Sven PS-60 Manuel utilisateur

www.sven.ﬁ

USER’S MANUAL

Portable Speaker System

with FM-radio

PS-60

Congratulations on your purchase of the SVEN speaker system!

BUYER RECOMMENDATIONS

• Unpack the device carefully. Make sure there are no accessories left in the box. Check

up the device for damage; if the product was damaged during transportation, address

the ﬁrm which carried out the delivery; if the product functions incorrectly, address the

dealer at once.

• Shipping and transportation equipment is permitted only in the original container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and com-

puter equipment.

APPLICATION

PS-60 multimedia speaker system is designed to play music. There is a built in

high-quality broadband speaker, FM-tuner, MP3-player, micro SD memory card slot

and USB port for connecting a USB drive.

PACKAGE CONTENTS

• Speaker system – 1 pc

• USB to miniUSB power cable – 1 pc

• Carrying strap – 1 pc

• Li-Ion battery BL-5C (3.7V, 600mA*h) – 1 pc

• User’s Manual – 1 pc

• Warranty card – 1 pc

SPECIAL FEATURES

• LED display

• Headphones jack

• Built-in player with USB ﬂash and with micro SD memory card

• Built-in FM tuner

• Flashlight

ENG

Portable Speaker System

with FM-radio

1 2 3 4 5

6 7 8 9 0

ON OFF USB

ab cde

h i

j k l m

Speaker system description

a Previous track (in Рlayer mode);

Next station (in Radio mode);

Time settings

b Play/Pause button (in Рlayer mode);

MUTE (short pressing in Radio mode);

Start/Stop auto scan (long pressing in Radio mode);

Exit the Time setting mode

c Next track (in Рlayer mode);

Next station (in Radio mode);

Time settings

d M/ : switching modes button: Radio / Player / Clock (short pressing);

Repeat mode selection (long pressing in Рlayer mode);

Enter the Time settings mode (long press in the Clock mode)

e : light on/oﬀ button

f Display

g 0-9: numeric pad to enter the station number or track number

h USB-ﬂash card slot

i TF : Micro SD card slot

Fig. 1. Speaker system description

ENG

User’s Manual PS-60

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Speaker system battery charging

• Connect speaker system to a USB port of PC or USB charger using miniUSB to USB

cable (included). When charging, the battery indicators ﬂash alternately.

When the battery is fully charged, the battery indicator lights up .

Attention! Instead of the BL-5C battery (included), you can use AA batteries (3 pcs.)

(not included). Observe the polarity when installing them.

Fig. 2. Connection diagram

USB jack

Socket

USB to miniUSB power cable

j On/Oﬀ power switch

k Headphones jack

l USB: mini USB jack for charger connecting, the USB port of laptop / PC

m Volume control knob

ON OFF USB

ENG

Portable Speaker System

with FM-radio

OPERATION MODES

Radio mode

• Turn on the speaker system – press button d several times until, the radio mode

will not turn on. Long-term pressing button d activates auto search mode. After

scanning completion, the ﬁrst scanned radio station will start to operate automatically.

With buttons a and c select a desired radio station.

Player mode

Attention! The ﬁle system of a micro SD carrier is FAT32. Maximum volume is

32 GB. It is not recommended to use the micro SD Ultra Speed.

• The system will enter the Player mode automatically when a carrier (USB ﬂash or SD

card) is connected to corresponding ports. Use button b to switch between Play /

Pause modes. You can control tracks by using buttons a (previous track) and c (next

track).

TECHNICAL SPECIFICATIONS

Notes:

• Technical speciﬁcations given in this table are supplemental information and

cannot give occasion to claims.

• Technical speciﬁcations and package contents are subject to change without

notice due to the improvement of SVEN production.

Technical support is on www.sven.ﬁ.

Parameter, measurement unit

Frequency range, Hz

Output power (RMS), W:

Membrane, mm

Battery capacity, mA * h

Power supply, V

Weight, kg

Dimensions, mm

Value

120-20000

Ø 50

600

USB/DC5V

0.21

127 × 73 × 36

ENG

User’s Manual PS-60

Portable Speaker System

with FM-radio

Model: PS-60

Импортер в России: ООО «РЕГАРД», 105082,

г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Уполномоченная организация в России: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

в гарантийном талоне или на сайте www.sven.ﬁ.

Гарантийный срок: 12 мес.

Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано в Китае.

Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,

№ 02-02, Singapore, 427447. Produced under the

control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,

Kotka, Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland. PS-60
