SysKonnect SK-4591 Manuel utilisateur

SK-NET TR/PCI (SK-4591)

SK-NET TR/PCI+ (SK-4590)

Siemensstr. 23

D-76275 Ettlingen

BR Deutschland

Tel. +49 7243 502 100

Fax +49 7243 502 989

http://www.syskonnect.de

Token Ring PCI Network Interface Cards

1922 Zanker Road

San Jose, CA 95112

USA

Tel. +1 408 437 3800

Fax +1 408 437 3866

http://www.syskonnect.de

Installation Guide

55-00-070-000

Installation Instructions 2SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

Safety Information - Read This

First First Edition (February 1996)

This edition applies to the SysKonnect products SK-NET TR/PCI (SK-4591) and SK-NET

TR/PCI+ (SK-4590) Token Ring PCI Network Interface Cards. Right of technical

modifications reserved.

We would like to receive comments on this publication. Please address your comments to:

SysKonnect

Information Development

Siemensstraße 23

76275 Ettlingen

Germany

FAX: (49) 72 43 50 29 89

INTERNET: [email protected]

Trademarks

Product names mentioned herein may be trademarks and/or registered trademarks of their

respective companies.

Warranty and Software License

Contracts are included in this documentation.

a business unit of Schneider & Koch & Co. Datensysteme GmbH.

Installation Instructions 3SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

SAFETY INFORMATION -

READ THIS FIRST

DANGER!

Electric current from power, telephone, and communications cables is hazardous.

To avoid the risk of an electric shock,

➔do not connect or disconnect any cables or perform any installation, maintenance or

reconfiguration work during an electrical storm.

➔the power cord of the computer must be connected to a properly wired and grounded

(earthed) receptacle. Any equipment attached to this product must also be properly

wired and connected to grounded receptacles.

➔connect and disconnect cables as described in the following chart.

➔do not connect this product to a telephone line.

The electrical installations must comply with the safety regulations of the country in which

they are used.

Installation Instructions 4SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

Safety Information - Read This

First To connect: To disconnect:

• Turn everything involved in the

connection OFF.

• First, attach all cables to the devices.

• Attach signal cables to receptacles.

• Note: In the UK, by law, the telephone line

cable must be connected after the power

cord (please refer to the Safety Information

above).

• Attach power cord(s) to the outlet(s).

• Turn everything involved in the

connection OFF.

• First, remove power cord(s) from outlet(s).

• Note: In the UK, by law, the power cord

must be disconnected after the telephone

line cable (please refer to the Safety

Information above).

• Remove signal cables from receptacles.

• Remove all cables from the devices.

Installation Instructions 5SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

CONTENTS

SAFETY INFORMATION - READ THIS FIRST 3

FIGURES 8

NOTICES 9

Product support 9

SysKonnect at CompuServe 10

Prerequisites 10

Industry Standards Reflected in This Product 11

Safety Standards 11

Related Manuals 11

CHAPTER 1. GENERAL INFORMATION 12

Features 12

Hardware Requirements 13

The Adapter Kit 13

Handling Instructions 15

What You Need to Install the Adapter 16

Installation Instructions 6SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

Safety Information - Read This

First CHAPTER 2. INSTALLING THE ADAPTER 18

Immediate Installation 18

Step-by-Step Installation 20

Step 1. Remove the Cover from the Computer 20

Step 2. Install the Adapter in an Expansion Slot 20

Step 3. Reinstall the Computer Cover and Reconnect the Cables 24

Step 4. Attach the Adapter to the Data Network 24

LEDs 27

Step 5. Restart and Configure the Computer 28

Step 6. Test the Adapter and Troubleshooting (if Required). 28

Step 7. Install Protocol Drivers and Remote Boot Option 29

Calling and Operating the README Viewer 29

CHAPTER 3. USING THE DIAGNOSTICS PROGRAM 34

Requirements 34

Using the Individual Program Parts 35

Select Board 38

Configure 39

Bring-Up Diagnostics: 40

Open/Close 41

Send/Receive 45

DMA Test 46

PCI Devices 49

Exit 50

RMA (Return Material Authorization) procedure 50

Installation Instructions 7SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

Safety Information - Read This

First APPENDIX A. TECHNICAL SPECIFICATIONS 52

APPENDIX B. SIGNAL ASSIGNMENT OF THE JACK 54

APPENDIX C. ELECTROMAGNETIC COMPATIBLITY NOTICES 55

Federal Communications Commission (FCC) Statement 55

APPENDIX D. LICENSE AND WARRANTY CONTRACTS 57

Great Britain and Ireland 57

Other European Countries 60

USA and Canada 63

U.S. Government Use 65

South and Central America, Asia, Australia, New Zealand and Pacific Rim 67

Installation Instructions 8SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

FIGURES Figure 1. Adapter Kit (e.g. SK-NET TR/PCI or SK-NET TR/PCI+) 14

Figure 2. RJ-45, SubMinD9 Plug 16

Figure 3. Unscrew the Expansion Slot Cover 21

Figure 4. Remove the Expansion Slot Cover 26

Figure 5. Insert the Adapter 27

Figure 6. Connecting UTP/STP Cables with RJ-45 Plugs 27

Figure 7. LEDs 27

Figure 8. README Viewer Copyright Message 30

Figure 9. README Viewer Selection Menu 31

Figure 10. README Viewer "Latest News" 32

Figure 11. Diagnostics Program, Initial Window 36

Figure 12. Diagnostics Program, Main Menu 37

Figure 13. Diagnostics Program, Select Board Menu 38

Figure 14. Diagnostics Program, Bring-Up Test 40

Figure 15. Diagnostics Program, Send/Receive Test 45

Figure 16. Diagnostics Program, DMA Test 46

Figure 17. Diagnostics Program, PCI Device List 49

Installation Instructions 9SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

NOTICES

References in this publication to SysKonnect (SK) products, programs, or services do not

imply that SK intends to make these available in all countries in which SK operates. Any

reference to an SK product, program, or service is not intended to state or imply that only SK's

product, program, or service may be used. Any functionally equivalent product, program, or

service that does not infringe on any of SK's intellectual property rights may be used instead of

the SK product, program, or service. Evaluation and verification of operation in conjunction

with other products, except those expressly designated by SK, are the user's responsibility.

PRODUCT SUPPORT

The Americas, Asia and Pacific Rim Europe, Africa and all other countries

Time Mon-Fri 8 h -15 h Pacific Time Mon-Thu 8 h -18 h, Fri 8:h -15:30 h CET

Tel./ Fax +1 408 437 3857/ +1 408 437 3866 +49 7243 502 330 /+49 7243 502 364

BBS +1 408 437 3869, (8,N,1) 14,400 bps +49 7243 502 586, (8,N,1) 9,600 bps

+49 7243 502 6091, ISDN

email [email protected] [email protected]

WWW http://www.skd.de http://www.skd.de

Address SysKonnect Inc.

1922 Zanker Road;

San Jose, CA 95112 (USA)

SysKonnect

Siemensstr. 23

D-76275 Ettlingen

Installation Instructions 10 SK-NET TR/PCI (+) (SK-459x) Token Ring PCI NIC

Notices

SYSKONNECT AT COMPUSERVE

As a leader in high performance networking, SysKonnect offers current information on-line 24

hours a day within the LAN A Vendor forum at CompuServe. SysKonnect's information pool

includes

• current news

• product information

• driver updates

• direct communication with our support engineers

Prerequisites

To access our service, you need, besides your computer,

• a modem

• the communication software

• a license number (CompuServe membership)

1. Via modem, dial your next CompuServe node

2. Type in GO SYSKONNECT

You will directly reach the LAN A Forum, including the SysKonnect section.
