SVAT PI300-SD Manuel utilisateur
with Built-In Color Camera
Covert Alarm Clock DVR
MODEL #: PI300-SD
USER MANUAL
COVERT SYSTEM
PI300-SD 1
NEED
HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a SVAT customer support representative rst regarding additional
information on product features, specications or assistance with setup.
Toll free telephone:
1.866.946.7828
Online live web chat:
Visit www.svat.com
Email:
support@svat.com
Toll free fax:
1.888.771.1701
For more product information visit www.svat.com
Note: This is manual version 1.0 for this product,
you may nd updated versions by visiting
our website.
IMPORTANT! PLEASE READ
PI300-SD 2
PRODUCT WARRANTY INFORMATION
We take quality very seriously. That is why all of our products come with
a one year warranty from the original purchase date against defects in
workmanship and materials. If you have warranty or support issues please
contact us using any of the following methods:
Phone: 1.866.946.7828
Fax: 1.888.771.1701
Email: support@SVAT.com
Website: www.SVAT.com
Warranty Terms
1. SVAT products are guaranteed for a period of one year from the date of purchase
against defects in workmanship and materials. This warranty is limited to the
repair, replacement or refund of the purchase price at SVAT’s option.
2. This warranty becomes void if the product shows evidence of having been mis
used, mishandled or tampered with contrary to the applicable instruction manual.
3. Routine cleaning, normal cosmetic and mechanical wear and tear are not covered
under the terms of this warranty.
4. The warranty expressly provided for herein is the sole warranty provided in
connection with the product itself and no other warranty, expressed or implied
is provided. SVAT assumes no responsibilities for any other claims not specically
Mentioned in this warranty.
5. This warranty does not cover shipping costs, insurance, or any other charges.
6. You MUST call SVAT before sending any product back for repair. You will be sent
a Return Authorization number with return instructions. When returning the
product for warranty service, please pack it carefully in the original box with
all supplied accessories, and enclose your original receipt or copy, and a brief
explanation of the problem and RA#.
7. This warranty is valid only in Canada and the continental U.S.
8. this warranty cannot be re-issued.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK, DO NOT OPEN MONITOR
SVAT USA
60 Industrial Parkway #Z64
Cheektowaga, NY
USA 14227
SVAT CANADA
4080 Montrose Road
Niagara Falls, ON
Canada L2H 1J9
IMPORTANT! PLEASE READ
PI300-SD 3
Disclaimers:
1. Recording capacity may vary based on recording resolution and quality, lighting conditions and movement in the scene. Based on a 2GB SD card, using
lowest quality settings.
2. Product may not be exactly as shown on the package. Some images are used for illustration purposes only.
3. SVAT does not endorse any SVAT products for illegal activities. SVAT is not responsible or liable in any way for any damage, vandalism, theft or any other
action that may occur while a SVAT product is in use by the purchaser.
Covert DVR Disguised as an Alarm Clock
Hidden in a fully functional, Magnasonic LED alarm clock, you can privately monitor your oce, employees, valuables or nanny with this unit’s conventional appearance.
Record Over a Month of Footage with the Included 2GB SD Card1
Capture over a month of high quality video when you record with the included 2 GB SD card. Easily remove the SD card to backup your footage to a computer.
Motion Activated Recording
Choose to record only when motion is detected and capture just the important events while conserving space on your SD card.
Easily Connect to a TV or Monitor
Review recorded footage easily by connecting the DVR to a television or monitor.
Fully Functional Alarm Clock
This unit also operates as a fully functional LCD alarm clock with alarm and snooze functions.
High Quality MPEG-4 Compression
MPEG-4 compressed recording allows for hours and hours of capturing footage without sacricing video quality to conserve space.
Compatible With High Capacity SD Memory Cards up to 32 GB
The PI300 comes with an included 2 GB SD card, if you should require more memory for your system, you can install a SD card up to 32 GB.
24/7 Lifetime Customer Support
Our customer support team can be reached by phone 24/7 or by email and live web chat services, so you can always have access to an expert.
FEATURES
PI300-SD 4
WHAT’S INCLUDED
Covert DVR Alarm Clock 2GB SD Card
Power Adapter RCA Cable
• User Manual • 24/7 Lifetime Live
Customer Support
Need Help Page .............................................................. 1
Warranty Information ..................................................... 2
Features ......................................................................... 3
Table of Contents ............................................................ 4
What’s Included .............................................................. 4
Buttons and Connections ................................................. 5
Installation .................................................................... 6
Introduction ................................................................... 7
Setting the LCD Alarm Clock ............................................. 8
Main Menu ..................................................................... 9
DVR Settings ................................................................... 10
Search and Play ........................................................................... 10
Set Date/Time ............................................................................. 10
Set Motion Detection .................................................................. 11
Motion Detection Sensitivity ....................................................... 11
Manual Record ............................................................................ 12
Schedule Record .......................................................................... 12
Motion Record ............................................................................. 13
Continuous Record ...................................................................... 13
SD Card Status ............................................................................. 14
System Status ............................................................................. 15
Power ON Setup .......................................................................... 15
Factory Default ............................................................... 16
Camera Specications ..................................................... 16
DVR Specications ........................................................... 17
TABLE OF CONTENTS
PI300-SD 5
2
1
10
14
15
1. AC Jack: Connect AC Adapter to this location
2. SD Card Slot: Insert SD Card in this slot
3. 1/4” RCA Jack: Connect RCA video cable to this location
4. Record LED: Indicates recording
5. Power LED: Indicates unit is connected to power source
6. Joystick: Operate the menu by moving up, down, left, right
and select menu options
7. Stop: Stop manual recording / stop playback / navigate
back in menu
8. Record: Start manual recording
9. Play: Prompts playback / plays video
10. Time Switch: Select to adjust time, alarm or set to be locked
Up Alarm Set
Mid Time Set
Down Time Lock
11. Alarm Switch:
Up Alarm On
Down Alarm O
12. Hour: Increase hour by one
13. Snooze: Snooze button, delays alarm for 9 minutes
14. Minute: Increase minute by one
15. Camera: Covert pinhole camera
786
3
9
12
13
11
4
5
BUTTONS AND CONNECTIONS
PI300-SD 6
PI300-SD was designed to be quick and easy to set up and to use. Please follow
these simple instructions to get your covert DVR up and running in just a matter
of minutes.
Powering your PI300
1. Connect the included AC adapter to conventional AC outlet.
2. Connect AC adapter to AC Jack (1) on the back side of PI300.
Connect your PI300 to a TV
1. Connect the included RCA cable to the RCA Jack (3) on the back side of PI300.
2. Connect the RCA cable to the Yellow RCA Composite Video Input Jack of your
television.
View your PI300 on a TV
1. Once you have connected your PI300 to your TV, power both units on.
2. Set your TV’s input source to “VIDEO,” “AUX” or whichever source is required
for viewing your connected devices.
INSTALLATION
PI300-SD 7
Monitoring Mode
PI300-SD ICONS
Manual Record
Indicates manual record is on
Motion Record
Indicates motion record is on
Scheduled Record
Indicates scheduled continuous
record is on
Recording
This circle will appear on your display while
your covert DVR is rrecording
Quality Level
Indicates quality level: low (LQ) medium (MQ)
and high (HQ)
Resolution
Indicates the resolution being recorded
320x240 or 640x480
Power
Indicates covert DVR is
connected to power source
Overwrite
Indicates overwrite is enabled
SD Card
Indicates SD card is installed
GETTING STARTED
As soon as you power on your PI300 you will automatically be brought to Monitoring Mode.
From here you will be able to access the main menu, trigger manual recording or view
previously recorded footage.
The top bar of your screen will display the date and time of your covert DVR. The bottom bar
will feature icons indicating what actions are taking place on your PI300.
Please, take the time to read through this manual in its entirety to get the most out of your
covert recording experience with the PI300-SD.
INTRODUCTION
PI300-SD 8
PI300 is a covert DVR hidden inside of a fully functional Magnasonic LCD alarm
clock. Follow these basic steps to setup the external alarm clock portion of
your covert DVR:
To set the time:
1. Adjust the Time Switch to the mid position, this will enable time set.
2. Press the hour button to increase the time, in hours, by one.
3. Press the minute button to increase the time, in minutes, by one.
4. When you have nished setting the time, adjust the Time Switch to the
down position to prevent any adjustments.
To set the alarm:
1. Adjust the Time Switch to the up position, this will enable alarm set.
2. Press the hour button to increase the alarm time, in hours, by one.
3. Press the minute button to increase the alarm time, in minutes, by one.
4. When you have nished setting the alarm time, adjust the Time Switch
to the down position to prevent any accidental adjustments.
To enable the alarm:
1. Adjust the Alarm Switch to the up position to enable alarm.
2. Adjust the Alarm Switch to the down position to disable alarm.
To turn o the alarm / use the snooze button:
When the alarm is set and enabled, an audible buzzer will sound at the set
time.
1. To turn o activated alarm, move the Alarm Switch down to disable
alarm.
2. While alarm is activated, press the snooze button to disable the alarm
for 9 minutes. After 9 minutes, the alarm will sound again and you
will again be prompted to either press the snooze button or turn o
the alarm.
NOTE: The time displayed on the LCD Alarm Clock must set
independently from the time setting on the covert DVR.
SETTING THE LCD ALARM CLOCK
PI300-SD 9
To access the main menu, press the joystick button. Navigation throughout the main menu is made easy with the directional joystick: move it up or down to
navigate the menu, left or right to adjust settings and use the “STOP” button to go back a screen.
The following options are available in the main menu:
Search and Play: This option prompts the le list, view all of your recorded footage here
Set Date / Time: Congure the date, date format and time for your PI300
Set Motion Detect: Set a customized area for motion detection and adjust the camera’s
sensitivity to picking up movement
Manual Record: Congure the resolution, frame rate and quality of manual recordings
Schedule Record: Set up a 24 hour recording schedule and adjust the resolution, frame rate
and quality for each of your scheduled recording types
SD Card Options: This option displays the size of your SD Card as well as how much space is
available. Additionally, you can specify the size of recorded les and set
automatic overwriting
System Status: Dispalys all of the current settings of your PI300
Power On Setup: Set your OSD language and video format
Factory Default: Return the settings of your PI300 to its original factory defaults
Main Menu Screen
MAIN MENU
Autres manuels pour PI300-SD
3
Table des matières
Autres manuels SVAT DVR
SVAT
SVAT CV0104DVR Manuel utilisateur
SVAT
SVAT PI300-SD Manuel utilisateur
SVAT
SVAT PI300-SD Manuel utilisateur
SVAT
SVAT CLEARVU1 Manuel utilisateur
SVAT
SVAT CV1002 Manuel utilisateur
SVAT
SVAT CLEARVU4 Manuel utilisateur
SVAT
SVAT GX5400 Manuel utilisateur
SVAT
SVAT CV1010 Manuel utilisateur
SVAT
SVAT CV101DVR Manuel utilisateur
SVAT
SVAT ClearVu CVDVR200 Manuel utilisateur
