Sysgration BSE-02 Manuel utilisateur
1
Bluetooth Low Energy
Tire Pressure Monitoring System
User Manual
Model: BSE-02
2
Table of Contents
1. PRODUCT INTRODUCTION....................................................................................................................................3
2. NOTICE ........................................................................................................................................................................3
3. BLE TPMS SPECIFICATION....................................................................................................................................5
4. BLE TPMS PACKAGE ...............................................................................................................................................6
5. BLE TPMS SENSOR INSTALLATION....................................................................................................................6
6. APP DOWNLOAD AND INSTALLATION..............................................................................................................8
7. SETTING & ADD DEVICE ......................................................................................................................................10
8. ALARMS AND WARNINGS....................................................................................................................................18
9. SYSTEM SETTING...................................................................................................................................................19
10. EXCHANGE SETTING...........................................................................................................................................20
11. VOICE DONGLE SETTING ..................................................................................................................................22
12. ABOUT......................................................................................................................................................................24
13. FREQUENTLY ASKED QUESTIONS..................................................................................................................25
14. WARRANTY POLICY............................................................................................................................................25
3
1. Product Introduction
With the new technology product: Bluetooth Low Energy Tire Pressure Monitoring System
Retrofit Kit (hereinafter referred to as BLE TPMS), the driver could get the accurate tire pressure
and temperature at any time through smart phone by using this kit while driving. When the system
detects abnormal status, it will alarm the driver actively, and show the abnormal data and its tire
location on the BLE TPMS APP (hereinafter referred to as APP).
2. Notice
Product Warning
2.1.1 Do not operate the APP while driving. The company is exempt from all responsibilities
that result from driver’s carelessness and improper operation.
2.1.2 The system adopts the wireless transmission of signals. In some special environments,
frequency interference, faulty operation or faulty installation may result in weaker signals or
inability to receive signals. If the insulation adhesive sticker of the windshield contains metallic
material, it will affect the signal reception. When the alarm sounds and shows abnormal data, please
drive the vehicle away from the current location (there may be signal interference in the
surroundings) or drive the vehicle to a tire shop to be checked.
2.1.3 If the TPMS sensor is low on battery(if abnormal conditions exist continuously, the battery
may make the TPMS sensors continuously emit signals to warn the driver, so the battery life will be
shorter than expected), please go as soon as possible to a specified service station to confirm
whether the TPMS sensor needs to be replaced. You will take all the risks and responsibilities if you
do not change the sensor when the low battery sensor warning is displayed.
2.1.4 Temporary resealing or re-inflation of product injected through the valve hole may adversely
affect the operation of the sensor. The company is exempt from all responsibilities. Furthermore, do
not place the TPMS sensor in contact with any chemicals. They might damage the sensor and
prevent it from functioning properly.
2.1.5 Please close any other APPs or web pages which are not in use when using the BLE APP.
Data receiving status of the APP may be affected by the system load of the smart phone.
4
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
5
3. BLE TPMS Specification
BLE Sensor Specification
Operating Voltage 3V
Operating Humidity 95 % MAX
Operating Current ＜15 mA at DC 3V
Storage Temperature -40℃to 85 ℃
Operating Temperature -20℃to 85 ℃
Monitored Pressure Range Passenger: 0 to 92 psi (0 to 640 kPa)
Truck: 0 to 185 psi (0 to 1280 kPa)
Monitored Temperature Range -20 ℃to 85 ℃
Operating Frequency 2.4GHz
Transmission Power 4 dBm MAX
Battery Life 1 years (under normal operating condition)
Battery Capacity 130 mAh (CR1632)
Weight 9.5 g ± 0.5 g (including battery)
Voice Dongle Specification
Operating Voltage 5V
Operating Humidity 95 % MAX
Operating Current ＜900 mA at DC 5V
Storage Temperature -40℃to 85 ℃
Operating Temperature -20℃to 85 ℃
Sound Pressure (min.) 80dB@30cm
Operating Frequency 2.4GHz
Transmission Power 4 dBm MAX
Weight 10 ± 1 g
6
4. BLE TPMS Package
5. BLE TPMS Sensor Installation
5.1 BLE TPMS Sensor Accessories
Part Name Quantity
BLE TPMS Sensor 4 pcs
CR 1632 Battery 4 pcs
Anti-theft part 4 pcs
Lock-Nut 4 pcs
User Manual 1 pcs
Voice Dongle 1 pcs
Spanner 1 pcs
7
1.Battery(CR1632) 2.Tire Sensor 3.Anti-theft part 4.Lock-Nut 5. Spanner
5.2 Installation Steps
8
After installation, please download the APP to your smart phone, and proceed with all settings.
(Please check the 7 Initial Setting)
6. APP Download and Installation
6.1 Operation System Required
TPMS system supports both smartphone for Android & iOS operation system. (Bluetooth 4.0)。
APP Download Operation System Compatible Smartphone
APPLEAPP Store iOS 7.1.2 or later iPhone 4S, 5, 5S, 6, 6 Plus or
later
Android Google Play Store Standard Android 4.3 or later Android Smart Phone
9
6.2 How to Download
Search in the Google Play Store orAPPLE APP Store by keyword “BLE” or ”TPMS” , in order to
find the free APP.( )
After you install the APP, please reboot and make sure Bluetooth is enabled. Open the APP after
installation is completed. A statement from the operation system will pop up, displaying “Bluetooth
Service Disabled” and/or “Location Services Disabled”. Please choose “ok” to turn on the
“Bluetooth” & “Location Services” function.
In case “Location Services” is not turned on properly, please turn it on in “Settings” (only for iOS
system).
iOS version Android version
10
7. Setting & Add Device
7.1 Introduction of Contents
Please make sure the “Bluetooth” & “Location Service” Setting functions are enabled when you
start to use the APP.
iOS version Android version
Start-up Page of the APP
