Talkaphone AOR-5 Manuel utilisateur

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 1of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

I. Introduction

This installation guide provides instructions for installation, programming, and operation of Model

AOR-5 or Model AOR-10. For instructions on installation or programming of Talkaphone Area of

Rescue Call Stations, please refer to the manual for the AOR-CSE Analog Call Station.

It is recommended that this instruction set be read completely prior to the start of any installation.

II. Contents

Please ensure receipt of each of the included AOR-5 / AOR-10 components:

QTY

Part Number

Description

AOR-5 or AOR-10

5- or 10-Station Area of Rescue Command Unit

68684

12VDC, 4.5Ah Backup Battery

Optional components (sold separately) include:

QTY

Part Number

Description

AOR-TR10

Trim Ring for Flush Mounting Model AOR-5 or Model

AOR-10 without Latched Door

AOR-TR10-D

Trim Ring for Flush Mounting Model AOR-5 or Model

AOR-10 with Latched Door

42970

6-18 Phillips Screw for Flush Mount Trim Ring

THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE

APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH

THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE

HAZARDS INVOLVED

CE PRODUIT DOIT ÊTRE INSTALLÉ SELON LE CODE D’INSTALLATION

PERTINENT, PAR UNE PERSONNE QUI CONNAÎT BIEN LES PRODUIT

ET SON FONCTIONNEMENT AINSI QUE LES RISQUES INHÉRENTS

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 2of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

III. Technical Requirements

Power for Command Unit:

24 VDC, 2A power source

Power for AOR-CSE Analog Call Stations:

AOR-CSE Analog Call Stations are line-powered by the AOR-5 / AOR-10 Command Unit.

Cabling should meet these specifications:

•Twisted, shielded pair specifically designed for use with analog telephones

•Connect shield to earth ground at the Command Unit

•Distance ranges for recommended wire gauges are provided in the table below:

Distance from Command Unit to AOR-CSE

Analog Call Station or Local Phone(s)

Recommended

Wire Gauge

0 to 1,000 feet

24 AWG

1,001 to 1,500 feet

22 AWG

1,501 to 2,500 feet

20 AWG

2,501 to 3,500 feet

18 AWG

PSTN/POTS Telephone Line:

For Local Mode Only:

No external phone line (i.e. POTS/PSTN telephone line) is required.

For Remote Mode:

One (1) dedicated POTS/PSTN telephone line (i.e. analog telephone line or analog PBX

extension line).

If connected to a PBX, the analog extension must provide:

1. Minimum of 24V talk battery and 20 mA off-hook loop current

2. Either a CPC (Calling Party Control) disconnect pulse (voltage drop at end of call) or 30-

seconds of silence after hang-up (no re-order or howler feature)

If connected to a POTS/PSTN line, there must be no special features, such as hook-flash, call-

waiting, auto-redial when busy or voicemail. If the telephone company has activated any such

features, contact them to have these features turned off.

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 3of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

IV. System Overview

1. Local Mode

In Local Mode, pressing the button on any of the Talkaphone Analog Call Stations will call the

AOR-5 / AOR-10 Command Unit and/or Sub-Command Unit(s).

2. Remote Mode

Remote Mode is primarily used when a central control point is not always constantly attended.

In Remote Mode, the Command Unit will allow any of the Talkaphone Analog Call Stations

access to a phone line for remote dial out.

In this mode, Talkaphone Analog Call Stations can dial, in round robin fashion, from a list of up to

five (5) phone numbers—this list can be comprised of a mix of remote phone numbers or local

answering points (i.e. the AOR-5 / AOR-10 Command Unit and/or Sub-Command Unit(s)).

For this configuration, connect an outside phone line to the “TELCO IN” terminal.

NOTE: See p.2, Technical Requirements, for outside phone line requirements.

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 4of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

V. Internal System Components

Figure 1. Model AOR-5, front view.

Figure 2. Model AOR-5, internal components.

Item

Component

Local Handset

PSTN Line Disconnect

Button

Station Selection Buttons

Sub-Command Unit

Selection Buttons

Status LEDs

Fault LEDs

FAULT RESET Key Switch

Item

Component

5-channel Controller Board

Station 1-5 Terminals

“TELCO IN” Terminal

Open/Short/System Ground

Fault/AOR-CSE Station

Activation Relay Outputs

24VDC Input Terminal

Orange-red Configuration

Button

4.5Ah Backup Battery

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 5of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

Figure 3. Model AOR-10, front view.

Figure 4. Model AOR-10, internal components.

Item

Component

Local Handset

PSTN Line Disconnect

Button

Station Selection Buttons

Sub-Command Unit

Selection Buttons

Status LEDs

Fault LEDs

FAULT RESET Key Switch

Item

Component

10-channel Controller Board

Station 1-10 Terminals

“TELCO IN” Terminal

Open/Short/System Ground

Fault/AOR-CSE Station

Activation Relay Outputs

24VDC Input Terminal

Orange-red Configuration

Button

4.5Ah Backup Battery

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 6of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

VI. Installation

1. Remove the AOR-5 / AOR-10 unit from its packaging carton and inspect for any possible

damage. If the unit is damaged or if any components are missing, please contact your

Talkaphone distributor immediately.

Do not discard any hardware or packaging prior to checking for all included components listed

above and ensuring that the unit is installed and functioning as expected.

2. Model Configurations without Latched Door:

Remove the six (6) screws from the stainless steel front panel. Carefully take the panel off the

enclosure—there are cables connected to the front panel.

Model Configurations with Latched Door:

Open the latched door and remove the packaged front cover door handle. Install the handle onto

the outside surface of the latched door using the provided screws.

Remove the six (6) screws from the stainless steel front panel. Carefully take the panel off the

enclosure—there are cables connected to the front panel.

3. The AOR-5 / AOR-10 unit may be either surface mounted or flush mounted to a wall.

NOTE: For flush mounting configuration without the latched door, AOR-5 / AOR-10 units

should be ordered with the available AOR-TR10 Flush Mount Trim Ring (sold

separately).

For flush mounting configurations with latched door, AOR-5 / AOR-10 units should be

ordered with the available AOR-TR10-D Flush Mount Trim Ring (sold separately).

NOTE: Conduit knockouts exist on the left, right, and bottom sides of the cabinet for

access to power and communication lines. Determine the method of bringing in these

power and communication lines before mounting the enclosure.

NOTE: Whenever possible, it is best to keep the maximum clearance possible between

analog phone lines and alternating current. Running phone lines too close to hot VAC

lines will lead to noise or interference on the phone line.

4. Surface Mounting onto an Interior Wall:

The AOR-5 / AOR-10 unit has four (4) surface mounting keyholes located on the rear of the

chassis.

5. Flush Mounting into an Interior Wall:

The AOR-5 / AOR-10 unit has six (6) screw points on the sides which can be used to mount the

Command Unit within a wall.

Both halves of the AOR-TR10 trim ring (or AOR-TR10-D for latched door configurations) should

be secured to the wall using the provided 6-18 screws.

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 7of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

6. Interfaces

7. The AOR-5 can support up to five (5) AOR-CSE Stations and the AOR-10 can support up to ten

(10) AOR-CSE Stations.

The AOR-CSE Stations can dial out through an analog (PSTN/POTS) telephone line, to the local

handset on the Command Unit, or to a Sub-Command Unit.

8. Routing Cabling:

Route the AOR-CSE Station cabling and the analog (PSTN/POTS) telephone line (depending on

the local jurisdiction, may or may not be required) through the conduit knockouts located on the

left, right, or bottom sides of the Command Unit. Always try to separate power lines from

communication lines in order to mitigate the risks of noise or interference on the communication

lines.

This section outlines the interfaces on the controller

board:

(A) Station #1-5 –Each AOR-CSE Station is

provided with a dedicated terminal

(B) Station #6-10 (for AOR-10 only) –Each AOR-

CSE Station is provided with a dedicated terminal

Sub-Command Units #1 and #2

(D) PSTN Line –Connect an analog (PSTN/POTS)

telephone line or analog PBX extension line for

dialing off-site or to a remote answering point

(E) Earth Ground –Connect Earth ground

(F) Station Active –This relay output (normally

open, NO) will provide a contact closure when any

AOR-CSE Station is activated

(G) Power Fault –This relay output (normally open,

NO) will provide a contact closure when there is a

loss in 24VDC power

(H) Battery Fault –This relay output (normally open,

NO) will provide a contact closure when the

backup battery is disconnected or providing a low

voltage output

(I) Ground Fault –This relay output (normally open,

NO) will provide a contact closure when a system

ground fault is present

(J) Phone Fault –This relay output (normally open,

NO) will provide a contact closure when a short or

open is present on any Station or PSTN Line

terminal

(K) 24 VDC –Connect a 24VDC power supply

(L) Config –Used to configure the Station and

PSTN Line terminals

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 8of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

9. Terminating AOR-CSE Station Cabling:

Terminate the cabling for each AOR-CSE Station to Station 1 through Station 5 (or through

Station 10).

The tip and ring connections for the AOR-CSE Stations are NOT polarity sensitive.

10. Terminating PSTN/POTS Telephone Line for Off-site Dialing:

If an analog (PSTN/POTS) telephone line or analog PBX extension line is to be used for off-site

dialing, terminate the analog telephone line or PBX extension line to the PSTN Line terminal on

the controller board—this connection is NOT polarity sensitive.

Each AOR-5 / AOR-10 Command Unit supports one (1) dedicated POTS/PSTN telephone line.

11. Connecting Primary Power:

Once the appropriate low voltage field cabling terminations have been completed, connect the

primary power (24VDC, 2A) to the controller board—the power input connector is located at the

center-bottom of the controller board.

Earth ground should be connected to the Earth Ground terminal on the center-left side of the

controller board.

It is the installer’s obligation to ensure compliance with all national, regional, and

local regulations.

IMPORTANT NOTE:

See Technical Requirements (p.2), for analog PSTN/POTS telephone line specifications.

IMPORTANT NOTE:

The Command Unit will only power on when primary power is connected. If the backup

battery is connected first, the Command Unit will not power on until primary power is

connected to the system.

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 9of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

12. Fault Detection Configuration for AOR-CSE Stations and PSTN Line:

Carrying out this procedure on the controller board is required for proper open/short fault and

PSTN/POTS telephone line fault detection on the system.

In the lower-right of the controller, there is an orange-red configuration button.

Once you have the AOR-CSE Stations and the PSTN/POTS telephone line (if required)

terminated to the controller board, press and hold the orange-red button for three (3) seconds—

the LED will flash rapidly. When the LED turns solid, release the orange-red button. You will

hear a beep to confirm that configuration has been completed.

13. Connecting the Backup Battery:

Install the backup battery inside the Command Unit cabinet and connect its faston tabs to the

appropriately marked battery cable—black goes to black, red goes to red.

It is the installer’s obligation to ensure compliance with all national, regional, and

local regulations.

It is the installer’s obligation to mark the “date of installation” on each battery.

Area of Rescue Command Unit

Installation Guide

Model AOR-5 / Model AOR-10

Page 10 of 23 Rev. 4/13/2022

All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, bAlert, Scream Alert, WEBS, and WEBS Contact are registered trademarks of

any approval, endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.

VII. System Programming

List of Programming Codes for the Command Unit

Command

Function

* 31 * [up to 8 digits] *

Guard Access Code entry for phone programming

[Default * 31 * *]

* 30 * [up to 8 digits] *

Master Access Code entry to change Guard Access Code, Master

Access Code, and/or factory default the unit

[Default * 30 * 12345678 *]

* 30 * 14725836 *

Resets controller board programming to factory defaults.

Requires prior Master Access Code entry.

* 32 * [up to 8 digits] *

Programs and stores a new Master Access Code.

Requires prior Master Access Code entry.

* 33 * [up to 8 digits] *

Programs and stores a new Guard Access Code.

Requires prior Master Access Code entry.

* 34 * [1 to 99] *

Sets number of rings before controller board picks up when it is

dialed (1 to 99)

[Default 3]

* 37 *

Local Mode

NOTE: All calls will route to the Command Unit handset and/or

Sub-Command Unit(s).

* 38 * [1 to 24] *

PSTN line test interval in hours (1-24 hours)

[Default 23]

* 39 * 1 *

PSTN line is a Central Office (CO) line from the telephone

company (allows 9 transfers)

[Default]

* 39 * 2 *

PSTN line is a PBX extension (disables 9 transfers)

* 56 * 1 *

Ignore any inbound PSTN line call when Stations, Command Unit,

and/or Sub-Command Unit(s) are active

[Default]

* 56 * 2 *

Allow any inbound PSTN line call to barge in when Stations,

Command Unit, and/or Sub-Command Unit(s) are active

* 57 *

Erase the “On Hold” voice message for calls in queue or on hold

* 58 *

Record the “On Hold” voice message for calls in queue or on hold.

Press the # key to stop recording or it will end after 50 seconds.

The recorded message will automatically play back.

* 59 *

Preview the recorded “On Hold” voice message for calls in queue

or on hold

* 62 *

Remote Mode

[Default]

Ce manuel convient aux modèles suivants

Table des matières

Manuels Téléphone sans fil populaires d'autres marques

3Com

3Com NBX Manuel utilisateur

Panasonic

Panasonic KX-TGK210HK Manuel utilisateur

Panasonic

Panasonic KX-TCA181EX Manuel utilisateur

BT FREESTYLE 3200 Manuel utilisateur

AT&T

AT&T CL84102 Manuel utilisateur

BREZZICNI

BREZZICNI CL-3622 Manuel utilisateur

Panasonic

Panasonic KX-TG1831NZ Manuel utilisateur

Panasonic

Panasonic KX-TG7301E Manuel utilisateur

Furuno

Furuno FM-4721 Manuel utilisateur

Sanyo

Sanyo CLT-J70 Manuel utilisateur

Amplicomms

Amplicomms BigTel 201 Manuel utilisateur

GE 26992 Manuel utilisateur

AT&T

AT&T E1812B Manuel utilisateur

Sanyo

Sanyo CLT-670 Manuel utilisateur

GE 15432970 Manuel utilisateur

Curtis

Curtis TC595 Manuel utilisateur

Gigaset

Gigaset Gigaset 3000 Micro Manuel utilisateur

Poly

Poly VVX D230 Guide de configuration
