SHREDDERS
STACK-AND-SHRED100X&100M™
English instruction manual 6
https://www.supplychimp.com/
6
autofeed technology
The Stack and Shred 100X/100M has been designed to automatically shred up to 100 sheets from
the auto-feed chamber and up to 6 sheets through the manual feed slot.The auto-feed mechanism
has been designed to handle paper fastened with staples and paper clips and to only pull a few
sheets of paper into the cutting mechanism to minimise the risk of paper jams.
To guard against injury, the following basic safety precautions must be observed in the set-up of this
product.
• Ensure the machine is plugged into an easily accessible power outlet, and ensure the cable is not
likely to trip up a passer by.
• Any attempt to repair this unit by unqualied personnel will invalidate the warranty. Please return to
supplier.
• Unplug your shredder before moving it or when it is not in use for an extended period of time.
• Do not operate with a damaged power supply cord or plug, after it malfunctions, or after it has been
damaged in any manner.
• Do not overload electrical outlets beyond capacity as this can result in re or electrical shock.
• The socket-outlet should be installed near the equipment and shall be easily accessible.
• Do not alter the attachment plug. The plug is congured for the appropriate electrical supply.
• Do not use near water.
• Do not use aerosol dusters or cleaners.
• Do NOT spray anything into the shredder.
• Do NOT load the autofeed chamber with junk mail, magazines, bound documents etc.
Although this shredder has been designed to comply with UL 60950-1 EN 60950-1 safety standards
including the “probe accessibility tests”, do not operate the shredder near children or pets.
There is a ‘cross shaped’ integral safety device, located on the left of the internal loading bay, which
is designed to prevent the shredder from operating when the loading door is open. You must NOT
under any circumstances tamper with with this switch, add any object into the cross-shaped interlock
switch other than the interlock actuator, as to do so would activate the cutting blades.
English
https://www.supplychimp.com/
STACK-AND-SHRED 100X&100M™SHREDDERS 7
warning symbols
This means no aerosols.
This means keep children away
from shredder.
This means you should be careful
because long hair can become
entangled in the cutting head.
This means don’t reach into the
feed opening of the cutting head.
This means be careful of loose
jewellery which could become
entangeld in the cutting head.
This means no oil lubrication,
use Swingline oil sheets only.
This means be careful of ties and
other loose clothing which could
become entangled in the cutting
head.
This means the shredder can
accept small paperclips.
This means the shredder can
accept small staples.
Safety First
Sheet capacity of manual feed
entry slot.
6
control panel and indicators
Continuous Jam BoostReverse Auto
Paper Loading Door/Bin Door
Open or Bin Full indicator –
This means either:
• Loading door is open
• Bin is open
• Bin is full
Paper jam indicator – This means
there is a paper jam in the auto feed
chamber.
If this symbol is ashing the
shredder is attempting to clear a
paper jam automatically.
If this symbol is permanently
illuminated red please follow the
instructions under ‘Rare Occasion
of Jamming’.
Cool Down indicator – This means
the machine is cooling down.
English
Sheet capacity:
Manual feed slot
6 sheets (80gsm)
Sheet capacity:
Autofeed chamber
100 sheets (80gsm)
Auto shutdown After 2 minutes
Duty Cycle 5 min ON / 30 min OFF
technical specifications
Swingline Stack-and-Shred 100X/100M
Run time from cold 10 minutes
Volts / Hz 120V / 60Hz
Amperage 1.5 Amps
Motor Watts 100X: 200 Watts
100M: 350 Watts
https://www.supplychimp.com/
8
Stack and Shred 100X/100M shredding capability
Stack and Shred 100X/100M CAN shred the following:
• 100 sheets
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small sized paper loaded centrally
• 100 sheets
• Paper clip paper, 25mm within the corner (100M through manual feed slot ONLY)
• Capable of shredding small/medium paper clips (max. wire thickness = 0.9 mm)
• >80/100gsm paper (through manual feed slot ONLY)
• A3 folded in half max. 2 sheets
• 100 sheets
• 80 gsm paper
- Letter and Legal
- A3 single sheet folded in half to make A4
Stack and Shred 100X/100M CAN shred (through the manual feed slot):
Thick paper or
card.
Multiple folded
sheets (e.g. A3
sheets folded in
half).
Unopened mail
(e.g. junk mail).
Glossy paper or
a sheet covered
with print on both
sides.
Stack and Shred 100X/100M CANNOT shred the following:
Large clips.
Check the length
of the paperclip
is not longer than
32mm.
Heavy duty
staples. Check
the staple leg
length is not
greater than
6mm.
Bound
documents
Bulldog clips
Magazines or
other documents
bound by multiple
staples or clips.
Adhesive labels.
Plastic sheets,
laminated
documents,
plastic folders.
English
https://www.supplychimp.com/
STACK-AND-SHRED 100X&100M™SHREDDERS 9
1. operation
1 After unpacking the product, pull out the shredder bin. Remove and t the recyclable paper bag
(as per instructions printed on the bag).
2Connect the shredder to mains supply.
3 Ensure the on/o button on the back of the machine is in the on position.
4To commence shredding, press the central Auto button ( ).This will illuminate the blue
standby symbol on the auto button and sets the shredder into auto mode.You are now ready to
shred.
5 Press the loading door button to open the loading door. Load up to 100 sheets at a time into the
feed chamber. Do not ll above the 100 MAX level, this could damage the shredder.
6Close the loading door without pressing the loading door button.The shredder will now start
automatically.
7 If there is still paper in the Autofeed tray after rst attempt, open and re-close paper loading
door a second time.
8If you only have up to 6 sheets to shred, you can use the manual feed entry slot, provided the
auto feed chamber is empty.
9If the shredder is left in auto mode for more than 2 minutes without being used, it will
automatically turn to sleep mode to save power.
10 The shredder will automatically operate from standby mode when paper is inserted into the
manual feed entry slot. Opening either the loading door, empting the bin or pressing any button
will return the product to auto mode.
2. reverse function
1Should you wish to reverse paper out whilst shredding, a reverse button ( ) has been tted for
your convenience.The jam indicator will illuminate.
2 To resume shredding, turn the shredder on using the ON/OFF switch at the rear of the shredder.
Return the switch to the auto position ( ).
Swingline encourages customers to recycle shredded paper.
Please note that shredded paper cannot be recycled if mixed with credit card shards.
If recycling, please separate shredded paper and credit cards.
3. credit card shredding
Stack and Shred 100X and 100M can shred credit cards, not CDs or DVDs. Switch the shredder to
auto mode and insert the credit card into the opening on top of the manual feed entry slot. Swingline
encourages customers to recycle shredded paper. Please note that shredded paper can not be
recycled if mixed with credit card shards. If recycling, please separate shredded paper and credit cards.
bin or loading door open safety function
As a safety precaution, if the bin or loading door is opened during shredding, the shredder will stop
and the bin full indicator will illuminate ( ).
English
https://www.supplychimp.com/
10
over heating
If the Stack and Shred 100X/100M is used continuously for over 10 minutes the shredder may
overheat and the cool down indicator will ash red ( ). Please allow the shredder to cool down.
When the shredder is ready to be used the thermometer symbol will no longer illuminate. If the
shredder needs to cool down while shredding, no action is needed. The shredder will automatically
restart shredding paper once it has cooled down after periods of continuous use. All you need to do
is ensure paper is loaded into the chamber and the bin is empty when the machine is cooling down.
service
We recommend these machines are serviced every 6 to 12 months by a Swingline service
engineer – see back of this booklet for the contact details of your local service centre and for
enquiries about maintenance contracts.
4. self-cleaning cutters
After emptying and replacing a full bin, the shredder will run in forward for 4 seconds, stop for 2 seconds
and then reverse for 4 seconds to clear away any remaining paper from the cutter mechanism.This
unique ‘self-cleaning’ mechanism is additional jam prevention technology from Swingline.
rare occasions of jamming
If after this auto jam clearance cycle the shredder still has a paper jam, it will stop and the jam
indicator illuminate ( ).Try clearing the jam using the reverse ( ) and continuous jam boost
( ) buttons. If this is unsuccessful, open the loading door, remove the remaining stack of paper,
then pull the jammed paper free of the cutting mechanism.
automatic jam clearance
In the unlikely event of the shredder jamming, the Stack and Shred 100X and 100M will
automatically reverse and forward the engine three times to clear a jam. During this operation the
Paper Jam indicator will ash ( ).
5. bin full
The shredder will not function when the bin is full and the bin full symbol ( ) is illuminated.
You should empty the bin.
• Pull open the bin slowly to empty.
• Push the empty bin back into place and press the auto button to resume shredding.
6. maintenance
The rollers on the auto-feed mechanism may become dirty over time, please wipe clean with a dry
cloth to maintain maximum product performance.
The auto-start infra-red sensor, located in the paper feed entry-slot, can occasionally become
covered in paper-dust causing the shredder to run despite no paper being fed into the machine.
Switch the shredder o at the rear of the machine and carefully clean the sensor using a cotton-swab.
English
shredder accessories
Accessory Part Number Box Quantity
Recycling Waste Sack 1765031 20
lubrication of the shredder
Only use oil sheets to lubricate. ACCO Brands accepts no liability for product performance or
safety when other types of lubricants are used on any part(s) of this machine. Insert the oil sheet
into the manual feed slot and NOT in the auto-feed chamber. Using an oil sheet in the auto-feed
chamber will contaminate the feed rollers preventing the auto-feed mechanism shredding. Follow
the maintenance instructions if the rollers become contaminated. Do not directly oil the shredder.
