Symbol LS 5300 Manuel utilisateur

RS 2200/3200 Series

LS 5300/LS 5400

Quick Reference

LS-5300

Quick Reference

Symbol reserves the right to make changes to any product to

improve reliability, function, or design.

Symbol does not assume any product liability arising out of, or

inconnectionwith,theapplicationoruseofanyproduct,circuit,

or application described herein.

No license is granted, either expressly or by implication,

estoppel, or otherwise under any patent right or patent,

covering or relating to any combination, system, apparatus,

machine, material, method, or process in which Symbol

products might be used. An implied license only exists for

equipment, circuits, and subsystems contained in Symbol

products.

Symbol Technologies, Inc.

One Symbol Plaza

Bohemia, N.Y. 11742-1300

WWW: http://www.symbol.com

FCC Information

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation. This Class A digital apparatus meets all

requirements of the Canadian Interference-Causing Equipment

Regulations. Cet appareil numérique de la clase A respecte

toutes les exigences du Règlement sur le matériel brouilleur du

Canada.

Purpose

This Quick Reference Guide is designed to assist you during

routine LS 5300/LS 5400 operation. Detailed information about

unpacking, installation, performance speciﬁcations, and

troubleshooting, can be found in the LS 5300 Product

Reference Guide.

Product Description

LS 5300

The Symbol LS 5300 is a high performance laser scanner that

allows you to quickly and accurately read a bar code, with a

minimum of effort. The LS 5300 can be installed in a variety

of ways. Usually it is either mounted on the checkstand

counter top or built directly into the checkstand.

Quick Reference

Product Description

The LS 5400

TheLS5400isaspecialin-counterversionoftheLS5300thathas

a stainless steel top and scratch resistant glass. This scanner is

ideal for more demanding settings where hard goods such as

cans and bottles are frequently scanned. In all other aspects, the

LS5400 is identical to theLS5300.So, unless noted otherwise, all

references to the LS 5300 will also apply to the LS 5400.

Operating the LS 5300 Scanner

Turning it on

The LS 5300 does not have an on/off switch. As soon as you

plug it in, it’s ready to scan.

Indicator Lights

Notice the red and green indicator lights just below the scan

window. They provide you with information about the

scanner’s operation. Here’s what you can expect to see:

• Green light on, red light off -

This means the scanner is

on, waiting to decode a symbol.

• Green light off brieﬂy -

Abar code has been successfully

decoded. You will also hear a beep from the scanner to

conﬁrm this. As long as this light is off, the scanner will

not decode the same bar code again. This helps to prevent

accidental double reads.

• Green light on, red light on -

The scanner is asleep. See

Sleep Mode, on page 5.

• Anything else -

This includes, steady red light, blinking

red light, or blinking green light. The scanner is not

operating normally. Contact the technical person in

charge of scanning at your location, or see the LS 5300

Product Reference Guide for the number of the Symbol

Support Center.

Quick Reference

Operating the LS 5300 Scanner

Programming

Generally, the technical person in charge of scanning will

customize the scanner for your particular application through

the use of programming bar codes, which are found in the

LS 5300 Product Reference Guide. If you are programming the

scanner yourself, consult the Product Reference Guide for more

information.

Scanning a Bar Code

The shaded areas below represent the scan pattern. For the best

scanning performance, the countertop or surface area covered

by the scan pattern should be free of any designs (e.g. stripes,

patterns). Ideally, that area should be a light, solid color. To scan

a bar code, move an item through the scan pattern, in the

direction of the arrows, with the bar code label facing the

scanner window. The scanner will beep when a bar code has

been decoded successfully.

Scan pattern

Sleep Mode

If there is no scanning activity for a speciﬁed period of time,

the scanner will enter a “sleep” mode. You select this period of

time by scanning the appropriate bar code in the Product

Reference Guide. This sleep mode saves power and extends

the life of the scanner. The LS 5300 will automatically awaken

as soon as you pass a bar coded item past the scan window.

What If...

If the scanner is not operating according to your needs, contact

the technical person in charge of scanning. If there is no one in

charge of scanning, see the LS 5300 Product Reference Guide for

the number of the Symbol Support Center.

Some Helpful Bar Codes

You can adjust the volume and the frequency (tone) of the

scanner’s beeper by scanning the appropriate bar codes

beginning on page 31.

Quick Reference

Objet de ce guide

Ce Guide utilisateur contient des informations générales sur le

maniement de votre terminal LS 5300/ LS 5400. Pour de plus

amples informations sur le déballage, l’installation, les

caractéristiques techniques et le dépannage, reportez-vous au

Guide de référence produit du LS 5300.

Description du produit

LS 5300

Le LS 5300 de Symbol est un lecteur laser hautes performances

permettant une lecture rapide et ﬁable des codes à barres avec

un minimum d’efforts. Le LS 5300 peut être installé de multiples

manières. En général, il est monté sur le comptoir ou y est

intégré.

Guide utilisateur

Description du produit

LS 5400

Le LS 5400 est une version spéciale intégrée du LS 5300 dotée

d’un revêtement en acier et d’une vitre à l’épreuve des rayures.

Ce lecteur est d'une résistance à toute épreuve, même dans les

environnements les plus difﬁciles (lecture répétée d’articles tels

que les bouteilles ou autres produits similaires). Toutes les

autres fonctions sont identiques à celles du LS 5300. Par

conséquent, sauf indication contraire, toutes les caractéristiques

du LS 5300 s’appliquent également au LS 5400.
