Tab T9-Pro Manuel d'exploitation
Model:
T9-Pro
Product User Manual
Please read this manual carefully before use
The company reserves the right to interpret the manual
The appearance of the product is subject to the real product
Please keep it properly with the invoice after reading it
In case of product technology or software upgrade, there shall not be prior notice
Packing list
Ground cleanser x1
（Be suitable for cleaning
all kinds of ground stains）
Cleaning tool x1
（Be suitable for cleaning residual stains in
dirty-water tank of floor scrubber
and hair wound by the rolling brush）
Rolling brush x2 Adaptor x1
Main unit x1
Filter x1 Screwdriver x1
Charging base assembly A x1
Charging base assembly B x1
Screw x4
Accessories of main unit
Before using this product, please check whether the package contains the following items.
Please contact our customer service for any missing.
The pictures are for reference only. Please refer to the real product received.
x1
Contents
Safety instruction 1
Product Introduction 3
Product Installation 4
How to Use 7
Product Maintenance 11
Product Parameters/Description
of hazardous substances in the product 13
Failure Recovery 14
Warranty Card/Warranty Terms 15
1
Safety instruction
1. This product is only used on indoor surfaces. It is forbidden to install, charge and use
this product outdoors, in bathrooms and around swimming pools.
2.This product may not be used by people with physical, sensory or intellectual disabilities
and people without relevant experience and knowledge (including children), unless there
is a guardian’s care or guidance to ensure that they can use this product safely.
3. Please do not let children use this product as a toy.
4. Please do not touch the plug or any live parts of the product with wet hands to avoid
electric shock.
5. Please do not move this product from the power cord or other cables, otherwise it may
cause danger.
6. If the charger or plug is damaged, please stop using it. Please call the professional
maintenance personnel of our company to replace it, so as to avoid harm.
7. When using, if leakage or excessive motor temperature and abnormal sound are found,
such as overheating of the unit, abnormal sound, peculiar smell and weak suction, please
immediately stop using it and call our professional maintenance personnel.
8. When charging, please use the charger specially designed by our company for
charging. Other types of chargers may cause battery failure or extreme thermal effect.
9. If this product is not used for a long time, please turn off the power supply and unplug
the charging socket.
10. Please do not use this product near or on the surface of inflammable and explosive
objects, which may lead to fire and explosion.
11. Please do not use this product near the working fireplace or heater to prevent the
machine shell from being deformed.
12. Please do not use this product to absorb high-temperature substances (unlit cigarette
butts, matches or hot ashes, etc.), superfine substances (such as lime, cement, wood
chips, gypsum powder, ashes and carbon powder, etc.), sharp fragments (such as glass,
nails and pins, etc.), dangerous goods (such as solvents and detergents, etc.), chemical
substances (such as acid substances and detergents, etc.), flammable and explosive
liquids (gasoline, alcoholic products) and other substances with uncertain physical
characteristics.
13. Shoe polish, paint, pigment and other stains with strong grease, strong stickiness or
strong dyeability are not within the scope of use of this product.
2
Safety instruction
14. Please clean according to the instructions of the detergent. If a large amount of clean-
ing solution is added, more foam will be generated during use, which may penetrate into
the motor and cause danger. It is recommended to use the detergent produced by our
company and the manufacturer approved by our company, and it must not contain acid,
alkali solution or substances harmful to the environment.
15. Please keep the detergent out of the reach of children. If the cleaning solution
accidentally enters the eyes, rinse thoroughly with clean water; if you accidentally eat, you
should seek medical attention immediately.
16. Please do not disassemble the closed machine by yourself. There are no parts in the
machine that customers can repair by themselves, and do not try to change the perfor-
mance of the machine, otherwise it will lead to danger.
17. Please do not use the voltage that does not correspond to the specifications of this
product, otherwise it will damage the motor, and it is more likely to hurt the users.
18. Please do not shake the machine up and down or collide violently, and do not tilt the
machine to one side or lay flat to prevent sewage from flowing into the motor.
19. The main body and floor brush of this product contain electrical components, which
should not be soaked in water or washed, otherwise fire and electric shock accidents may
occur due to short circuit of the machine.
20. It is forbidden to use this product without installing the rolling brush, clean-water tank,
dirty-water tank and filter element.
21. Please make sure to replace the rolling brush after turning off the machine.
22. After using the machine, please clean up the dirty-water tank in time to keep the
ventilation path unblocked, so as to avoid the suction drop and motor heating caused by
blockage, thus affecting the service life of the machine.
23. After using the machine, please keep it in a dry place. Humid places will affect the
insulation and service life of electrical appliances.
24. In order to prevent tripping, the machine should be placed against the wall after use.
25. Please check the smoothness of the suction nozzle regularly. If there is any blockage,
please clear it in time, so as to avoid the decrease of suction caused by blockage and
affect the service performance of the machine.
26. When the machine breaks down, please do not repair it yourself. Please call the
after-sales department of our company for help.
3
Product Introduction
Main unit
ON/OFF button
Display screen
Self-cleaning button
Dirty-water tank
release button
Dirty-water tank
Dirty-water tank handle
Front rolling brush cover
Front rolling brush
cover release button
Front rolling brush
Rear rolling brush cover
Rear rolling brush
Rear rolling brush cover
release button
Clean-water tank
release button
Clean-water tank
Tube
Mode button
Voice button
Clean-water tank handle
1.Handle installation and disassembly
1.1 Installation：
Insert the end of the handle assembly
vertically into the port on the top of the
body according to the direction shown in
the figure, and the it is successfully.
1.2 Disassembly：
Firstly take down the clean-water tank,
then put a pen-like hard object into the
hole on the back of the body to press
the shrapnel, and pull out the handle of
the main unit upwards at the same.
2. Installation of charging base:
Insert the charging base assembly B into the card slot of the charging base assembly
A, and fix it with 4 screws on the back of the assembly A; if it is needed to disassemble,
please unscrew the screw to separate the upper and lower parts.
4
Product Installation
Click
5
Product Installation
3. Clean-water tank installation and disassembly
3.2 Disassembly：
Hold the machine body with one hand
and press the button of the clean-water
tank with the other hand, and then pull it
out to take out the tank..
3.1 Installation：
Firstly, put the bottom of the clean-water
tank into the opening support position of the
machine body, then gently push the
clean-water tank, and it is successfully
installed after hearing the click sound.
Click
Click
4.Dirty-water tank installation and disassembly
4.2 Disassembly：
Hold the machine body with one hand
and press the button of the dirty-water
tank with the other hand, and then pull it
out to take out the tank.
4.1 Installation：
Firstly, put the bottom of the dirty-water tank
into the opening support position of the
machine body, then gently push the
dirty-water tank, and it is successfully
installed after hearing the click sound.
Product Installation
6
5.Installation and disassembly of rolling brush cover
5.1 Installation of the rolling brush cover: press down the protrusion corresponding to
the notch of the rolling brush cover and it is successfully installed after hearing the click
sound (as shown in Figure 1).
5.2 Disassembly of the rolling brush cover: press the center of the button on the front
rolling brush cover, the rolling brush cover will automatically pop up and take out the
rolling brush cover (as shown in Figure 2).
5.3 The installation and disassembly of the front and rear covers of the rolling brush are
consistent.
6.Installation and disassembly of rolling brush assembly
6.1 Installation of rolling brush assembly: hold the handle of the rolling brush by hand,
firstly align the right end of the rolling brush with the rolling brush shaft, then put the left
handle of the rolling brush into the groove, and then install the rolling brush cover (as
shown in Figure 1).
6.2 Disassembly of rolling brush assembly: firstly remove the rolling brush cover, then
pull up the left rolling brush handle by hand, and then pull it out to the left to remove it
(as shown in Figure 2).
6.3 The installation and disassembly of the rolling brush are consistent.
6.4 Rolling brush A is correspondingly installed to the letter A side of the floor brush,
and rolling brush B is correspondingly installed to the letter B side of the floor brush.
Click
1.Water injection of clean-water tank
1.1 Hold down the disassembly button of the clean-water tank and remove the
clean-water tank (as shown in Figure 1).
1.2 Turn the bottom of the clean-water tank upward, open the clean-water tank cover,
and inject clean water. Different water levels can be selected according to the clean
area. If deep cleaning is required, it is recommended to add the specified cleanser in
proportion (as shown in Figure 2).
1.3 Cover the clean-water tank cover and make sure it is in place (as shown in Figure
3).
1.4 Tilt the clean-water tank, firstly put the bottom in place, and then push it inward to
ensure that it is installed in place (as shown in Figure 4).
7
How to Use
Click
12 3 4
Note:
·Please do not add non-designated cleanser or disinfectant to avoid corrosion of the
machine.
·Please add special cleanser according to the specified proportion, and do not add too
much.
·Please do not add hot water over 60℃ to avoid deformation of the clean-water tank.
* Tip: Please try to complete a complete charging and discharging process before using
the product to ensure the accuracy of the electric quantity program.
