernet or USB (type “A” connector).

The HD-R1 provides two channels of Mic preamps with a 20dB pad and phantom power (rear panel selectable).

In addition, unbalanced (RCA), balanced (XLR and Euroblock), and S/PDIF Digital (Coaxial & Optical) I/O is

included. Traditional source device features are Power-on-Play, Front Panel Rotary Input Level Controls,

Headphone Jack w/level control, and a variety of Playback Modes.

MSRP - $1,299.00

The HD-R1 Professional Solid State

Recorder is a two-channel, recording

and playback device using Compact

Flash Card as its storage medium.

Compact Flash Card (Supports Type I and Type II)

USB host interface for USB Flash Cards (file

transfer and USB computer keyboard use only)

Audio data formats: PCM (16/24bit), WAV and

MP3

Sampling rates: 44.1, 48, 88.2 and 96 KHz

Mic/Line XLR (with 20dB pad) balanced I/O

Phantom Power (+ 48V rear panel switch and front

LED panel indicator)

Euroblock terminal (Input and Output)

Unbalanced RCA (Input and Output)

Front panel rotary input level controls

RS-232 interface for control

Ducking (input and playback)

RJ45 100Mbit/s Ethernet interface for file transfer

and control.

D-sub25 parallel remote control interface

16 Direct Play via D-Sub25 pin parallel interface

Power on play (front panel selectable)

S/PDIF Digital In/Out (Coaxial & Optical)

Headphone Jack w/level control

Input through and Auto Fade function

Input monitoring / mixing of live stereo input

along with playback

Program Play, Folder Play, Shuffle Play, Interval

Play Modes etc…

Internal real-time clock. (File carries its creation date

and time.)

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

All features, pricing, and specifications are subject to change without notice. Contact your local TASCAM representative for the latest information.

TASCAM HD-R1

Preliminary information

Shipping August 2008

RS-232

Ethernet

None available.

Compact Flash card 44.1 kHz mono 32

bps MP3 44.1 kHz stereo

128 bps MP3 44.1 kHz stereo

16-bit WAV 96 kHz stereo

24-bit WAV

512 MB 35 hours 8.75 hours 0.8 hours 0.25 hours

1 GB 70 hours 17.5 hours 1.6 hours 0.5 hours

4 GB 280 hours 70 hours 6.5 hours 2 hours

8 GB 560 hours 140 hours 13 hours 4 hours

16 GB 1120 hours 280 hours 26 hours 8 hours

ANELS

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

All features, pricing, and specifications are subject to change without notice. Contact your local TASCAM representative for the latest information.

TASCAM HD-

Specifications

Applicable Recording Media: Compact Flash

Recording Format: WAV, MP3

Quantization: 16/24 bit liner, MP3

Sampling Frequency: 44.1/48KHz

MIC/LINE INPUT

Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD), balanced

Euro Block Terminal, balanced

LINE INPUT

Connector: RCA, unbalanced

LINE OUTPUTS

Connector: XLR-3-32 (1: GND, 2: HOT, 3: HOT), balanced

Euro Block Terminal, balanced

Connector: RCA, unbalanced

COAXIAL INPUT

Connector: RCA

Format: IEC60958-2 (S/PDIF)

Quantization: 16/24-bit

COAXIAL OUTPUT

Connector: RCA

Format: IEC60958-2 (S/PDIF)

Quantization: 16/24-bit

HEADPHONE OUTPUT:

Connector: 1/4” Stereo Phone Jack

Serial Control

Connector: D-sub 9 pin

Parallel Control

Connector: D-sub 25 pin

LAN

Connector: RJ45

USB

Connector: USB A-type

All specifications subject to change without notice

SPECIFICATIONS

TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303 http://www.tascamcontractor.com

All features, pricing, and specifications are subject to change without notice. Contact your local TASCAM representative for the latest information.

TASCAM HD-
